THT-EX L1319 Operating Instructions

Universal explosion proof led lighting

Advertisement

Quick Links

Operating Instructions
Universal Explosion Proof LED Lighting
Model L1319
Drawing No: Instructions_L1319_IECEx
Revision Level: 01
Top Hi-Tech Co., Ltd.
5F., No. 113, Zhongcheng Rd.,
Tucheng District,
New Taipei City, 236 Taiwan
Website:
www.tht-ex.com
Contents
1.
General Safety Instructions ..................................................................................................1
2.
Intended Field of Application ...............................................................................................1
3.
Technical Data ..................................................................................................................2
4.
Model Code ....................................................................................................................2
5.
Dimension .......................................................................................................................3
6.
Assembly and Installation ........................................................................................................3
7.
Maintenance ...................................................................................................................5
8.
Accessories and Spare Parts .................................................................................................5
9.
Transport, Storage and Disposal ............................................................................................5
1.

General Safety Instructions

This manual contains basic safety instructions to be observed during installation, operation and
maintenance of the apparatus, and for properly and safety run of the apparatus according to its
performance data. Any damage of the apparatus may result explosion protection null and void. This
manual represents the most relevant information about the product, applicable codes and regulations shall
supplement it. Non-observance will endanger persons, plant and the environment. The person in charge is
required to secure its employment in the industrial unit. Any improper usage, as well as non-compliance
with the rules under this manual, shall release the manufacturer's all responsibilities.
The flameproof joints are not intended to be disassembled or repaired.
WARNING - The luminaire shall not be opened
1.1 Before assembly/commissioning:
F
Read through the operating instructions.
F
Give adequate training to the assembly and
operating personnel.
F
Ensure that the contents of the operating
instructions are fully understood by the
personnel in charge.
F
The national installation and assembly
regulations (e.g. IEC/EN 60079-14) apply.
2.

Intended Field of Application

The Universal Explosion Proof LED Lighting, Model L1319 is intended for using in gas explosive
atmospheres (Zone 1 and Zone 2 according to IEC60079-10-1) and dust explosion hazards (Zone 21 and Zone
22 according to IEC60079-10-2). The use in other potentially explosive atmospheres does not correspond to
Date: 2016-10-28
TEL: +886 2 22689570
FAX: +886 2 22689571
e-mail: sales@tht-ex.com
Revision: EX-L1319-01
Subject to alterations.
WARNING
1.2 When operating the device:
F
Ensure the operating instructions are made
available for the person in charge on
location at all times.
F
Observe these instructions, other working
instructions and national safety regulations.
F
Verify the implementation of safety
instructions.
1
