Room sensor WL
Art.-No. BTERWL/BW
Operating Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTERWL/BW and is the answer not in the manual?

Questions and answers

Summary of Contents for Schluter Systems BTERWL/BW

  • Page 1 Room sensor WL Art.-No. BTERWL/BW Operating Instructions...
  • Page 2: Information On Safety

    1. About these operating instructions 1.1 About these operating instructions These operating instructions describe the room sensor WL (also referred to as “product” in these operating instructions). These operating instructions are part of the product. • You may only use the product if you have fully read and understood these operating instructions. •...
  • Page 3: Transport And Storage

    3. Transport and storage The product may be damaged as a result of improper transport or storage. NOTICE IMPROPER HANDLING • Verify compliance with the specified ambient conditions during transport or storage of the product. • Use the original packaging when transporting the product. •...
  • Page 4 4.3 Function The single room temperature controller is used to control the temperature in rooms with underfloor heating system (heating/cooling). The product measures the actual temperature in the corresponding room. The reference temperature is adjusted via the rotary dial of the corresponding product.
  • Page 5 5. Mounting 5.1 Preparing mounting In case of using multiple products, create an installation diagram that shows the individual installation locations prior to installation. Label the individual products with a number or the name of the installation location as shown in the diagram. B Make sure all connected devices are accessible at the installation location.
  • Page 6: Montage

    2. Lift up and remove the twist-lock plate. entfernt werden. 3. Remove the upper part of the housing. 3. Nehmen Sie das Gehäuseoberteil ab. 2. Der Drehknopf wird angehoben und kann entfernt werden. 3. Nehmen Sie das Gehäuseoberteil ab. BTERWL/BW...
  • Page 7 Produkt mit einem Schraubendreher wieder in die Ausgangs- position. BTERWL/BW 6. Setzen Sie das Gehäuse- 7. Fit the upper part of the housing and the rotary dial to the bottom oberteil und Drehknopf part of the housing. Verify correct position with reference to the axis auf das Gehäuseunterteil.
  • Page 8 5.3 Inserting a battery (optional) If daylight is below 200 Lux, use an optional battery (see “Technical data”, not included in the scope of supply). 1. Remove the twist-lock plate and the top housing (see “Installing the product”). 2. Insert the battery into the battery compartment (A). - Observe proper polarity.
  • Page 9: Operation

    7. Operation 7.1 Adjusting the room temperature 1. Adjust the desired temperature at the thermostat. - Without temperature reduction: The room temperature is set to the adjusted value - With temperature reduction: The room temperature is set to a value 4 K below the adjusted value Fig.
  • Page 10: Betrieb

    Begrenzer mit der Ein- stellkante (B) auf den gewünschten Wert für die Maximaltemperatur und legen den roten Begren- zer dort ab. BTERWL/BW 3. Drehen Sie die Nocken- schraube am Produkt in Ausgangsposition zurück, damit der Drehknopf wie- der eingesetzt werden kann.
  • Page 11: Maintenance

    3. Dispose of the product and the optional battery separately. 11. Warranty See our terms and conditions or your purchase contract for information on warranty. 12. Spare parts and accessories Product Product designation Part no. Figure Room sensor WL BTERWL/BW...
