Summary of Contents for Fogco EC20
- Page 2 Example 30' x 96' SOLAR/BATTERY EC20 MAX DC SF. B20BLDC30 Greenhouse Layout _& Connect only to low voltage DC power supply. Not warranted for use over 45V DC intake vent • (at ground) /2,. WARNING: NO SERIES WIRING. Do NOT wire multiple fans in series to power supply.
- Page 3 Flat head screws should sit 7. Once mount assembly has been flush into the counter sunk holes of securely hung, install EC20 Max choice on T Bracket Plate. Place washers Snap-Fan’s motor clamp to the under locknut and tighten securely to narrow-exposed end of the lower attach the T Bracket Post to Plate.
- Page 4 SF.1358...
