- Page 1 All manuals and user guides at all-guides.com 1100W DIGITAL INVERTER Instruction Manual PLU 553026 For service, spare parts or product information, please contact Smart Marketing Group Pty. Ltd. AUST. 1300 660 457 N.Z. 0800 474 876 03738 05/18...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com SUGGESTED APPLICATIONS CONTENTS These are some suggestions of appliances which could Section Page be powered by this generator. These suggestions cannot Contents be run at the same time, please read page 13 for full Suggested Applications details: Introduction... -
Page 3: Introduction
All manuals and user guides at all-guides.com INTRODUCTION What is covered • Manufacturing fault or defect. Dear Customer, Thank you for purchasing this generator which has How to claim under this warranty passed through our extensive quality assurance • Call customer service, phone number to the left. processes. - Page 4 All manuals and user guides at all-guides.com COMPLETE WARRANTY STATEMENT – GENERATORS As soon as you have purchased the generator, we Damage caused by third party accessories is not recommend that you check to make sure it is intact and covered under this warranty.
-
Page 5: General Safety Instructions
All manuals and user guides at all-guides.com LUBRICATION OF ENGINE PROTECT POWER LEADS FROM DAMAGE Your engine comes with NO oil in the sump. You will need Always disconnect power cords from a power supply to add engine oil, refer to pages 8 and 10 for complete socket by pulling the plug. - Page 6 All manuals and user guides at all-guides.com EXTENSION CORDS & REELS Inspect extension cords periodically and replace if Ear Protection damaged. Never use damaged extension cord as these The use of ear protection is highly recommended when may cause injury. Always unwind any extension cords using generators.
-
Page 7: Specific Safety Instructions
All manuals and user guides at all-guides.com SPECIFIC SAFETY INSTRUCTIONS • Your generator is factory set, NEVER attempt to speed Warning! Do not use the generator in areas where there is it up as this could endanger the user and damage the a risk of explosion or fire from combustible materials. -
Page 8: Electrical Information
All manuals and user guides at all-guides.com IMPORTANT ELECTRICAL DATA This generator is fitted with a sealed electrical connection socket that is compatible with the generator. If the electrical connection socket becomes damaged it must be replaced with a complete assembly that is identical to the original, and this must be replaced by an authorised service agent. -
Page 9: Components & Controls
All manuals and user guides at all-guides.com PIC. 1 COMPONENTS & CONTROLS (PIC.1) 3. Overload indicator (red): This indicator light is on when the generator is overloaded, check attached products 1. Low oil level indicator (yellow): this light is off when power, refer to page 13. -
Page 10: Operating Instructions
All manuals and user guides at all-guides.com OPERATING INSTRUCTIONS PIC. 2 UNPACKING Carefully unpack your generator. This generator is heavy (19kg) and may require two (2) people to lift. Dispose of all packing material in an environmentally responsible manner. Oil Filler Cap Open carton, gently lift the generator clear of the carton and packaging, this may require 2 people. - Page 11 All manuals and user guides at all-guides.com PIC. 5 PIC. 6 Earth Point GENERATOR ‘EARTHING’ PIC. 6A Always ensure that this generator is “Earthed” BEFORE starting and using. 1. Ensure that engine is OFF when fitting the “Earth” stake and wire. 2.
- Page 12 All manuals and user guides at all-guides.com 6. Hold down the generator firmly with one hand on the PIC. 9 frame, then pull the recoil starter slowly until engaged, then pull briskly, Pic. 9. This step may need to be repeated until generator engine starts, this can take up to about 12 pulls.
- Page 13 All manuals and user guides at all-guides.com USING YOUR GENERATOR PIC. 13 AC OUTLET Your generator is equipped with a 240V AC power socket. This will run a range of devices providing they are with in the limits of the generators output. NOTE: The peak (surge) power requirements of some devices e.g.
- Page 14 All manuals and user guides at all-guides.com OUTPUT POWER ALERT 4. Push the circuit breaker back in, it should stay in. If not the circuit breaker is still over heated, allow to Green light will always glow when power supply is good. cool down for another 2 minutes before trying again If it goes out it will generally be due a power overload, to push it in.
- Page 15 All manuals and user guides at all-guides.com STORAGE If the generator is not to be used or is to be stored for more than one month the following storage procedure should be carried out. Drain all the fuel from the fuel tank (refer to page 18) and the carburettor (see below), ensure that all the fuel has been drained.
-
Page 16: Maintenance Chart
All manuals and user guides at all-guides.com MAINTENANCE CHART Item Remark Pre-operation Initial 1 month or Every 3 month Every 6 month Every 12 month check (daily) 20 hours or 50 hours or 100 hours or 300 hours Check condition Spark plug Adjust gap and clean Replace if required... -
Page 17: Maintenance
All manuals and user guides at all-guides.com MAINTENANCE PIC. 15 CHECKING/CLEANING THE AIR FILTER For proper performance and long life, keep air filters clean. 1. Remove access panel screw and remove panel. 2. Lift up both air filter clips (Pic. 15). AIR FILTER BOX 3. - Page 18 All manuals and user guides at all-guides.com CLEANING THE EXHAUST PORT & MUFFLER PIC. 19 Depending on the type of fuel used, the type and amount of oil used, and/or your operating conditions, the exhaust port and muffler may become blocked with carbon deposits.
-
Page 19: Fault Chart
All manuals and user guides at all-guides.com FAULT CHART ACTION No oil/ Low oil level Fill sump with correct oil, See page 8 Loose spark plug Tighten plug Insufficient Loose cylinder Tighten bolt compression head bolt Damaged gasket Replace gasket FUEL SYSTEM PROBLEMS Insufficient pulling Pull rope sharply... - Page 20 All manuals and user guides at all-guides.com FAULT CHART CONTINUED ACTION Tripped circuit breaker Reset Poor connection or faulty lead Check and repair Indicator light ON. No AC output Broken recepticle Faulty circuit breaker Check and repair Indicator light OFF. Generator problem No AC output Output power too...
-
Page 21: Service Log
All manuals and user guides at all-guides.com SERVICE LOG This service is to be completed within 50 hours This service is to be completed within 100 hours or 3 months of purchase, which ever comes first. or 6 months of purchase, which ever comes first. Replace Check &... -
Page 22: Specifications
All manuals and user guides at all-guides.com SPECIFICATIONS Inverter generator..............TP1100DG Engine type..........Single cylinder, 4 stroke 70cc Engine speed..............3300-5100 r/min Oil tank capacity................450 mL Oil type......4 stroke motor oil, SAE 30W or SAE 15W-40 Fuel tank capacity.................3L Fuel type..........Unleaded 91 Petrol - no ethanol Spark plug.................. - Page 23 All manuals and user guides at all-guides.com...
- Page 24 All manuals and user guides at all-guides.com 1100W DIGITAL INVERTER 3L Fuel tank Output LED Light Generator ON/OFF switch Recoil starter USB outlet 240V AC~50Hz 12V DC Cigarette Outlet socket lighter socket Manufactured and packaged for SRGS PTY LTD ABN 23 113 230 050 751 Gympie Road, Lawnton, Queensland 4501, Australia...
