American Hearth ALS3236FFD-1 Installation Instructions And Owner's Manual

For use with dvcc(32,36,42)-3 fireplaces

Advertisement

Quick Links

INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
If the information in these instructions are
not followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
WARNING
LOG SET MODELS
ALS3236FFD-1
For Use With
DVCC(32,36,42)-3 Fireplaces
DRIFTWOOD
NOTICE: Crushed glass and ceramic fiber rocks
may differ in appearance from those shown in
this manual.
If not installed, operated and maintained in
accordance with the manufacturer's instructions,
this product could expose you to substances in
fuel or from fuel combustion which can cause
death or serious illness.
GAS-FIRED
WARNING

Advertisement

loading
Need help?

Need help?

Do you have a question about the ALS3236FFD-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for American Hearth ALS3236FFD-1

  • Page 1 INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL LOG SET MODELS INSTALLER: GAS-FIRED ALS3236FFD-1 Leave this manual with the appliance. CONSUMER: For Use With DVCC(32,36,42)-3 Fireplaces Retain this manual for future reference. DRIFTWOOD WARNING If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2 LOG SET IDENTIFICATION INDEX LETTER PART FRONT & DESCRIPTION NUMBER VIEW VIEW Center 37633 Right 37635 Left 37634 Decorative 32780 Rocks (Large) Decorative 32781 Rocks (Small) Decorative 37636 Sticks Page 2 37710-1-0617...
  • Page 3 LOG SET & DECORATIVE ROCK PLACEMENT ATTENTION: The position of the crushed glass and ceramic REPLACEMENT PARTS PART NUMBERS fiber accessories is critical for the safe and clean operation Decorative Rocks 32780 32781 of this fireplace. Sooting and other problems may result if Contact your Empire the crushed glass and ceramic fiber rocks are not properly Crushed Glass...
  • Page 4: Log Placement

    LOG PLACEMENT STEP 1. Push up pin on the right shown below. Replace burner cover inside fireplace. Top View Front View Page 4 37710-1-0617...
  • Page 5 LOG PLACEMENT STEP 2. Apply a thin layer of Crushed Glass over the burner surface and cover. See image below. Top View Front View 37710-1-0617 Page 5...
  • Page 6 LOG PLACEMENT STEP 3. Place (Log Index Letter A) onto pins 1 and 4. See image below. Top View Front View Page 6 37710-1-0617...
  • Page 7 LOG PLACEMENT STEP 4. Place (Log Index Letter B) onto the right pin on log A and angle behind log A. See image below. Top View Front View 37710-1-0617 Page 7...
  • Page 8 LOG PLACEMENT STEP 5. Place (Log Index Letter C) onto the left pin on log A and angle in front of log A. See image below. Top View Front View Page 8 37710-1-0617...
  • Page 9 LOG PLACEMENT STEP 6. Place (Log Index Letters D, E, F) Decorative Rocks and Sticks on top of crushed glass. See image below. Glowing embers may be placed along the circular ports on the burner as shown in Figure 5. Top View Front View 37710-1-0617...
  • Page 10 LOG PLACEMENT STEP 7. This completes the assembly of the decorative media and log set. Replace glass door and barrier screen as indicated in the fireplace manual. Top View Front View Page 10 37710-1-0617...
  • Page 11: Master Parts Distributor List

    MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort. com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit.
  • Page 12 Empire Comfort Systems Inc. Belleville, IL If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com Page 12 37710-1-0617...
