- Page 1 OSLT Calibration Kit NEX10 ® (50 ohms) BN 355112 Note: NEX10 is a registered trademark of HUBER&SUHNER, Radiall and ROSENBERGER...
- Page 2 Dear Customer, Thank you for the trust you have placed in us by buying a SPINNER calibration kit. Each SPINNER calibration kit is carefully tested and subject to strict quality controls by Spinner’s quality assurance. Nevertheless, the service life of a calibration kit depends to a great extent on you. Observe the information contained in these instructions and the enclosed documentation.
-
Page 3: Table Of Contents
10. Handling and Storage ..........................10 11. Recalibration ............................. 10 12. Spare parts ............................... 10 13. Disposal ..............................11 14. Warranty ..............................11 15. Contacts ..............................11 Data subject to change without notice │ M36544 │ Issue B │ 2020-12-11 3 / 11 www.spinner-group.com... -
Page 4: General Safety Information
The following instructions and safety instructions are to be carefully read and followed! The Spinner group makes every effort to keep the safety standard of our products up to date to be able to offer our customers the highest possible degree of safety. Our products are designed and tested in accordance with the relevant safety standards. - Page 5 Repair must be carried out only by the manufacturer or technical personnel authorized by the manufacturer. Unless otherwise specified, Spinner products are not protected against penetration of liquids, gases, steam, etc. If this is not taken into account, there exists the danger of electric shock for the user or damage to the product, which can also lead to personal injury.
-
Page 6: Product Identification
Product Identification The SPINNER calibration kit BN 355112 has a type label on the top of the box containing the following information for product identification: OSLT- Calibration Kit NEX10 ® BN 355112 (SPINNER part number) Ser. No: XXX (Serial number) -
Page 7: Offset Opens And Shorts
The electrical, mechanical and environmental specifications of the calibration kit are given in the data sheet file “355112-BE” on the USB stick. The data sheet is available for download at www.spinner-group.com. ATTENTION Temperature changes may have an impact on electrical characteristics. Therefore, the operating temperature is a critical performance factor. -
Page 8: Use And Preventive Maintenance
(e.g. swabs with polyvinylidene fluoride tip). • Never put lateral pressure on the connector’s inner conductor. • The inner conductor does not require cleaning. Data subject to change without notice │ M36544 │ Issue B │ 2020-12-11 8 / 11 www.spinner-group.com... -
Page 9: Gauging Connectors
Separate the components in turning only the coupling nut. Disconnect the components straight without any bending, twisting or rocking of the connectors. Data subject to change without notice │ M36544 │ Issue B │ 2020-12-11 9 / 11 www.spinner-group.com... -
Page 10: Handling And Storage
The suggested initial interval for recalibration is 12 months or 500 matings, whichever comes first. The actual need for recalibration depends on the use and the maintenance of the kit. The recalibration interval should begin with the day of initial use after recalibration. The SPINNER recalibration service includes cleaning of the connector interfaces ... -
Page 11: Disposal
Warranty Do not disassemble any component of the calibration kit. The warranty is void, if components are modified, improperly handled or third party intervention or modification has occurred. Contacts SPINNER GmbH • Headquarters Erzgiessereistr. 33 80335 München Germany tel.: +49 89 12601-0 fax: +49 89 12601-1292 info@spinner-group.com...
