Summary of Contents for Anest Iwata Revolution Airbrush Series
- Page 1 HP-AR | HP-BR | HP-CR | HP-CR3 | HP-SAR | HP-BCR Operating Instruction Manual IR102-IM-NJI...
- Page 2 Iwata Revolution Series and NEO For Iwata Series airbrushes deliver soft, effortless coverage at low air pressures. Fine atomization is achieved with the smallest of air compressors, making these airbrushes a simple choice for medium spray applications and for anyone wanting to start airbrushing for the first time.
-
Page 3: Need Assistance
NEED ASSISTANCE If you have any issues or warranty service questions, contact your local ANEST IWATA a liate before returning to your place of purchase. ANEST IWATA-MEDEA, INC. ANEST IWATA CORPORATION ANEST IWATA AUSTRALIA PTY LTD. Portland, Oregon U.S.A. Yokohama, Japan Mt. - Page 4 IWATA REVOLUTION HP-AR, HP-BR, HP-SAR, HP-BCR,HP-CR AND HP-CR3 Iwata Revolution HP-AR • Internal mix airbrush • Ergonomic handle • Spray pattern from .75” down to hairlines • Smaller nozzle and needle combination allows for detailed spraying in smaller areas • Redesigned trigger mechanism and larger needle chuck nut for easy assembly •...
- Page 5 Iwata Revolution HP-BR Iwata Revolution HP-SAR • Internal mix airbrush • Siphon feed, single action airbrush • Ergonomic handle • Perfect for those seeking high performance • Spray pattern from .75” down to hairlines in a single-action design • Smaller nozzle and needle combination •...
- Page 6 Iwata Revolution HP-BCR Iwata Revolution HP-CR • Internal mix airbrush • Internal mix airbrush • Ergonomic handle • Ergonomic handle • Spray pattern from 1.5” down to fine lines • Spray pattern from 1.5” down to fine lines • Larger nozzle and needle combination allows •...
- Page 7 Iwata Revolution HP-CR3 • Internal mix airbrush • Ergonomic handle • Spray pattern from .75” down to hairlines • Smaller nozzle and needle combination allows for detailed spraying in smaller areas • Replaceable internal PTFE needle packing for use with solvent-base paints •...
-
Page 8: Getting Started
GETTING STARTED Compressor 9. BCR: Pull back on main lever to open the nozzle of airbrush. Choose an appropriate compressor for your Revolution 10. SAR only: Unscrew the fluid adjustment knob (#15) to airbrush. The Iwata Sprint Jet and Smart Jet compressors open the airbrush nozzle and press down on trigger. -
Page 9: General Operation
GENERAL OPERATION Fine-Line Spray (AR, BR, BCR, CR, CR3) Fine-Line Spray (SAR) 1. Depress the main lever (#6) to start airflow. 1. Depress the main lever (#7) to start airflow. 2. Position the airbrush close to the surface, between 1/16 2. - Page 10 GENERAL OPERATION Wide-Line and Background Spraying (SAR) Air Pressure 1. Depress the main lever (#7). For the Revolution, working pressures generally vary between 20 and 60 psi, depending on what type of work is being done 2. Position the airbrush farther away from the surface, from and what textures are desired.
-
Page 11: Maintenance
MAINTENANCE 1. Remove the paint bottle. • If the needle stops abruptly, retract and examine the trigger 2. Attach a bottle containing the appropriate cleaning solution. mechanism for proper assembly and re-insert the needle. 3. Spray until the solution sprays clear. 7. - Page 12 MAINTENANCE Before Each Session 5. Wipe the needle with a soft, clean cloth, leaving a light Spray water or the appropriate paint solvent through the coat of lube behind. airbrush to make sure the airbrush is working properly. 6. Re-insert the needle gently into the airbrush. 7.
-
Page 13: Troubleshooting Procedures
TROUBLESHOOTING PROCEDURES Solution Symptom Problem •Tighten (#2) finger tight •Bubbles in color cup or bottle •Loose nozzle cap •See nozzle (#3) to reseat the nozzle •Improper nozzle to body connection •See nozzle (#3) to replace the nozzle •Cracked or damaged nozzle •See cleaning the needle •Double Line •Dried paint on needle tip (Tip-Dry) - Page 14 TROUBLESHOOTING PROCEDURES Symptom Problem Solution •Skipping •Dried paint on needle tip (Tip-Dry) •Clean with cotton swab dipped in cleaner •Pigment too thick •See paint preparation •Air pressure too high •See specific compressor instructions to lower the air pressure •Improper nozzle to body connection •See nozzle (#3) to reseat the nozzle •Dirty airbrush •See cleaning the airbrush between colors...
-
Page 15: Replacement Parts And Accessories
REPLACEMENT PARTS AND ACCESSORIES Nozzle (#3) Needle (#11) Iwata needles are made of precision ground and hardened In time, the nozzle may wear or be damaged and may need stainless steel that will withstand prolonged usage. They are, to be replaced. however, subject to easy physical damage because of the 1. - Page 17 PRICE PRICE ITEM DESCRIPTION ITEM # HP-AR HP-BR HP-BCR HP-CR HP-CR3 HP-SAR ITEM DESCRIPTION ITEM # HP-AR HP-BR HP-BCR HP-CR HP-CR3 HP-SAR CODE CODE Needle Spring I1351 I7012 Needle Cap 10 Spring Guide I7701 I7011 I7171 I7022 11 Needle Nozzle Cap I7173 I7021 12 Needle Chucking Nut...
- Page 18 This warranty does not cover damage caused by negligence or airbrushes which have been altered or abused in any way. ©2018 Anest Iwata-Medea, Inc. All rights reserved.
