GETTING STARTED

Home – On this screen function tiles provide at-a-glance information and quick
access to common TD4 tasks: Duplicate, Logical, Case Info, Job History, Hash,
Verify and Restore.
At any time, click on "TD4" in the top menu bar to navigate back to the Home screen.
Drive Info – Drive tiles display on the sides of the UI and match the source and
destination port locations. When a drive is detected by TD4, the associated drive tile
will become active. Click on an active drive tile to view the drive's details.
Job Status – Provides a summary of the current job's details/status. To access,
click on the that appears in the top menu bar or from the Home screen, click on
the progress bar within the active job's function tile.
Side Navigation Menu – Located in the upper left corner
Administration, Lock System and About (device and firmware information)
Clock – After initial start-up or following a factory setting reset, verify the
TD4's date, time, and time zone are properly set:
> System Settings.
For a comprehensive overview of the TD4's features and functions, see the
Tableau TD4 User Guide: opentext.com/products/tableau-forensic

CABLE RECOMMENDATIONS

For SATA/SAS Drive
For USB Drive
For PCIe Drive*
For FireWire Drive**
For IDE Drive***
For Power (DC In)
* A Tableau Forensic PCIe Adapter is required to connect PCIe media.
** The Tableau Forensic PCIe- FireWire Adapter [TDA7-9] is required to connect FireWire devices.
*** The Tableau Forensic PCIe-IDE Adapter [TDA7-5] is required to connect IDE drives.

SUPPORT

For Tableau Forensic product support:

ABOUT OPENTEXT

OpenText, The Information Company, enables organizations to gain insight through
market leading information management solutions, on-premises or in the cloud. For
more information about OpenText (NASDAQ: OTEX, TSX: OTEX) visit: opentext.com.

CONNECT WITH US:

• OpenText CEO Mark Barrenechea's blog
• Twitter | LinkedIn
Use a Tableau SATA/SAS Signal & Power cable
[TC4-8-R4]
Use cable supplied with USB drive enclosure or
directly connect
Use a USB-AC adapter [TCA-USB3-AC] as needed
Use a Tableau PCIe cable [TC-PCIE-8]
Use cable supplied with FireWire device
Use a Tableau IDE power cable [TC2-8-R3] and
Tableau PCIe cable [TC-PCIE-8]
Use a Tableau Power Supply [TP6]
opentext.com/support/contact/guidance
, access Home, Settings,
