Hubbell GAI-Tronics 42003-216A Manual

RigCom Aluminum Horn
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.

General Information

The Model 12804-001 RigCom Aluminum Horn Replacement Kit includes the following components:
Qty Description
1 Model 13419-003 Aluminum Horn
1 Model 13424-002 Cone
28109-003 Fiber washer, 1.312 O.D. × 0.75 I.D. × 0.030 thick
1
13357-004 Rubber washer, 1.30 O.D. × 0.75 I.D. × 0.090 thick
1
13357-005 Steel washer, 1.875 O.D. × 1.40 I.D. × 0.070 thick
1
13357-006 Fiber washer, 1.875 O.D. × 1.40 I.D. × 0.015 thick
2

Installation

Assemble the Model 12804-001 RigCom Aluminum Horn Replacement Kit according to the order shown
in Figure 1 on page 2.
