Summary of Contents for Zumimall G4K
- Page 1 ZUMIMALL ® Get Smarter About Your Security 4G LTE Security Camera QUICK START GUIDE...
- Page 2 Over the years, Zumimall has served 45 continents of America, covering 80% of the population. Zumimall is the provider of a smart lifestyle and a guardian of the wonderful moments of your life.
-
Page 3: What's In The Box
What's in the Box? Charging Camera Camera Bracket Cable Solar Panel Solar Panel Screw Bag Bracket SIM Card Product SIM Card Tweezers Manual... -
Page 4: Camera Introduction
Camera Introduction Antenna Built-in PIR Sensor Working LED Charging LED Spotlight Lens Microphone Reset Key Power Key SD Card Clot Nano SIM Clot Charging Port Speaker Press and hold the power button for 5 seconds to turn on the Power Key camera Press and hold RESET for 5 seconds to reset the device (if you have modified the settings, they will revert to the factory default... - Page 5 Thumb Screw For fixing the camera and the bottom bracket Antenna 4G dedicated signal antenna Download and Register APP l.Download "ZUMIMALL" Search "zun "in App Store or Google Play, or scan the QR code below to download and install it on your smartphone.
- Page 6 When using the application for the first time, please turn on the following 2 permissions. Allow ■ " to access mobile cellular data and WLAN, otherwise you ZUMIMALL will not be able to add devices. Allow" " to receive messages, otherwise the phone will not receive ZUMIMALL alert push notifications when motion detection or audible alerts are triggered.
- Page 7 ： O Please use the correct e-maiL Q Please select the correct country code. ❸ When registering for a new account, please select the region where you are actually located. (Cameras cannot be shared between different registration regions.) Choice SIM card l.A SIM card is included in the camera box, and this card supports the major carrier networks in your country.
-
Page 8: Insert The Sim Card
Note: • The camera does not guarantee the compatibility of the SIM cards of carriers other than those listed in the above list, please choose carefully. The camera only uses data traffic and will not use services such as calls/texts. •... - Page 9 Add the Camera On the Phone Stepl: Move the camera and smartphone to a location with a good mobile network signal, and make sure there are no signal interferes around. Run the" ZUMIMALL" application, click and select "4G Camera". Step2: Step3: Follow the prompts to ensure that that the camera has been inserted into the SIM card and turned on (the indicator light turns blue and flashes).
- Page 10 Step5: After you click "Hear the sound", the camera will start connecting to smartphone. Once the connection is complete, the app will jump to the "Device Found!" page where you can edit the camera name, and then click "Done". Please read the installation instructions of the camera carefully. When installing the camera later, it can help you avoid some wrong operations.
-
Page 11: Apn Settings
1. Please check whether the SIM card has a PIN code, insert the SIM card into the mobile phone and disable the PIN (do not insert the camera's own SIM card into the mobile phone). 2. Check whether your SIM card has been activated, if not, please contact Red and blue SIM card cannot be... -
Page 12: Charge The Camera
• Just enter the corresponding information in the first three columns "MCC ； "MNC" and "APN". If you do not know the APN information of the SIM card, please consult the card operator for assistance. Or insert the SIM card into the smart phone and obtain APN information in the phone system After successfully... -
Page 13: Install The Camera
Note: _______For better weather resistance, insert the charging port of the solar panel into the rubber plug, and the rubber plug fully covers the charging port. Safety Reminder: Do not use a non-5V power adapter to charge the camera, and do not charge near fire and heaters. If the battery emits odor, heat, deformation and other abnormal conditions during the charging process, please stop charging or use it immediately. - Page 14 Note: As shown in the picture, the red dotted line is the usual intrusion path of the intruder, then point A is the best installation location for the camera, if it is installed at point B, it may cause a missed alarm. •...
- Page 15 Note: In order to obtain the best charging efficiency, the solar panel must be installed in a location with sufficient sunlight (it is recommended that there be no light shielding around), and the daily light time can be guaranteed to be more than 4 hours.
