- Page 1 Electric Bicycle User Manual Before The First Cycling, Please Read This Manual For Security! TOP-017 Shenzhen Xinhuanan Bicycle Industry Co.,Ltd...
-
Page 2: Table Of Contents
Electric Bicycle User Manual Model: TOP-017 Content Warning Safety Precautions Electric Bicycle Parts Introduction Wheel Installation Handlebar Installation Front Light Installation Saddle Installation Pedal Installation Plug-in Battery Disassembly and Charge Mode (direct charge) 11-12 Control operation instructions 13-14 LCD Display Monitor Description Error Demonstration... - Page 3 Electric Bicycle User Manual Inspection Before Riding Warning! Inspection before riding should be carried out. 1. Saddle seat post (Whether it does not cross the limit line or is locked tight). 2. Bell (Does it ring well). 3. Handle bar or Stem (Is it not over the limit line, Is it locked tightly). 4.
- Page 4 Electric Bicycle User Manual Safety Precautions 1.Wear earphone while cycling is not permitted in road traffic act. 2. Avoid the clothes too long to be caught by wheels and belts. 3. Do not release the steering wheel except the signal shows. 4.
- Page 5 Electric Bicycle User Manual Electric Bicycle Parts Introduction LCD display Grip Brake-Rake material: rubber. (It does not include asbestos.) Fork Front light Aluminum alloy rim Saddle Tire Budelice Ski Material Battery Burefoot: Pure Steak (Not including asbestos) Motor Free wheel Chain Pedal Disc Brake...
- Page 6 Electric Bicycle User Manual Wheel Installation Install the quick release part in turn to the Pay attention to the direction of the disc brake front wheel. when installing the front wheel as shown. Loosen the nut and put the front wheel in the Pay attention to the direction of the pring middle of the fork.
- Page 7 Electric Bicycle User Manual Handlebar Installation Remove the screws and black cap with tools. Remove the screw at the handlebar and insert the lever as shown. Make sure the handlebar is at the bottom of the Reset and tighten the screws and black cap and lever and tighten the removed screws with tools.
- Page 8 Electric Bicycle User Manual Front Light Installation Remove the screws on the bike body. Fix the front light to the screws as shown. Tighten the screws. The front light is assembled.
- Page 9 Electric Bicycle User Manual Saddle Open the seat post clamp quickly and place it in the seat tube. Adjust the mat to a suitable height and snap seat post clamp until it does not shake.
- Page 10 Electric Bicycle User Manual Pedal Installation The pedal may tilt and slide during installation but it cannot be tried hard. It is necessary to find the correct position and the installation can be done easily. For pedal installation, please rotate and tighten Before installation, you should pay attention to with a tool.
-
Page 11: Plug-In Battery Disassembly And Charge Mode (Direct Charge)
Electric Bicycle User Manual Plug-in battery disassembly and charge mode (direct charge). Find the charging hole on the right side of the body and insert the charging cable. When plug in the power, red indicator shows the start of charging. Green light indicates that charging is completed. -
Page 12: Control Operation Instructions
Electric Bicycle User Manual Control operation instructions Open the keyhole as shown with the key, unscrew the battery lock and then remove the battery. When plug in the power, red indicator shows the start of charging. Green light indicates that charging is completed. - Page 13 Electric Bicycle User Manual Control operation instructions 4.LCD display 1.Grip 5.LCD Monitor Control settings 2.Light/Horn Button 6.Rear shifter 3.Mobile Holder PAS level up Speed ON/OFF PAS level minus Trip Battery...
- Page 14 Electric Bicycle User Manual LCD Display Monitor Description Screen Display ODO/TRIP/TIME Speed ODO（Odometer/ Trip /Time switch by the function key Battery Indicator SOC(State of Charge) Display 0-7file display speed PAS...
- Page 15 Electric Bicycle User Manual Operating instructions Operating Mode： 1x briefly Function： ODO/TRIP/TIME After you turn on the system, once again Click to switch. Operating Mode： 1x Long Function： Power On Operating Mode：1x Long Function：OFF Single click to turn on the system,all the contents show one time.
-
Page 16: Error Demonstration
Electric Bicycle User Manual Error Demonstration Can not be charged. Solution: Please contact us if you can not charge after seriously inspecting the power connection etc. Charger can be changed. Tap hole is defective. Note: Inspect it seriously before shipping, when aligning, align it to the tapped hole and tighten the screw. -
Page 17: Maintenance
Electric Bicycle User Manual Maintenance It should be regularly maintained and checked. Especially the transmission, three brake systems and shafts,regular maintain and check are important. 1. Operating System : Some parts need to be lubricated. (1) Brake rod (front and rear) wire movement part [brake material: refined steel (without asbestos)] (2) Chain (3) Wire loop section (4) Movable parts of rear derailleur (rear derailleur) and front derailleur (front derailleur) -
Page 18: Specifications
Electric Bicycle User Manual Specifications Body frame material: 6061 aluminum alloy Display: LCD display Motor: 48V*1000W super large power motor for snowmobile Battery: 48V*10AH lithium battery Controller: 48V for high power snowmobile Controller speed: 45-50km/h Range: 31 km Net weight: 31.2 kg Gross weight: 38.8 kg Box size: 150*34*84cm... -
Page 19: After-Sale Service
Electric Bicycle User Manual After-sale Service About assembly 85% of bicycles manufactured by RICHBIT are assembled, but some parts must be assembled by the buyer, such as pedal, saddle, front wheel, etc. For safety, please check and test everything before riding. After inspection and adjustment, If there is any abnormality, please contact your seller. - Page 20 Shenzhen Xinhuanan Bicycle Industry Co.,Ltd Tel : Fax : Email: 0755-81736468 0755-81736451 info@richbitebike.com Address: 1-336,xiangshang Rd, 3th Luotian Industry Zone, Songgang Town, Bao'an Dist, Shenzhen, China...
