Electric Bicycle
User Manual
Before The First Cycling,
Please Read This Manual For Security!
Shenzhen Xinhuanan Bicycle Industry Co.,Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOP-016 and is the answer not in the manual?

Questions and answers

Related Manuals for Rich Bit TOP-016

Summary of Contents for Rich Bit TOP-016

  • Page 1 Electric Bicycle User Manual Before The First Cycling, Please Read This Manual For Security! Shenzhen Xinhuanan Bicycle Industry Co.,Ltd...

  • Page 2: Table Of Contents

    Electric Bicycle User Manual Model: TOP-016 Content Warning Safety Precautions Electric Bicycle Components Handlebar Installation Wheel Installation Pedal Installation Saddle Installation Plug-in Battery Disassembly and Charge Mode (direct charge) Plug-in Battery Disassembly and Charge Mode (seating charge) Control operation instructions...

  • Page 3: Warning

    Electric Bicycle User Manual Inspection Before Riding Warning! Inspection before riding should be carried out. 1. Saddle seat post (whether it does not cross the limit line or is locked tight). 2. Bell (Does it ring well?) 3. Handle bar or Stem (Is it not over the limit line, is it locked tightly?) 4.

  • Page 4: Safety Precautions

    Electric Bicycle User Manual Safety Precautions 1. Do not carry person on the back carrier. 2. Avoid the clothes too long to be caught by wheels abd belts. 3. Do not release the steering wheel except the signal. 4. Avoid clothes that are easily caught by wheels and belts. 5.
  • Page 5 Electric Bicycle User Manual Electric Bicycle Parts Introduction LCD display Right indicator light Left indicator light Grip Brake lever-material: alloy aluminum (It does not include asbestos.) Fork Front light Alloy Aluminum rim Saddle Battery Tire Brake Caliper (Not including asbestos) Motor Rear Derailleur Chain...

  • Page 6: Handlebar Installation

    Electric Bicycle User Manual Handlebar Installation Lift the handlebar from below to the figure (2). Fold the folding handle to the buckle and lock the buckle(3). Remove quick release of the tube cover and open the cover. Place the handlebars in the slots, align them with the middle, close the cover and fasten the handlebars.
  • Page 7 Electric Bicycle User Manual Tyre Installation Install the quick release parts in turn to the Loosen the nut and put the front wheel in the front wheel. middle of the fork. Slightly minor force launching, quitting fast For your safety, please check regularly to see if speed leisurely fitting, fitting before wheelchair, the quick release is loosen, install the wrench in finished inexpensive hard rocking, jumping one...
  • Page 8 Electric Bicycle User Manual Saddle Installation Open the clamp and place the seat post. Adjust the mat to a suitable height and snap the seat post clamp until it does not shake.

  • Page 9: Pedal Installation

    Electric Bicycle User Manual Pedal Installation The pedal may tilt and slide during installation but it cannot be tried hard. It is necessary to find the correct position and the installation can be done easily. Before installation, you should observe For pedal installation, please rotate and tighten positions of the pedal (the bottom shows the with a tool.

  • Page 10: Plug-In Battery Disassembly And Charge Mode (Direct Charge)

    Electric Bicycle User Manual Plug-in battery disassembly and charge mode (direct charge). Open the jack protector and insert the jack directly into the hole. When plug in the power, red indicator shows the start of charging. Green light indicates that charging is completed.

  • Page 11: Plug-In Battery Disassembly And Charge Mode (Seating Charge)

    Electric Bicycle User Manual Plug-in battery disassembly and charge mode (seating charge). Under the ebike frame, there is one hole, you need use the another key to open it, and loose the pack to fold the ebike frame. Pull the battery out and fold the ebike. Pull the battery outside, at the right side of the battery, one hole for the charge.

  • Page 12: Control Operation Instructions

    Electric Bicycle User Manual Control operation instructions LCD display Grip Brake lever Rear shifter Light/Horn Button Turn on/off light Speed PAS level up PAS level down Mileage Turn on/off LCD Power ON/OFF Trip Turning light Battery Klaxon on/off...
  • Page 13 Electric Bicycle User Manual Error Demonstration 1. Can not be charged. Solution: Please contact us if you can not charge after seriously inspecting the power connection etc. Charger can be changed. 2. Tap hole is defective Note: Inspect it seriously before shipping, when aligning, align it to the tapped hole and tighten the screw.

  • Page 14: Maintenance

    Electric Bicycle User Manual Maintenance It should be regularly maintained and checked. The emphasis on the transmission, three brake systems and shafts are important. Operating System: Some parts need to be lubricated. (1) Brake rod (front and rear) wire movement part [brake material: refined steel (without asbestos)] (2) Chain (3) Wire loop section (4) Movable parts of rear derailleur (rear derailleur) and front derailleur (front derailleur)

  • Page 15: After Sale Service

    Electric Bicycle User Manual After-sale Service About assembly 85% of bicycles manufactured by RICHBIT are assembled, but some parts must be assembled by other buyer, such as pedal, saddle, front wheel, etc. For safe driving,please check and test everything before departure.
  • Page 16 Electric Bicycle User Manual...
  • Page 17 Electric Bicycle User Manual...
  • Page 18 Shenzhen Xinhuanan Bicycle Industry Co.,Ltd Tel : Fax : Email: 0755-81736468 0755-81736451 info@richbitebike.com Address: 1-336,xiangshang Rd, 3th Luotian Industry Zone, Songgang Town, Bao'an Dist, Shenzhen, China...
