Page 1
Quick Start Manual FOR TECHNICAL SUPPORT, PLEASE CALL 1-800-SAMSUNG (726-7864) POR FAVOR LLAMAR 1-800-SAMSUNG (726-7864) PARA ASISTENCIA TECNICA For more information, refer to the User Manual included on the supplied CD-ROM. SL102 This Quick Start Manual has been specially designed to guide you through the basic functions and features of your device.
Contents Health and safety information…………………… 2 Camera layout ……………… 4 Setting up your camera …… 5 Unpacking ……………………… 5 Inserting the battery and memory card …………………… 6 Charging the battery …………… 6 Turning on your camera ………… 7 Selecting options ……………… 7 Capturing photos or videos Playing files …………………...
Page 3
Handle and dispose of batteries and chargers with care • Use only Samsung-approved batteries and chargers. Incompatible batteries and chargers can cause serious injuries or damage to your camera. • Never place batteries or cameras on or in heating devices, such as microwave ovens, stoves, or radiators.
Setting up your camera Unpacking Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the optional equipment, contact your nearest Samsung dealer or Samsung service centre. Camera Rechargeable Battery...
Setting up your camera Inserting the battery and memory card With the gold- coloured contacts facing up With the Samsung logo facing up Removing the battery Removing the memroy card ▼ ▼ Push gently until the card disengages from the camera and then pull it out of the slot.
Turning on your camera Press [ POWER]. ▪ The intial setup screen appears. Press [ ] to select Language and press [ ]. Press [ ] or [ ] to select a language and press [ Press [ ] or [ ] to select Date & Time and press [ ].
3648 x 2432 3648 x 2052 2592 x 1944 2592 x 1944 2048 x 1536 1024 x 768 1,238 1,673 These figures are measured under Samsung’s standard conditions and may vary depending on shooting conditions and camera settings. Normal 1,067 1,876...
Playing files Viewing photos Press [ Press [ ] or [ ] to scroll through files. ▪ Press and hold to view files quickly. Viewing videos Press Press [ Play Capture Use the following buttons to control playback. Scan backward Pause or resume playback Scan forward...
Transferring files to a PC (Windows) Insert the installation CD in a CD-ROM drive and follow the onscreen instructions. Connect the camera to the PC with the USB cable. Turn on the camera. My Computer → On your PC, select Removable Disk →...
Effective pixels: approx. 10.2 mega-pixels • Total pixels: approx. 10.3 mega-pixels • Focal length: Samsung lens f = 6.3 - 18.9 mm (35 mm film equivalent: 35 - 105 mm) Lens • F-stop range: F3.2 (W) - F5.8 (T) 2.5” (6.4 cm) 230 K, TFT LCD...
Page 12
Contenido Información sobre salud y seguridad …………………… 2 Diseño de la cámara ……… 4 Configuración de la cámara 5 Desembalaje …………………… 5 Insertar la batería y la tarjeta de memoria ………………………… 6 Cargar la batería ……………… 6 Encender la cámara …………… 7 Selección de opciones …………...
Page 13
Utilice y deseche las baterías y los cargadores con cuidado • Utilice únicamente baterías y cargadores aprobados por Samsung. Las baterías y los cargadores incompatibles pueden producirle graves lesiones o causar daños a la cámara. • Nunca coloque las baterías o las cámaras dentro de dispositivos conductores de calor, como hornos de microondas, estufas o radiadores, ni sobre ellos.
Diseño de la cámara Botón del obturador Botón de encendido y apagado Luz AF auxiliary/luz de temporizador Objetivo / Tapa del objetivo Altavoz Orificio para el montaje del trípode Cubierta de la cámara de la batería Flash Micrófono ES-4 ES-4 Luz indicadora de estado Botón Tele(T) de zoom (Zoom digital) Botón Wide(W) de zoom (Miniatura)
Revise que estén todos los componentes antes de usar este producto. El contenido puede variar en función de la zona de venta. Para comprar equipos opcionales, diríjase al distribuidor de Samsung o al centro de servicio de Samsung más cercano.
Configuración de la cámara Insertar la batería y la tarjeta de memoria Con los contactos de color dorado hacia arriba Con el logotipo de Samsung hacia arriba. Quitar la batería Quitar la tarjeta de memoria ▼ ▼ Ejerza una leve presión hasta que la tarjeta se desprenda de la cámara y,...
Encender la cámara Pulse [ POWER]. ▪ Aparecerá la ventana de configuración inicial. Pulse [ ] para seleccionar Language y pulse [ ]. Pulse [ ] o [ ] para seleccionar un idioma y pulse [ Pulse [ ] o [ ] para seleccionar Date & Time y pulse [ ].
2592 x 1944 2592 x 1944 2048 x 1536 1024 x 768 Estas son medidas tomadas en condiciones estándar, establecidas por Samsung, y pueden variar según las condiciones de disparo y la configuración de la cámara. (para SD de 1GB) Superfina Fina...
Reproducción de archivos Ver fotografías Pulse [ Pulse [ ] o [ ] para desplazarse por los archivos. ▪ Mantenga la tecla pulsada para ver los archivos rápidamente. Ver vídeos Pulse [ Pulse [ Reproducir Captura Utilice los siguientes botones para controlar la reproducción.
Transferencia de archivos a un ordenador (para Windows) Inserte el CD de instalación en la unidad de CD-ROM y siga las instrucciones que aparezcan en la pantalla. Conecte la cámara a su PC con el cable USB. Encienda la cámara. En el ordenador, seleccione Mi PC →...
Sensor de imagen • Píxeles totales: aproximadamente 10,3 megapíxeles • Distancia focal: Lente Samsung f = 6,3-18,9 mm (equivalente en película de 35 mm: de 35 a 105 mm) Lente • Rango de apertura del objetivo: F3,2 (W) y F5,8 (T) 2,5"...
Page 24
Please refer to the warranty that came with your product or visit our website http://www.samsung.com for after- sales service or inquiries. AD68-03920A (1.0)
