Summary of Contents for HDC LEA 202

  • Page 1 NOTICE D’UTILISATION INSTRUCTION OF USE MANUALE D’ISTRUZIONE LEA 202...
  • Page 2: Table Of Contents

    Chère cliente, cher client, Nous vous remercions de la confiance que vous nous avez accordée en choisissant notre table de cuisson vitrocéramique. Afin de bien connaître cet appareil, nous vous recommandons de lire attentivement cette notice d’utilisation dans son intégralité et de la conserver pour une consultation ultérieure. SOMMAIRE SECURITE ...........................
  • Page 3: Securite

    SECURITE Précautions avant utilisation en cuisson  Retirez toutes les parties de l’emballage.  L’installation et le branchement électrique de l’appareil sont à confier à des spécialistes agrées. Le fabricant ne saurait être tenu responsable des dommages résultant d’une erreur d’encastrement ou de raccordement.
  • Page 4: Precautions Pour Ne Pas Deteriorer Lappareil

     Les objets magnétisables (cartes de crédits, disquettes informatiques, calculatrices) ne doivent pas se trouver à proximité immédiate de l’appareil en fonction.  Ne placez aucun objet métallique autre que les récipients de chauffe. En cas d’enclenchement intempestif ou de chaleur résiduelle, celui-ci risquerait selon le matériau de chauffer, de fondre ou de commencer à...
  • Page 5: Precautions En Cas De Defaillance De Lappareil

     Eviter que le sucre, les matières synthétiques ou une feuille d’aluminium ne touchent les zones chaudes. Ces substances peuvent au refroidissement provoquer des cassures ou d’autres modifications de la surface vitrocéramique: Eteindre l’appareil et enlevez-les immédiatement de la zone de cuisson encore chaude (attention : risque de brûlures).
  • Page 6: Autres Protections

    Autres protections  Assurez-vous que le récipient de cuisson soit toujours centré sur la zone de cuisson. Le fond de la casserole doit autant que possible couvrir la zone de cuisson.  Pour les utilisateurs portant un régulateur de rythme cardiaque, le champ magnétique pourrait influencer son fonctionnement.
  • Page 7: Description De L'appareil

    DESCRIPTION DE L’APPAREIL Caractéristiques techniques Type LEA202 Puissance Totale 3000 W Consommation d’énergie de la table de cuisson EC 178.9 Wh/kg Foyer avant Ø 190 mm Puissance nominale 1800 W Catégorie de la casserole standard* Consommation d’énergie EC 183.9 Wh/kg Foyer arrière Ø...
  • Page 8: Mise En Route Et Gestion De L'appareil

    MISE EN ROUTE ET GESTION DE L’APPAREIL Avant la première utilisation Nettoyez votre appareil avec un chiffon humide, puis séchez le. N’utilisez pas de détergent qui risquerait de provoquer une coloration bleutée sur les surfaces vitrées. Mise en route Vous devez d’abord enclencher la table de cuisson, puis la zone de chauffe : ...
  • Page 9: Conseils De Cuisson

    CONSEILS DE CUISSON Exemples de réglage des puissances de cuisson (Les valeurs ci-dessous sont indicatives) 1 à 2 Faire fondre Sauces, beurre, chocolat, gélatine Réchauffer Plats pré-cuisinés 2 à 3 Gonfler Riz, pudding et plats cuisinés Décongélation Légumes, poisson, produits congelés 3 à...
  • Page 10: Que Faire En Cas De Probleme

    QUE FAIRE EN CAS DE PROBLEME La table de cuisson ou les zones de cuisson ne s’enclenchent pas :  La table est mal connectée au réseau électrique  Le fusible de protection a sauté  Les touches sensitives sont couvertes d’eau ou de graisse ...
  • Page 11: Instructions D'installation

     Découpe du plan de travail : Appareil Dimension de découpe LEA 202 490 x 280 mm  La distance entre la table de cuisson et le mur doit être au minimum de 50mm.  La table de cuisson est un appareil qui appartient à la classe de protection « Y ». Lors de son encastrement, une paroi d’armoire haute ou un mur peut se trouver sur l’un des...
  • Page 12: Connexion Electrique

    CONNEXION ELECTRIQUE  L’installation de cet appareil et son branchement au réseau électrique ne doit être confiés qu’à un électricien parfaitement au fait des prescriptions normatives.  La protection contre les pièces sous tension doit être assurée après le montage. ...
  • Page 13 Dear customers, Thank you for having chosen our ceramic hob. In order to make the best use of your appliance, we would advise you to read carefully the following notes and to keep them for later consulting. SUMMARY SAFETY ............................. 15 ....................
  • Page 14: Safety

    SAFETY Precautions before using  Unpack all the materials.  The installation and connecting of the appliance have to be done by approved specialists. The manufacturer cannot be responsible for damage caused by installation or connecting errors.  To be used, the appliance must be well-equipped and installed in a kitchen unit and an adapted and approved work surface.
  • Page 15: Precautions Not To Damage The Appliance

     In general do not place any metallic object except heating containers on the glass surface. In case of untimely engaging or residual heat, this one may heat, melt or even burn.  Never cover the appliance with a cloth or a protection sheet. This is supposed to become very hot and catch fire ...
  • Page 16: Precautions In Case Of Appliance Failure

     Never put any inflammable object (ex. sprays) into the drawer situated under the vitroceramic hob. All cutlery drawers must be resistant to heat. Precautions in case of appliance failure  If a defect is noticed, switch off the appliance and turn off at the main electrical supplying.
  • Page 17: Description Of The Appliance

    DESCRIPTION OF THE APPLIANCE Technical data Type LEA202 Total power 3000 W Energy consumption for the hob EC 178.9 Wh/kg Front heating zone Ø 190 mm Nominal power 1800 W Standardised cookware category* Energy consumption EC 183.9 Wh/kg Rear heating zone Ø...
  • Page 18: Starting Up The Appliance

    STARTING UP THE APPLIANCE Before using your new hob Clean your hob with a damp cloth, and then dry the surface thoroughly. Do not use detergent which risks causing blue-tinted colour on the glass surface. Starting-up  Start-up/ switch off the hob Action Control panel Display...
  • Page 19: Cooking Advices

    COOKING ADVICES Examples of power setting (The values below are indicative) Sauces, butter, chocolate, gelatine 1 to 2 Melting, Reheating Dishes prepared beforehand Rice, pudding, sugar syrup 2 to 3 Simmering, Defrosting Dried vegetables, fish, frozen products 3 to 4 Steam Vegetables, fish, meat 4 to 5...
  • Page 20: What To Do In Case Of A Problem

    WHAT TO DO IN CASE OF A PROBLEM The hob or the cooking zone doesn’t start-up:  The hob is badly connected to the electrical system.  The protection fuse has blown.  The sensitive keys are covered bygrease or water. ...
  • Page 21: Installation Instructions

     The dimensions are: Reference Cut-size LEA 202 490 x 280 mm  Ensure that there is a distance of 50 mm between the hob and the wall or sides.  The hobs are classified as “Y” class for heat protection. Ideally the hob should be installed with plenty of space on either side.
  • Page 22: Electrical Connection

    ELECTRICAL CONNECTION  The installation of this appliance and the connection to the electrical network should be entrusted only to an electrician perfectly to the fact of the normative regulations and which respects them scrupulously.  Protection against the parts under tension must be ensured after the building-in. ...
  • Page 23 Gentile Cliente, Grazie per avere scelto il nostro piano di cottura. Per ottenere il meglio dal Suo piano cottura, La preghiamo di leggere con attenzione le presenti istruzioni, e di conservarle per un’eventuale consultazione futura INDICE SICUREZZA ..........................25 ................... 25 RECAUZIONI PRIMA DEL PRIMO UTILIZZO ......................
  • Page 24: Sicurezza

    SICUREZZA Precauzioni prima del primo utilizzo  Sballare eliminando tutti i materiali di imballo.  L’installazione e connessione dell’apparecchio devono essere effettuate da personale specializzato. Il Fabbricante declina ogni responsabilità civile e penale per danni causati da installazione e/o connessione non realizzate a regola d’arte. ...
  • Page 25: Istruzioni Di Sicurezza

    Istruzioni di sicurezza  La parte elettronica (relais) può provocare durante l‘esercizio rumori udibili di attivazione. Può essere percepibile anche la ventola di raffreddamento. La ventola di raffreddamento può continuare a girare anche dopo la fine del processo di cottura per raffreddare i componenti elettronici.
  • Page 26: Precauzioni Onde Non Danneggiare L

    Precauzioni onde non danneggiare l’apparecchio  Pentole con fondo graffiato o danneggiato possono danneggiare il vetro ceramico. Le pentole potrebbero graffiare la superficie in vetroceramica.  Sabbia o altre sostanze abrasive possono danneggiare il vetro ceramico.  Il vetro ceramico non è sensibile agli shock termici ed è molto resistente, non è...
  • Page 27: Recauzioni In Caso Di Malfunzionamento Dell Apparecchio

    Precauzioni in caso di malfunzionamento dell’apparecchio  Se si nota un difetto di funzionamento, spegnere l’apparecchio e disconnetterlo dalla rete elettrica.  vetro ceramico è rotto crepato: disconnettere immediatamente l’apparecchio dalla rete elettrica, svitando e rimuovendo il fusibile e chiamare l’assistenza tecnica. ...
  • Page 28: Escrizione Dell'apparecchio

    ESCRIZIONE DELL’APPARECCHIO Dati tecnici Typo LEA202 Potenza totale 3000 W Consumo di energia del piano cottura EChob* 178.9 Wh/kg Posizione anteriore Ø 190 mm Potenza nominale 1800 W Categoria standard di pentola * Consumo di energia ECcw* 183.9 Wh/kg Posizione posteriore Ø...
  • Page 29: Prima Accensione E Utilizzo Dell'apparecchio

    PRIMA ACCENSIONE E UTILIZZO DELL’APPARECCHIO Prima del primo utilizzo Pulire l’apparecchio con uno straccio umido, indi asciugarlo accuratamente. Non utilizzare detergenti che possano causare colorazioni anomale del vetro. Per iniziare  Accensione/spegnimento dell’apparecchio: Azione Pannello di controllo Display Per accendere premere [ 2 x [ 0 ] Per arrestare...
  • Page 30: Suggerimenti Di Cottura

    SUGGERIMENTI DI COTTURA Esempi di regolazione della potenza (I valori sotto sono indicativi) Da 1 a 2 Sciogliere Salse, burro, cioccolata, gelatine Riscaldare Piatti preparati in precedenza Da 2 a 3 Cuocere a fuoco lento Riso, budini, sciroppi di zucchero Scongelare Verdure liofilizzate, pesce, prodotti congelati...
  • Page 31: Cosa Fare In Caso Di Problemi

    COSA FARE IN CASO DI PROBLEMI L’apparecchio non si accende  L’apparecchio non è collegato correttamente alla rete elettrica.  Il fusibile è assente o il circuito aperto  I tasti a sfioramento sono coperti da grasso o acqua.  Un oggetto è posizionato su uno dei tasti. Compare il simbolo [ E ] ...
  • Page 32: Istruzioni Di Installazione

    Inserimento – installazione  Le misure di incasso sono: Tipo Foro incasso LEA 202 490 x 280 mm  Assicurarsi che ci sia una distanza di almeno 50 mm tra l’apparecchio e il muro o le pareti o paratie laterali.
  • Page 33: Connessione Elettrica

    CONNESSIONE ELETTRICA  L’installazione di questo apparecchio e la connessione alla rete elettrica devono essere affidate esclusivamente a personale qualificato e autorizzato, nel rispetto della normativa in vigore.  Dopo l’installazione, una adeguata protezione delle parti sotto tensione deve essere garantita. ...
  • Page 34 22389-0...
