EP A II
EP A I
Please read the oper ator's manual carefully and
Oper ator's manual
make sure you understand the instructions
before using the machine.
CS 2152 CS 2153

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS 2152 EPA II and is the answer not in the manual?

Questions and answers

Related Manuals for Jonsered CS 2152 EPA II

Summary of Contents for Jonsered CS 2152 EPA II

  • Page 1 EP A II EP A I Please read the oper ator’s manual carefully and Oper ator’s manual make sure you understand the instructions before using the machine. CS 2152 CS 2153...

  • Page 2: Key To Symbols

    KEY T O SYMBOLS Symbols on the mac hine: Refuelling. W ARNING! Chain saws can be dangerous! Careless or improper use can result in serious or fatal injury to the operator or others. Filing with oil and adjusting oil flow. Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.

  • Page 3: Table Of Contents

    CONTENTS Contents KEY TO SYMBOLS Symbols on the machine: ..........2 Symbols in the operator’s manual: ........ 2 CONTENTS Contents ............... 3 INTR ODUCTION Dear customer! ............. 4 WHA T IS WHAT? What is what on the chain sa w? ........5 GENERAL SAFETY PRECA UTIONS Bef ore using a new chain saw ........

  • Page 4: Intr Oduction

    Good luck on using your Jonsered machine! Jonsered has a policy of continuous product development and therefore reserves the right to modify the design and appearance of products without prior notice.

  • Page 5: Wha T Is What

    WHA T IS WHA T? What is what on the chain saw? 1 Cylinder cover 16 Bumper spike 2 Front handle (Felling direction guide) 17 Chain catcher 3 Front hand guard 18 Clutch cover 4 Starter 19 Rear handle with right hand guard 5 Chain oil tank 20 Throttle control 6 Starter handle...

  • Page 6: General Safety Preca Utions

    GENERAL SAFETY PRECA UTIONS Bef ore using a new chain saw Impor tant • Please read this manual carefully. IMPOR TANT! • Check that the cutting equipment is correctly fitted and adjusted. See instructions under the heading Assembly. The machine is only designed for cutting wood. •...

  • Page 7: Personal Protective Equipment

    GENERAL SAFETY PRECA UTIONS chain sa w usage if possible. Your dealer, forestry school or Generally clothes should be close-fitting without restricting your library can provide information about which training your freedom of movement. materials and courses are available. IMPOR TANT! Sparks can come from the muffler, the bar and chain or other sources.
  • Page 8 GENERAL SAFETY PRECA UTIONS • The brake is applied when the front hand guard (B) is • To release the chain brake pull the front hand guard pushed forwards. backwards, towards the front handle. • This movement activates a spring-loaded mechanism that tightens the brake band (C) around the engine drive •...
  • Page 9 GENERAL SAFETY PRECA UTIONS Will my hand always activate the chain Chain catcher brake during a kickback? The chain catcher is designed to catch the chain if it snaps or jumps off. This should not happen if the chain is properly No.

  • Page 10: Cutting Equipment

    GENERAL SAFETY PRECAUTIONS Cutting hardwoods (most broadleaf trees) creates more WARNING! Never use a saw without a vibration than cutting softwoods (most conifers). Cutting with muffler, or with a damaged muffler. A cutting equipment that is blunt or faulty (wrong type or badly damaged muffler may substantially increase sharpened) will increase the vibration level.
  • Page 11 To maintain the safety features of the cutting equipment, you should replace a worn or damaged bar or chain with a bar and chain combinations recommended by Jonsered. See instructions under the heading Technical Data for a list of replacement bar and chain combinations we recommend.
  • Page 12 GENERAL SAFETY PRECAUTIONS • The cutting part of the chain is called the cutter and Sharpening cutting teeth consists of a cutting tooth (A) and the depth gauge (B). The cutters cutting depth is determined by the difference in height between the two (depth gauge setting). To sharpen cutting teeth you will need a round file and a file gauge.
  • Page 13 GENERAL SAFETY PRECAUTIONS Adjustment of depth gauge setting • Loosen the bar nuts that hold the clutch cover/chain brake. Use the combination spanner. Then tighten the bar nuts by hand as tight as you can. • The cutting teeth should be newly sharpened before adjusting the depth gauge setting.
  • Page 14 GENERAL SAFETY PRECAUTIONS Filling with chain oil • Check that the bar tip sprocket turns freely and that the lubricating hole in the tip sprocket is not blocked. Clean • All our chain saws have an automatic chain lubrication and lubricate if necessary. system.
  • Page 15 GENERAL SAFETY PRECAUTIONS Check regularly: • Whether there are burrs on the edges of the bar. Remove these with a file if necessary. • Whether the groove in the bar has become badly worn. Replace the bar if necessary. • Whether the tip of the bar is uneven or badly worn.

  • Page 16: Assembly

    ASSEMBLY Fitting the bar and chain Tension the chain by turning the chain tensioning screw clockwise using the combination spanner. The chain should be tensioned until it does not sag from the underside of the bar. WARNING! Always wear gloves, when working with the chain, in order to protect your hands from injury.

  • Page 17: Fuel Handling

    Then add the entire amount of oil. Mix (shake) the Environment fuel fuel mixture. Add the remaining amount of gasoline. JONSERED recommends the use of alkylate fuel or • Mix (shake) the fuel mixture thoroughly before filling the environment fuel for four-stroke engines blended with two- machine’s fuel tank.

  • Page 18: Fueling

    FUEL HANDLING Fueling • Never start the machine: 1 If you have spilled fuel or chain oil on the machine. Wipe off the spillage and allow remaining fuel to evaporate. 2 If you have spilled fuel on yourself or your clothes, change your clothes.

  • Page 19: Starting And Stopping

    STARTING AND STOPPING Starting and stopping Warm engine Use the same procedure as for starting a cold engine but without setting the choke control in the choke position. The WARNING! Note the following before correct choke/start throttle setting is obtained by moving the starting: choke control to the choke position and then pushing it in again.
  • Page 20 STARTING AND STOPPING Note! Pull the front hand guard towards the front handle. The • Always hold the saw with both hands. The right hand chain brake is now disengaged. Your saw is ready for use. should be on the rear handle, and the left hand on the front handle.

  • Page 21: Working Techniques

    WORKING TECHNIQUES Before use: Basic safety rules 1 Look around you: • To ensure that people, animals or other things cannot affect your control of the machine. • To make sure that none of the above might come within reach of your saw or be injured by falling trees. 1 Check that the chain brake works correctly and is not damaged.
  • Page 22 WORKING TECHNIQUES be a danger, you may be surprised and lose control of the saw. Never saw stacked logs or branches without first separating them. Only saw one log or one piece at a time. Remove the cut pieces to keep your working area safe. 6 Before moving your chain saw switch off the engine and lock the chain using the chain brake.
  • Page 23 WORKING TECHNIQUES 8 Unless the user resists this pushing force there is a risk There are five important factors you should that the chain saw will move so far backwards that only the consider before making a cut: kickback zone of the bar is in contact with the tree, which 1 Make sure the cutting equipment will not jam in the cut.
  • Page 24 WORKING TECHNIQUES Cutting The log is supported at one end. There is a high risk that it will split. WARNING! Never attempt to cut logs while they are in a pile or when a couple of logs are lying together. Such procedures drastically increase the risk of kickback which can result in a serious or fatal injury.
  • Page 25 WORKING TECHNIQUES Felling direction Clearing the trunk and preparing your retreat The aim is to fell the tree in a position where you can limb and Delimb the stem up to shoulder height. It is safer to work from cross-cut the log as easily as possible. You want it to fall in a the top down and to have the tree between you and the saw.
  • Page 26 WORKING TECHNIQUES The directional cuts should run 1/4 of the diameter through All control over the felling direction is lost if the felling hinge is the trunk and the angle between the top cut and bottom cut too narrow or non-existent, or if the directional cuts and felling should be 45°.
  • Page 27 WORKING TECHNIQUES Freeing a tree that has fallen badly General advice: Position yourself so that you will be clear of the tree or branch Freeing a ”trapped tree” when the tension is released. It is very dangerous to remove a trapped tree and there is high accident risk.

  • Page 28: How To Avoid Kickback

    WORKING TECHNIQUES How to avoid kickback Limbing WARNING! A majority of kickback accidents WARNING! Kickback can happen very occur during limbing. Do not use the suddenly and violently; kicking the chain kickback zone of the guide bar. Be extremely saw, bar and chain back at the user. If this cautious and avoid contacting the log, other happens when the chain is moving it can limbs or objects with the nose of the guide...

  • Page 29: Maintenance

    filter is in use will result in a leaner mixture next time the filter is cleaned. This can give Your Jonsered product has been designed and manufactured rise to serious engine damage. to specifications that reduce harmful exhaust fumes.

  • Page 30: Checking, Maintaining And Servicing Chain Saw Safety Equipment

    MAINTENANCE High speed jet H Checking the front hand guard At the factory the engine is adjusted at sea level. When working at a high altitude or in different weather conditions, temperatures and atmospheric humidity, it Make sure the front hand guard is not damaged and that there may be necessary to make minor adjustments to the high are no visible defects such as cracks.
  • Page 31 MAINTENANCE Chain catcher Grasp the chain saw firmly, wrapping your fingers and thumbs around the handles. Check that the chain catcher is not damaged and is firmly attached to the body of the chain saw. Apply full throttle and activate the chain brake by tilting your left wrist forward onto the front hand guard.

  • Page 32: Muffler

    MAINTENANCE Muffler Starter WARNING! When the recoil spring is wound up in the starter housing it is under tension Never use a machine that has a faulty muffler. and can, if handled carelessly, pop out and cause personal injury. Care must be exercised when replacing the return spring or the starter cord.

  • Page 33: Air Filter

    The filter must therefore be replaced with a new one at regular intervals. A damaged air filter must always be replaced. A JONSERED chain saw can be equipped with different types of air filter according to working conditions, weather, season, etc. Contact your dealer for advice.

  • Page 34: Spark Plug

    MAINTENANCE Spark plug Adjustment of the oil pump The spark plug condition is influenced by: The oil pump is adjustable. Adjustments are made by turning the screw using a screwdriver or combination spanner. The • Incorrect carburetor adjustment. machine is supplied from the factory with the screw set to position 2.

  • Page 35: Air Injection" Centrifugal Cleaning

    MAINTENANCE ”Air Injection” centrifugal cleaning • a winter plug (B) for the air nozzle that is fitted as shown. Centrifugal cleaning means the following: All air to the carburetor passes through the starter. Dirt and dust is pushed out by the cooling fan. These reduce the flow of cooling air and prevent large amounts of snow from being sucked into the carburetor space.

  • Page 36: Maintenance Schedule

    MAINTENANCE Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. Daily maintenance Weekly maintenance Monthly maintenance Check the brake band on the chain brake On chain saws without a catalytic for wear.

  • Page 37: Technical Data

    TECHNICAL DATA Technical data CS 2152 CS 2153 Engine Cylinder displacement, cu.in/cm 3,15/51,7 3,06/50,1 Cylinder bore, inch/mm 1,77/45 1,74/44,1 Stroke, inch/mm 1,28/32,5 1,28/32,5 Idle speed, rpm 2700 2700 Power, kW/hp @ rpm 2,4/3,3 @ 9000 2,5/3,4 @ 9600 Ignition system Manufacturer of ignition system Type of ignition system Spark plug...

  • Page 38: Bar And Chain Combinations

    Recommended original and replacement bar and chain combinations Following is a list of recommended cutting equipment for the Jonsered chain saw models CS 2152 and CS 2153. The combinations of power head, bar and chain have been tested and found to be in accordance with the kickback and vibration requirements of ANSI B 175.1–2000.

  • Page 39: Federal Emission Control Warranty Statement

    The use of add-on or modified parts can be grounds for OWNER′ ′ ′ ′ S WARRANTY RESPONSIBILITIES disallowing a warranty claim. Jonsered is not liable to cover failures of warranted parts caused by the use of add-on or As the small nonroad engine owner, you are responsible for modified parts.

  • Page 40: American Standard Safety Precautions

    AMERICAN STANDARD SAFETY PRECAUTIONS Safety precautions for chain saw Other safety precautions users WARNING! Do not operate a chain saw with (ANSI B 175.1-2000 Annex C) one hand! Serious injury to the operator, helpers, bystanders or any combination of Kickback safety precautions these persons may result from one-handed operation.
