Evolutions Temperature Sensor Module
Installation Guide
Model Numbers
☐
EVOSTL
Evolutions Temperature Sensor &
Module
Compliance
• IC: 24889-WW08189
• FCC ID: 2ASQP-WW08189
This device has been tested in accordance to
UL 2043 and is safe to use in plenum and air
handling spaces.
Architectural/ Engineering Specification
Symmons Evolution EVOSTL Includes Temperature Sensor Module, X" attached cable and Probe. Operating Tempera-
ture Range: -30°C to 60°C with a Lithium ion battery enclosed. 10 Year Commercial Warranty. FCC rules compliant.
Symmons Industries, Inc.
Copyright © 2022 Symmons Industries, Inc.
Location:
Evolution
■
■
31 Brooks Drive
Braintree, MA 02184
■
symmons.com
Feature Highlights
•
Temperature Sensor & Module
•
Attached
3 foot
cable and probe
•
Operating Temperature Range: -30°C to 60°C
•
Lithium ion battery enclosed
Warranty
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
■
Phone: (800) 796-6667
■
■
gethelp@symmons.com
■
Fax: (800) 961-9621
■
ZV-3699 REV 0
121422
