Summary of Contents for Avantco 184T140
- Page 1 Adjustable Speed 4003027 4003027 5009704 5009704 Conveyor Toasters CONFORMS TO NSF STD. 4 CONFORMS TO UL STD. 197 CONFORMS TO CSA STD.C22.2 NO 109 Models: 184T140, 184T3300B, 184T3300D, 184T3600B, 184T3600D Please read and keep these instructions. Indoor use only. 11/2022...
-
Page 2: Table Of Contents
User Manual Index Important Safety Information ....... 3 Specifications ..........4 Clearance ............4 Discharge Assembly ........5 Stacking Kit ..........5 Before Use ............ 6 Operation Instructions ......6-7 Cleaning & Maintenance ......7 Troubleshooting ........... 8 www.AvantcoEquipment.com... -
Page 3: Important Safety Information
User Manual Important Safety Information When using electrical appliances, basic safety precautions should always be followed, including the following: 1. Read all instructions carefully and completely. 2. For commercial use only. 3. DO NOT touch hot surfaces. 4. Protect against electrical shock by keeping all cords, plugs, and other electrical components away from water or other liquids. -
Page 4: Specifications
User Manual Specifications Width Depth Height Model Belt Width Width Depth Height 184T140 10" 14½" 30" 16½" 184T3300B 10" 14½" 17" 16½" 184T3300D 10" 14½" 17" 16½" 184T3600B 14½" 18½" 18" 16½" 184T3600D 14½" 18½" 18" 16½" Depth Clearance •... -
Page 5: Discharge Assembly
User Manual Discharge Assembly As detailed in the diagrams below, the unit can either be assembled with front or rear discharge depending on installation position and preference. Front Discharge Rear Discharge 1. Pull metal plate up to the closed position 1. -
Page 6: Before Use
Operation Instructions NOTE: For best performance do not overload the toaster. Wait for a few seconds before loading the second row of bread into the toaster. 184T140 This unit has two controls. 1. Speed/Color Control Determines the length of time the toast or product is in the heating chamber. The slower the speed, the longer the exposure and the darker the product. -
Page 7: Cleaning & Maintenance
User Manual 184T3300B • 184T3300D • 184T3600B • 184T3600D These units have three controls. The top and bottom heating elements are independently controlled. 1. Speed/Color Control Determines the length of time the toast or product is in the heating chamber. The slower the speed, the longer the exposure and the darker the product. -
Page 8: Troubleshooting
Check to ensure hot air from other sources is directed away from at all. Unit is overheated the front of the unit. 184T140: The toaster is set to the Buns setting Adjust the knob to the BREAD setting (dual-sided toasting). (one-sided toasting) Unit toasts on one Ensure both the Top and Bottom Element dials are set to a toast 184T3300/3600: Only one Element Dial is engaged.
