INSTALLATION MANUAL
LED TV
Please read this manual carefully before operating
your set and retain it for future reference.
70UW340C-U*
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70UW340C-U Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG 70UW340C-U Series

Summary of Contents for LG 70UW340C-U Series

  • Page 1 INSTALLATION MANUAL LED TV Please read this manual carefully before operating your set and retain it for future reference. 70UW340C-U* www.lg.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INSTALLATION MENU Introduction Public Display Mode TV Manager - 1. USB - 2. Diagnostics Password Change Set ID Setup Configuration Setup Time Scheduler Lock Mode External Speaker HCEC Setup Insert Image NTP Timer sync AUTO PLAYBACK PLUS (PLAYLIST) 33 EXTERNAL CONTROL DEVICE SETUP - KEY CODES...

  • Page 3: Installation Menu

    The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’. The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators.

  • Page 4: Public Display Mode

    Public Display Mode y Image shown may differ from your TV. Installation Menu (V 3.0) Public Display Settings Public Display Settings (V 3.0) LG Hotel Mode Setup TV Manager ▲ Public Display Mode ► ◄ Password Change • Power On Status Set ID Setup •...
  • Page 5 Operation’ and ‘Local Key Operation’ will be worked by below. (4-1) IR Operation Decide whether work the LG remote control or not. y Able to set Normal, Use PWR Only, Block All y When ‘IR Operation’ is set to Block All, all normal remote keys don’t work. Use PWR Only (Block except power) makes block all remote keys except power key.
  • Page 6 (4-2) Local Key Operation Decide to operate 'Local/Front Key' working behavior by setting ‘Local Key Operation’ as Normal, Use PWR Only, Block All. (LX300C series use for only Normal/Block All) y When 'Local Key Operation' is set to Block All, all local keys don’t work. If value is Use PWR Only, it blocks all local keys except power key.
  • Page 7 Channel Change (5-3) Decide to change channel or not by setting ‘Channel Change' as ‘Yes’(Change Possible) or ‘No’(Change Impossible) when present source is TV. y When ‘Channel Change' is set to No (Change Impossible) » Channel Key, Numeral Key, List Key, Q.View Key don't work and entering 'Channel Menu' in the Main Menu OSD is impossible.
  • Page 8 (6) Power Management The Power Management feature will turn off the television receiver if no input control command is received from either the Local or IR Key within a selected hours. y Activity on either of these inputs shall restart the ‘Power Management’ timer and check key time interval again.
  • Page 9 (8-2) Tune Mode Tune the selected start channel with physical or virtual method. Usually, digital channel uses virtual channel and analog channel uses physical channel. (8-3) Major Select major part of start channel number if Input source value is TV. (in case of ATV, it means physical channel number.) (8-4) Minor Select minor part of start channel number if Input source value is TV.
  • Page 10 (10) Factory Reset Factory reset returns all the parameters to the default settings. • Factory Reset Confirm y Press ‘Enter key’ to proceed factory reset. and confirmation message window will be shown. All user settings and channel settings will be reset. Still Continue? y When select ‘Yes’, all television settings except UTT value should write to the default settings.
  • Page 11 Public Display Settings (Value Range Table) Item Enable Disable Initail Public Display Mode Power On Status *STD Volume Start Volume Off, Minimum Volume ~ Maximum Volume Maximum Volume Minimum Volume ~ 100 Minimum Volume 0 ~ Maximum Volume Key Management IR Operation Work (0) / Use PWR Only (1) / Bock All (2) Work (0)

  • Page 12: Tv Manager

    TV Manager 1. USB Ez Download Ez Download is a function that enables users to download the desired items all at once, such as EPK(software update file), TLL (see Send to USB descriptions for more information regarding file types), LogoImage, NoSignal Image, Welcome Video, etc (TLX, MICOM for Pro:Centric). * Splash images and EPK files and Welcome Video files should be copied into the folder named LG_DTV on the USB.
  • Page 13 SPI Boot or LG Boot Logo. If you checked the LG Boot Logo checkbox, then the Splash image, if selected, will be unchecked. Also, if you select the LG Boot Logo and proceed with the download, the existing Splash image will be deleted.
  • Page 14 USB Cloning An Installer can quickly set up and clone multiple TV sets at a property. These cloned TVs will all have the same Master TV Setup: Public Display Mode Installation Menu settings, User A/V settings and the Channel Map. This newer procedure significantly decreases the installation time that would be necessary if the standard RS-232C method were used instead.
  • Page 15 Receive From USB y Image shown may differ from your TV. Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) Public Display Settings TV Manager Password Change...
  • Page 16 Send To USB y Image shown may differ from your TV. Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) Public Display Settings TV Manager Password Change...
  • Page 17 Logo Image Download Make a ‘LG_DTV’ folder on the USB flash drive and then copy the splash image file to that folder. y Image shown may differ from your TV. Connect the USB device to the USB IN jack on the TV. /DVI IN (RGB) AUDIO IN...

  • Page 18: Diagnostics

    2. Diagnostics Diagnostics Setup Introduction This diagnostic function provides current status information of the TV in XML file format using a USB device. If the user sets a signal standard level, SignalTrace checks the signal strength status of the digital channel that the user tuned to. It checks and records good and bad channel signals, and then provides the signal information to a USB storage device in XML file format.
  • Page 19 y The information created in the XML file can be checked in the TV's UI by pressing 88888888 in the TV's Option menu. (3) Saving signal status information of digital channels through SignalTrace in XML format y Go to Installation menu -> TV Manager -> Diagnostics -> Diagnostics Setup y Set the level value in Signal Tracer Set.

  • Page 20: Password Change

    Password Change y Image shown may differ from your TV. - To ensure more security, Password can be changed by installers’ own design. Installation Menu (V 3.0) Public Display Settings TV Manager Password Change Password Change Password Change Set ID Setup Change Password Configuration Setup Confirm Password...

  • Page 21: Set Id Setup

    Set ID Setup Installation Menu (V 3.0) Public Display Settings TV Manager Set ID Setup Password Change Set ID Setup Set ID Lock Set ID setup ◄ ► Configuration Setup Set ID Time Scheduler Previous Lock Mode External Speaker HCEC Setup Insert Image NTP Timer Sync S/W : 02.00.00.01 Micom : 0.00.84...

  • Page 22: Configuration Setup

    Configuration Setup y Image shown may differ from your TV. Installation Menu (V 3.0) Configuration Setup Public Display Settings Number of RCU TV Manager Splash Offset Time Password Change ◄ ► Photo USB Auto Playback Set ID Setup Disable Configuration Setup 15Min Auto Off Time Scheduler To Set...
  • Page 23 For the audio signal, the priority order is the RGB -> AV -> Audio In component ports. (7) Screen Saver Cube y When ‘Screen Saver Cube’ is set to ‘No’, TV will do not display LG Screen Cube. (8) Big UI Display y When ‘Big UI Display’...

  • Page 24: Time Scheduler

    Time Scheduler Installation Menu (V 3.0) Public Display Settings TV Manager Password Change Time Scheduler Set ID Setup Time Scheduler ◄ ► Configuration Setup On Timer Timer Scheduler Time Scheduler Off Timer Lock Mode Previous External Speaker HCEC Setup Insert Image NTP Timer Sync S/W : 02.00.00.01 Micom : 0.00.84 Use the...

  • Page 25: Lock Mode

    Lock Mode Installation Menu (V 3.0) Public Display Settings TV Manager Password Change Set ID Setup Lock Mode Configuration Setup Enable Data Service ◄ ► Time Scheduler Enable Lock Mode Lock Mode Enable Factory Reset External Speaker Previous HCEC Setup Insert Image NTP Timer Sync S/W : 02.00.00.01 Micom : 0.00.84...

  • Page 26: External Speaker

    External Speaker Installation Menu (V 3.0) Public Display Settings TV Manager Password Change External Speaker Set ID Setup Fixed ◄ ► Volume Control Configuration Setup 1 Watt Output Timer Scheduler Previous Lock Mode External Speaker External Speaker HCEC Setup Insert Image NTP Timer Sync S/W : 02.00.00.01 Micom : 0.00.84 Use the...
  • Page 27 Speaker output SETUP Connect the external speaker to the external speaker out jack on the TV. EXTERNAL SPEAKER OUT RIGHT LEFT NOTE y External speaker must be used three plug(SE : Single Ended, Stereo) as shown in the drawings and external speaker fully inserted with external Speaker Jack.

  • Page 28: Hcec Setup

    HCEC Setup Installation Menu (V 3.0) Public Display Settings TV Manager Password Change HCEC Setup Set ID Setup CEC Mode Default ◄ ► Configuration Setup IR Decoding Timer Scheduler Device ID Lock Mode StandBy External Speaker HTNG HotelMode HCEC Setup HCEC Setup Previous Insert Image...
  • Page 29 (c) Stand By y Sets the sending and receiving scenario of the operation about [CEC Op standBy(0x0c) Command(Device Power)]. y The detailed scenario is described on the table below. Send Receive Send Only Receive Only (2) HTNG HotelMode y If the following options are selected because of the HTNG command: *Power On Default, Start Volume, Maximum Volume, Minimum Volume, or Start Volume, then the value for the HTNG HotelMode changes automatically to Yes and, even if the HotelMode is set to No, the above options are still affected.

  • Page 30: Insert Image

    INSERT IMAGE y This feature allows you to display an image you have stored on the TV instead of the LG Cube when there is no signal due to DTV signal attenuation, external device failure, or cable removal. Installation Menu (V 3.0)

  • Page 31: Ntp Timer Sync

    NTP Timer Sync y This feature allows you to receive time information via NTP(Network Time Protocol) Time Server to set current clock. Installation Menu (V 3.0) Public Display settings TV manager Password Change NTP Timer Sync Set ID Setup Configuration Setup NTP Timer Sync Time scheduler GMT Offset...

  • Page 32: Auto Playback Plus (Playlist)

    AUTO PLAYBACK PLUS (PLAYLIST) y This feature is available only on models that support it. y Image show may differ from your TV. (1) Auto Playback Plus Overview y Auto Playback Plus is a feature you can use to make and play your own media list. y Videos and photos are supported.

  • Page 33: External Control Device Setup

    EXTERNAL CONTROL DEVICE SETUP KEY CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button R/C Button CH -, PR - R/C Button LIST R/C Button VOLUME + R/C Button EXIT...

  • Page 34: External Control Device Setup

    (TV) (PC) • LGTV supports PL2303 chip-based (Vendor ID : 0x0557, Product ID : 0x2008) USB to serial converter RS-232C IN which is not made nor provided by LG. (CONTROL & SERVICE) (PC) (TV) • It can be purchased from computer stores that carry accessories for IT support professionals.
  • Page 35 Customer Computer RS-232C configurations 7-Wire Configuration (Serial female-female NULL modem cable) RS-232C (Serial port) D-Sub 9 D-Sub 9 3-Wire Configurations (Not standard) D-Sub 9 D-Sub 9 Set ID For Set ID number, see "Real Data Mapping". Press SETTINGS to access the main menus. Press the Navigation buttons to scroll to (*General →...
  • Page 36 Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA DATA...
  • Page 37 Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99.
  • Page 38 * Commands may work differently depending on model and signal. 01. Power (Command: k a) display OSD. ► To control Power *On or Off of the set. Transmission[k][a][ ][Set ID][ ][Data][Cr] 04. Volume Mute (Command: k e) ► To control volume mute on/off. Data 00 : Power Off 01 : *Power On You can also adjust mute using the MUTE button on...
  • Page 39 Data Red : 00 to Green : 64 * (Depending on model) Ack [j][ ][Set ID][ ][OK/NG][Data][x] 15. Balance (Command: k t) ► To adjust balance. You can also adjust balance in the AUDIO menu. 10. Sharpness (Command: k k) Transmission [k][t][ ][Set ID][ ][Data][Cr] ►...
  • Page 40 Result = ma 00 00 01 10 Transmission [j][q][ ][Set ID][ ][Data][Cr] Data 3. Tune to the satellite (DVB-S) Channel 1000. 00 : Off Set ID = All = 00 01 : Minimum Data 00 & 01 = Channel Data is 1000 = 03 E8 02 : Medium Data 02 = Digital Satellite TV = 40 03 : Maximum...
  • Page 41 data, but usually the low byte is used alone (high byte is 0). Data 03 & 04 = Don’t Care = 00 00 Data 05 = BS TV = 07 Digital * Tune Command Examples: Total = ma 00 00 00 1E 00 00 07 1.
  • Page 42 24. Input select (Command: x b) [Data 00] [Data 01] [Data 02] [Data 03] (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data 00 : DTV 01 : CADTV 02 : Satellite DTV 10 : ATV X : don’t care ISDB-BS (Japan)
  • Page 43 27. Auto Configure (Command: j u) (Depending on model) ► To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Data 01 : To set Auto Configure Ack [u][ ][Set ID][ ][OK/NG][Data][x]...
