- Page 1 KNOMI VERSION 2023-04-28...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WWW.BIGTREE-TECH.COM Welcome to KNOMI Configuring Wi-Fi Performance Comparison Test Installing KNOMI on StealthBurner Table of Contents Adding Relevant Macros Packing List KNOMI UI Overview Thanks for providing guidance on Voron's official style build guide. TABLE OF CONTENTS... - Page 3 WWW.BIGTREE-TECH.COM WHAT IS KNOMI KNOMI is a mini round screen designed specifically for Klipper running 3D printers, offering users a unique and personalized way to monitor their printer's operation. The screen displays important information through KNOMI UI, such as heated bed temperature, nozzle temperature, leveling status, printing progress, etc.
-
Page 4: Performance Comparison Test
DOES USING KNOMI IMPACT YOUR STEALTHBURNER'S PERFORMANCE? We will offer the customized mounting printed part files for you to effortlessly install KNOMI into your Voron Stealthburner, in which the StealthBurner main body retains the original fan position and incorporates additional vents on the top for enhanced compatibility and optimized heat dissipation. - Page 5 We conducted a comparative analysis measuring wind speed and acoustic energy levels between the original StealthBurner and our customized version featuring vents and KNOMI add-on. The results showed that both versions performed similarly, indicating that adding KNOMI will not compromise the performance of the StealthBurner.
- Page 6 PACKING LIST WWW.BIGTREE-TECH.COM KNOMI CABLE (MX1.25-2pin to 2x DuPont 2.54-1pin)
- Page 7 OVERVIEW WWW.BIGTREE-TECH.COM TYPE C （UART TO USB） DC 5V IN BOOT POWER IN DC5~24V...
-
Page 8: Configuring Wifi
ACTIVATE THE HELLO INTERFACE Power KNOMI using either the Type-C or MX1.25 interface. While KNOMI is powered on, press and hold the BOOT button for 5 seconds. Wait for KNOMI to display the HELLO message then release the BOOT button. - Page 9 This may be caused by the following problems: 1. You have modified the Wi-Fi name or password, causing KNOMI and the printer to be in different network states. To resolve this, press and hold the BOOT button on the side of KNOMI for 5 seconds to enter the "HELLO"...
-
Page 10: Installing Knomi On Stealthburner
INSTALL KNOMI TO STEALTHBURNER WWW.BIGTREE-TECH.COM StealthBurner Main Body for KNOMI ROUTING THE CABLE Pass the cable through the slot on the printed part before starting, as shown in the figure. This is important because it will be difficult to insert the cable once other components are installed. - Page 11 INSTALL KNOMI TO STEALTHBURNER WWW.BIGTREE-TECH.COM...
- Page 12 Use the mounting plate to securely fix KNOMI in place. TIPS To insert the KNOMI, first angle it so that the Wi-Fi antenna side is inserted into the slot. Then, carefully put the entire KNOMI into the front cover printed part until it is flush with...
- Page 13 EBB SB0000 CAN TURBOFAN Install the EBB SB0000 CAN or a similar board Install the turbofan using the original method as (skip this step if not using the EBB SB0000 if KNOMI were not being used. CAN or a similar board).
- Page 14 ROUTING THE CABLE As illustrated in the diagram, pass the cable of KNOMI through the designated cable slot on the printed part and direct it towards the rear of the turbofan.
- Page 15 INSTALL KNOMI TO STEALTHBURNER WWW.BIGTREE-TECH.COM TIPS Proceed with the installation of LEDs, axial fans, and other components following the same steps as if KNOMI were not being used. Prior to powering on the device, inspect for potential short circuits or reverse polarity issues.
-
Page 16: Adding Relevant Macros
HOMING AND LEVELING KNOMI requires the addition of relevant macros for homing and leveling within the printer.cfg file. Access the print control interface by entering the Klipper IP address into your browser, locate the config Files directory containing printer.cfg, and insert the following macro... -
Page 17: Knomi Ui
KNOMI UI WWW.BIGTREE-TECH.COM KNOMI user interface employs visual elements during various stages of printer operation to provide status information to the user: STANDBY HEATED BED – HEATING The printer awaits operational instructions. The target temperature is indicated at the top, while the real-time progress of the temperature change is shown at the bottom. - Page 18 The bed and nozzle have reached their respective target The printhead is in motion and starts to print. temperatures, and the printer is ready to print. PRINTING PROGRESS Print Completed After 1% progress, KNOMI will display this UI. The print has been completed.
- Page 19 WWW.BIGTREE-TECH.COM Website GitHub Discord www.discord.gg/5jdwbYYZuv WWW.bigtree-tech.com WWW.github.com/bigtreetech...
