Version 1.0
Published July 2020
Copyright©2020 ASRock INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the owners' benefit, without intent to
infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informational use only and subject to change without notice, and should not be
constructed as a commitment by ASRock. ASRock assumes no responsibility for
any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or fitness for a particular
purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from any
defect or error in the documentation or product.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
The Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
"Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate"
ASRock Website: http://www.asrock.com
migliori offerte di Schede Madri
AsRock A520M HVS
o
Advertisement
Table of Contents
Related Manuals for ASROCK A520M HVS
Summary of Contents for ASROCK A520M HVS
- Page 1 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
- Page 2 You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply) The terms HDMI®...
-
Page 3: Motherboard Layout
A520M-HDV A520M-HVS Motherboard Layout A520M-HDV: CPU_FAN1 ATX12V USB 2.0 T: USB1 B: USB2 USB 3.2 Gen1 T: USB1 B: USB2 CMOS USB 3.2 Gen1 Battery T: USB3 B: USB4 CHA_FAN1 BIOS SPI_TPM_J1 PCIE1 Ultra M.2 PCIe Gen3 x4 PCIE2 AUDIO CODEC RoHS Promontory... - Page 4 A520M-HVS: CPU_FAN1 ATX12V USB 2.0 T: USB1 B: USB2 USB 3.2 Gen1 T: USB1 B: USB2 CMOS USB 3.2 Gen1 Battery T: USB3 B: USB4 CHA_FAN1 BIOS SPI_TPM_J1 PCIE1 Ultra M.2 PCIe Gen3 x4 PCIE2 AUDIO CODEC RoHS Promontory A520 COM1 HD_AUDIO1 USB_5_6...
- Page 5 A520M-HDV A520M-HVS No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1) ATX Power Connector (ATXPWR1) USB 3.2 Gen1 Header (USB3_5_6) SATA3 Connector (SATA3_3) (Upper), SATA3 Connector (SATA3_4) (Lower) SATA3 Connector (SATA3_4) (Upper), SATA3 Connector (SATA3_2) (Lower) System Panel Header (PANEL1) Chassis Intrusion and Speaker Header (SPK_CI1) Chassis Fan Connector (CHA_FAN2)
- Page 6 I/O Panel A520M-HDV: No. Description No. Description USB 2.0 Ports (USB_12) USB 3.2 Gen1 Ports (USB3_34) D-Sub Port USB 3.2 Gen1 Ports (USB3_12) LAN RJ-45 Port* DVI-D Port Line In (Light Blue)** HDMI Port Front Speaker (Lime)** PS/2 Mouse/Keyboard Port Microphone (Pink)** A520M-HVS: No.
- Page 7 A520M-HDV A520M-HVS * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED Status Description Status Description No Link 10Mbps connection Blinking Data Activity...
-
Page 8: Chapter 1 Introduction
If you require technical support related to this mother- board, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com. -
Page 9: Specifications
(OC)/4666(OC)/4600(OC)/4533(OC)/4466(OC)/4400(OC)/ 4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866 (OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/3200/2933/ 2667/2400/2133 ECC & non-ECC, un-buffered memory* * Please refer to Memory Support List on ASRock’s website for more information. (http://www.asrock.com/) * Please refer to page 21 for DDR4 UDIMM maximum frequency support. • Max. capacity of system memory: 64GB • Supports Extreme Memory Profile (XMP) memory modules... - Page 10 Graphics • Integrated AMD Radeon Vega Series Graphics in Ryzen Series APU* * Actual support may vary by CPU • DirectX 12, Pixel Shader 5.0 • Shared memory default 2GB. Max Shared memory supports up to 16GB. * The Max shared memory 16GB requires 32GB system memory installed.
- Page 11 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)* * Supports NVMe SSD as boot disks * Supports ASRock U.2 Kit Connector • 1 x SPI TPM Header • 1 x COM Port Header • 1 x Chassis Intrusion and Speaker Header...
- Page 12 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.
-
Page 13: Chapter 2 Installation
A520M-HDV A520M-HVS Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings. -
Page 14: Installing The Cpu
2.1 Installing the CPU Unplug all power cables before installing the CPU. - Page 15 A520M-HDV A520M-HVS...
-
Page 16: Installing The Cpu Fan And Heatsink
2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other. - Page 17 A520M-HDV A520M-HVS...
- Page 18 Installing the AM4 Box Cooler SR2...
- Page 19 A520M-HDV A520M-HVS...
- Page 20 *The diagrams shown here are for reference only. The headers might be in a different position on your motherboard.
- Page 21 A520M-HDV A520M-HVS Installing the AM4 Box Cooler SR3...
- Page 23 A520M-HDV A520M-HVS +12V *The diagrams shown here are for reference only. The headers might be in a different position on your motherboard.
-
Page 24: Installing Memory Modules (Dimm)
2.3 Installing Memory Modules (DIMM) This motherboard provides two 288-pin DDR4 (Double Data Rate 4) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR4 DIMM pairs. 2. - Page 25 A520M-HDV A520M-HVS The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
-
Page 26: Expansion Slots (Pci Express Slots)
2.4 Expansion Slots (PCI Express Slots) There are 2 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation. -
Page 27: Jumpers Setup
A520M-HDV A520M-HVS 2.5 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper Short: Clear CMOS (CLRMOS1) 2-pin Jumper... -
Page 28: Onboard Headers And Connectors
2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power PLED+ PLED-... - Page 29 A520M-HDV A520M-HVS Chassis Intrusion and Please connect the SPEAKER DUMMY Speaker Header chassis intrusion and the DUMMY (7-pin SPK_CI1) chassis speaker to this (see p.1 or 2, No. 9) header. SIGNAL DUMMY Serial ATA3 Connectors These four SATA3 Vertical: connectors support SATA (SATA3_1: data cables for internal see p.1 or 2, No.
- Page 30 1. High Definition Audio supports Jack Sensing, but the panel wire on the chassis must support HDA to function correctly. Please follow the instructions in our manual and chassis manual to install your system. 2. If you use an AC’97 audio panel, please install it to the front panel audio header by the steps below: A.
- Page 31 A520M-HDV A520M-HVS ATX 12V Power Please connect an ATX Connector 12V power supply to this (4-pin ATX12V1) connector. (see p.1 or 2, No. 1) *The power supply plug fits into this connector in only one orientation. Serial Port Header This COM1 header RRXD1 DDTR#1 DDSR#1...
- Page 32 2.7 M.2_SSD (NGFF) Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket supports M Key type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s).
- Page 33 A520M-HDV A520M-HVS Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location C by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut. Otherwise, release the standoff by hand.
- Page 34 Step 6 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw as this might damage the module. NUT2 NUT1...
- Page 35 SanDisk SATA Sandisk Z400s-SD8SNAT-128G-1122 SanDisk SATA SanDisk-SD6SN1M-128G Transcend SATA Transcend TS256GMTS800-256GB V-Color SATA V-Color 120G V-Color SATA V-Color 240G SATA WD GREEN WDS240G1G0B-00RC30 For the latest updates of M.2_SSD (NFGG) module support list, please visit our website for details: http://www.asrock.com...
-
Page 36: Technische Daten
4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/ 3800(OC)/3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/ 2400/2133 ECC und non-ECC, ungepufferter Speicher* * Weitere Informationen finden Sie in der Speicherkompatibilitätsliste auf der ASRock-Webseite. (http://www.asrock.com/) * Bitte beachten Sie Seite 21 für die maximal unterstützte Frequenz von DDR4-UDIMM. • Systemspeicher, max. Kapazität: 64GB • Unterstützt Extreme-Memory-Profile- (XMP) Speichermodule • 15-μ-Goldkontakt in DIMM-Steckplätze... - Page 37 A520M-HDV A520M-HVS Grafikkarte • Integrierte Grafikkarte der AMD-Radeon -Vega-Serie in APU der Ryzen-Serie* * Tatsächliche Unterstützung kann je nach Prozessor variieren • DirectX 12, Pixel Shader 5.0 • Freigabespeicher von standardmäßig 2GB. Max. Freigabespeicher unterstützt bis zu 16GB. * Der max. Freigabespeicher von 16GB erfordert die Installation von 32GB Systemspeicher.
- Page 38 • 1 x Ultra-M.2-Sockel, unterstützt M-Key-Typ- 2242/2260/2280- M.2-SATA-III-6,0-Gb/s-Modul und M.2-PCI Express- Modul bis Gen3 x4 (32 Gb/s)* * Unterstützt NVMe-SSD als Bootplatte * Unterstützt ASRock U.2-Kit Anschluss • 1 x SPI-TPM-Stiftleiste • 1 x COM-Anschluss-Stiftleiste • 1 x Gehäuseeingriff- und Lautsprecher-Stiftleiste • 1 x CPU-Lüfteranschluss (4-polig)
- Page 39 A520M-HDV A520M-HVS • 2 x Gehäuselüfteranschlüsse (4-polig) (intelligente Lüftergeschwindigkeitssteuerung) * Der Gehäuselüfteranschluss unterstützt einen Wasserkühlerlüfter mit einer maximalen Lüfterleistung von 1 A (12 W). * CHA_FAN2 können automatisch erkennen, ob ein 3- oder 4-poliger Lüfter verwendet wird. • 1 x 24-poliger ATX-Netzanschluss • 1 x 4-poliger 12-V-Netzanschluss • 1 x Audioanschluss an Frontblende • 2 x USB 2.0-Stiftleisten (unterstützt 4 USB 2.0-Ports) (unterstützt...
-
Page 40: Spécifications
4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/ 3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133* * Veuillez consulter la liste de prise en charge des mémoires sur le site Web d'ASRock pour de plus amples informations. (http://www.asrock.com/) * Veuillez consulter la page 21 pour connaître la prise en charge de la fréquence maximale de l'UDIMM DDR4. - Page 41 A520M-HDV A520M-HVS Graphiques • Carte graphique AMD Radeon série Vega intégrée dans APU série Ryzen* * La prise en charge réelle peut varier selon le processeur • DirectX 12, Pixel Shader 5.0 • Mémoire partagée par défaut 2 Go. Mémoire partagée maximum prise en charge 16 Go.
- Page 42 6,0 Go/s type 2242/2260/2280 touche M et M.2 PCI Express jusqu'à Gen3 x4 (32 Gb/s)* * Prend en charge les SSD NVMe comme disques de démarrage * Prend en charge le kit ASRock U.2 Connecteur • 1 x embase SPI TPM • 1 x embase pour port COM...
- Page 43 A520M-HDV A520M-HVS * Le connecteur pour ventilateur de châssis prend en charge un ventilateur de refroidisseur d’ e au d’une puissance maximale de 1 A (12 W). * CHA_FAN2 peuvent détecter automatiquement si un ventilateur 3 broches ou 4 broches est utilisé. • 1 x connecteur d’alimentation ATX 24 broches • 1 x connecteur d’alimentation 12 V 4 broches • 1 x connecteur audio panneau frontal...
- Page 44 3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC e non ECC, senza buffer* * Per maggiori informazioni fare riferimento all'elenco dei supporti di memoria sul sito di ASRock. (http://www.asrock.com/) * Fare riferimento a pagina 21 per il supporto della frequenza massima DDR4 UDIMM. • Capacità max. della memoria di sistema: 64GB • Supporta moduli di memoria Extreme Memory Profile (XMP)
- Page 45 A520M-HDV A520M-HVS Grafica • Grafica AMD Radeon serie Vega integrata nelle APU serie Ryzen* * Il supporto effettivo può variare in base alla CPU • DirectX 12, Pixel Shader 5.0 • Memoria condivisa predefinita 2GB. Memoria condivisa massima supporta fino a 16GB. * La memoria condivisa massima di 16GB richiede che sia installata una memoria di sistema da 32GB.
- Page 46 M Key 2242/2260/2280 ed il modulo M.2 PCI Express fino a Gen3 x4 (32 Gb/s)* * Supporto di SSD NVMe come disco d’avvio * Supporta kit ASRock U.2 Connettore • 1 x connettore SPI TPM • 1 x connettore porta COM • 1 x collegamento altoparlante e intrusione telaio...
- Page 47 A520M-HDV A520M-HVS * Il cventola chassis supporta ventole di sistemi di raffreddamento ad acqua di potenza massima di 1A (12W). * CHA_FAN2 sono in grado di rilevare se è in uso una ventola a 3 pin o 4 a pin. • 1 x connettore alimentazione ATX 24-pin • 1 x connettore alimentazione 12 V 4-pin • 1 x connettore audio pannello frontale...
-
Page 48: Especificaciones
4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466(OC)/ 3200/2933/2667/2400/2133 ECC y no ECC* * Para obtener más información, consulte la lista de memorias compatibles en el sitio web de ASRock. (http://www.asrock.com/) * Consulte la página 21 para conocer las frecuencias máximas compatibles de DDR4 UDIMM. • Capacidad máxima de memoria del sistema: 64GB • Admite módulos de memoria Extreme Memory Profile (XMP) - Page 49 A520M-HDV A520M-HVS Gráficos • Tarjeta gráfica de la serie AMD Radeon Vega integrada en APU de la serie Ryzen* * El soporte real puede variar según la CPU • DirectX 12, Pixel Shader 5.0 • Memoria compartida predeterminada de 2 GB. Memoria máxima compartida admite hasta 16 GB.
- Page 50 2242/2260/2280 con clave M y el módulo PCI Express M.2 hasta Gen3 x4 (32 Gb/s)* * Admite unidad de estado sólido de NVMe como disco de arranque * Admite el Kit U.2 de ASRock Conector • 1 x Conector SPI TPM • 1 x Base de conexiones de puerto COM...
- Page 51 A520M-HDV A520M-HVS * CHA_FAN2 se pueden detectar automáticamente si se usa el ventilador de 3 o 4 pines. • 1 x conector de alimentación ATX de 24 contactos • 1 x conector de alimentación de 12V de 4 contactos • 1 x Conector de audio en el panel frontal • 2 x Bases de conexiones USB 2.0 (Admite 4 puertos USB 2.0) (Admite protección contra descargas electrostáticas) • 1 x base de conexiones USB 3.2 Gen1 (Admite 2 puertos USB 3.2...
-
Page 52: Технические Характеристики
4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/ 3600(OC)/3466(OC)/3200/2933/2667/2400/2133 с ECC и без ECC, небуферизованной памяти* * Дополнительная информация представлена в Списке совместимой памяти (Memory Support List) на веб-сайте ASRock. (http://www.asrock.com/) * Максимальные поддерживаемые частоты DDR4 UDIMM см на стр. 21. • Максимальный объем ОЗУ: 64 Гб... - Page 53 A520M-HDV A520M-HVS Графическая • Встроенный видеоадаптер AMD Radeon серии Vega в подсистема процессорах APU серии Ryzen* *Фактическая поддержка зависит от процессора • DirectX 12, пиксельные шейдеры 5.0 • Общий объем памяти по умолчанию 2 ГБ. Поддерживается максимальный общий объем памяти до 16 ГБ. * Для...
- Page 54 ключом М и модуль M.2 PCI Express до версии Gen3 x4 (32 Gb/s)* * Поддерживаются в качестве загрузочных SSD-диски типа NVMe * Поддерживается комплект ASRock U.2 Разъемы • 1 колодка SPI ТРМ • 1 колодка СОМ-порта • 1 колодка с разъемами датчика вскрытия корпуса и...
- Page 55 A520M-HDV A520M-HVS • 1 разъем для вентилятора охлаждения ЦП (4-контактный) * Разъем процессорного вентилятора поддерживает вентилятор с потребляемым током не более 1 А (12 Вт). • 2 разъема для корпусных вентиляторов (4-контактные) (смарт-регулятор скорости вентилятора) * вентилятора корпуса поддерживает вентилятор с потребляемым током не более 1 А (12 Вт). * Для...
- Page 56 4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/ 3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & não-ECC, memória sem buffer* * Por favor, consulte a Lista de Suporte de Memória no site da ASRock para obter mais informação. (http://www.asrock.com/) * Por favor consulte a página 21 para suporte de frequência máxima DDR4 UDIMM.
- Page 57 A520M-HDV A520M-HVS Gráficos • AMD Radeon Integrado Série Vega Gráficas na Série Ryzen APU* * Suporte atual pode vairar por CPU • DirectX 12, Pixel Shader 5.0 • Memória compartilhada padrão 2GB. Memória compartilhada máx suporta até 16GB. * A memória compartilhada máx de 16GB requer 32GB de memória de sistema instalado.
- Page 58 M.2 SATA3 6,0 Gb/s e módulo M.2 PCI Express até Gen3 x4 (32 Gb/s)* * Suporta NVMe SSD nos discos de inicialização * Suporta Kit U.2 ASRock Conector • 1 x Plataforma SPI TPM • 1 x Suporte porta COM • 1 x Intrusão do Chassi e Cabeçote de Autofalante...
- Page 59 A520M-HDV A520M-HVS • 1 x Conector de áudio do painel frontal • 2 x Plataformas USB 2.0 (Suporta 4 portas USB 2.0) (Suporta Proteção ESD) • 1 x Plataforma USB 3.2 Gen1 (Suporta 2 portas USB 3.2 Gen1) (Suporta Proteção ESD) Funções da • AMI UEFI Legal BIOS com suporte GUI BIOS...
- Page 60 DDR4 4733+(OC)/4666(OC)/4600(OC)/4533(OC)/4466(OC)/ 4400(OC)/4333(OC)/4266(OC)/4200(OC)/4133(OC)/4000(OC)/ 3866(OC)/3800(OC)/3733(OC)/3600(OC)/3466 (OC)/3200/2933/ 2667/2400/2133 ECC i nie-ECC* * Sprawdź listę obsługiwanej pamięci na stronie internetowej ASRock w celu uzyskania dalszych informacji. (http://www.asrock.com/) * Sprawdź stronę 21 w celu uzyskania informacji o maksymalnej obsługiwanej częstotliwości DDR4 UDIMM. • Maks. wielkość pamięci systemowej: 64GB • Obsługa modułów pamięci Extreme Memory Profile (XMP)
- Page 61 A520M-HDV A520M-HVS Grafika • Zintegrowana karta graficzna AMD Radeon serii Vega w APU serii Ryzen* * Rzeczywista obsługa zależy od CPU • DirectX 12, Pixel Shader 5.0 • Pamięć współdzielona, domyślnie 2GB. Maksymalnie pamięć współdzielona obsługuje do 16GB. * Maksymalna pamięć współdzielona 16GB wymaga zainstalowania 32GB pamięci systemowej.
- Page 62 M.2 SATA3 6,0 Gb/s i modułu M.2 PCI Express do Gen3 x4 (32 Gb/s)* * Obsługa SSD NVMe, jako dysków rozruchowych * Obsługa ASRock U.2 Kit Złącze • 1 x złącze główkowe SPI TPM • 1 x złącze główkowe portu COM • 1 x złącze główkowe naruszenia obudowy i głośnika...
- Page 63 A520M-HDV A520M-HVS • 1 x złącze audio na panelu przednim • 2 x złącza główkowe USB 2.0 (Obsługa 4 portów USB 2.0) (Obsługa zabezpieczenia ESD) • 1 x porty główkowe USB 3.2 Gen1 (obsługa 2 portów USB 3.2 Gen1) (obsługa zabezpieczenia ESD) Funkcja BIOS • Obsługa starszych wersji BIOS AMI UEFI z GUI • Obsługa “Plug and Play”...
- Page 64 4666(OC)/4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/ 4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/ 3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 및 비 ECC, 비버퍼링 메모리를 지원합니다 * * 추가 정보를 원하시면 ASRock 웹사이트에 있는 메모리 지원 목록을 참조하십시오 . (http://www.asrock.com/) * DDR4 UDIMM 최대 주파수 지원은 21 페이지를 참조하십시오 . • 시스템 메모리 최대 용량 : 64GB •...
- Page 65 A520M-HDV A520M-HVS • Ryzen Series APU 의 통합형 AMD Radeon Vega Series 그래픽 * 그래픽 * 실제 지원은 CPU 에 따라 다를 수 있음 • DirectX 12, Pixel Shader 5.0 • 기본 공유 메모리는 2GB 입니다 . 최대 공유 메모리는 16GB 까지...
- Page 66 • 울트라 M.2 하이퍼 1 개 , M 키 타입 2242/2260/2280 M.2 SATA3 6.0 Gb/s 모듈 및 Gen4 M.2 PCI Express 모듈 Gen3 x4 (32 Gb/s) * * NVMe SSD 를 부팅 디스크로 사용 가능하도록 지원 * ASRock U.2 키트 지원 • SPI TPM 헤더 1 개 커넥터...
- Page 67 A520M-HDV A520M-HVS • ACPI 5.1 준수 웨이크 업 이벤트 • 점퍼 프리 지원 • SMBIOS 2.3 지원 • CPU, CPU VDDCR_SOC, DRAM, VDDP 전압 다중 조정 • 온도 감지 : CPU, 커넥터 하드웨어 • 팬 타코미터 : CPU, 커넥터 모니터 •...
- Page 68 • AMD Ryzen シリーズ APU (Renoir) は、 DDR4 4733+(OC)/ 4666(OC)/4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/ 4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/ 3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC および非 ECC、 アンバッファードメモリに対応します * * 詳細については、 ASRock ウェブサイ トのメモリーサポート一覧を参 照してく ださい。 (http://www.asrock.com/) * DDR4 UDIMM 最大周波数サポートについては 21 ページを参照し てく ださい。 • システムメモリの最大容量 ： 64GB • Extreme Memory Pro le (XMP) メモリモジュールに対応します...
- Page 69 A520M-HDV A520M-HVS Vega シリーズグラフ ィ ックスを Ryzen シリーズ グラフ ィ ックス • AMD Radeon APU に統合 * * 実際のサポートは CPU によって異なるこ とがあります • DirectX 12、 Pixel Shader 5.0 • 共有メモリはデフォルトでは 2GB に設定されています。 最大共有 メモリは 16GB まで対応します。 * 最大共有メモリが 16GB の場合は、 32GB のシステムメモリがインス トールされていなければなりません。...
- Page 70 • 1 x Ultra M.2 Socket は、 M Key タイプ 2242/2260/2280 M.2 SATA3 6.0 Gb/s モジュール、 および、 最大 Gen3 x4 (32 Gb/s) までの M.2 PCI Express モジュール * * 起動ディスク として NVMe SSD に対応 * ASRock U.2 キッ トに対応 • 1 x SPI TPM ヘッダー コネクタ • 1 x COM ポートヘッダー...
- Page 71 A520M-HDV A520M-HVS • 1 x 24 ピン ATX 電源コネクタ • 1 x 4 ピン 12V 電源コネクタ • 1 x 前面パネルオーディオコネクタ • 2 x USB 2.0 ヘッダー （4 つの USB 2.0 ポートに対応） （ 静電気放電 (ESD) 保護に対応） • 1 x USB 3.2 Gen1 ヘッダー （2 つの USB 3.2 Gen1 ポートに対応） （静電気放電...
- Page 72 • AMD Ryzen 系列 APU (Renoir) 支持 DDR4 4733+(OC)/ 4666(OC)/4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/ 4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/ 3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC 及 非 ECC，非缓冲内存 * * 请参阅华擎网站上的 Memory Support List（内存支持列表）了解 详情。(http://www.asrock.com/) * 请参考第 21 页了解 DDR4 UDIMM 最大支持频率。 • 支持系统内存最大容量：64GB • 支持 Extreme Memory Pro le (XMP) 内存模块 • DIMM 插槽中 15 μ 金触点 扩充槽...
- Page 73 A520M-HDV A520M-HVS 图形 • Ryzen 系列 APU 中的集成 AMD Radeon Vega 系列图形 * * 实际支持可能视 CPU 而变化 • DirectX 12、Pixel Shader 5.0 • 默认共享内存 2GB。最大共享内存达 16GB。 * 最大共享内存 16GB 需要安装 32GB 系统内存。 A520M-HDV: • 3 个图形输出选项：D-Sub、DVI-D 和 HDMI • 支持三台显示器 •...
- Page 74 后面板 I/O • 1 x PS/2 鼠标 / 键盘端口 • 2 x USB 2.0 端口（支持 ESD 保护） • 4 x USB 3.2 Gen1 端口（支持 ESD 保护） • 1 x RJ-45 LAN 端口，带 LED（ACT/LINK LED 和 SPEED LED） • 高清音频插孔：线路输入 / 前扬声器 / 麦克风 A520M-HDV: •...
- Page 75 A520M-HDV A520M-HVS BIOS 功能 • AMI UEFI Legal BIOS，支持 GUI 特点 • 支持“即插即用” • ACPI 5.1 兼容唤醒事件 • 支持免跳线 (jumperfree) • 支持 SMBIOS 2.3 • CPU、CPU VDDCR_SOC、DRAM、VDDP 电压多次调整 (Voltage Multi-adjustment) 硬件监控 • 温度感测：CPU、机箱风扇 • 风扇转速计：CPU、机箱风扇 • 静音风扇（根据 CPU 温度自动调整机箱风扇速度）：CPU、 机箱风扇 •...
- Page 76 4666(OC)/4600(OC)/4533(OC)/4466(OC)/4400 (OC)/4333(OC)/ 4266(OC)/4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/ 3733(OC)/3600(OC)/3466(OC)/3200/2933/2667/2400/2133 ECC & 非 ECC、無緩衝記憶體 * * 如需更多資訊，請參閱華擎網站上的記憶體支援表。 (http://www.asrock.com/) * 關於 DDR4 UDIMM 最高頻率支援，請參閱第 21 頁。 • 最大系統記憶體容量：64GB • 支援 Extreme Memory Pro le (XMP) 記憶體模組 • 15 μ 特厚鍍金插槽 1 x PCI Express 3.0 x16 插槽（PCIE2: x16 模式）* 擴充插槽...
- Page 77 A520M-HDV A520M-HVS • 整合式 AMD Radeon Vega Series Graphics 內建於 Ryzen 系列 顯示卡 APU* * 實際支援可能隨 CPU 改變 • DirectX 12、Pixel Shader 5.0 • 預設共用記憶體 2GB。最大共用記憶體達 16GB。 * 最大共用記憶體 16GB 需要安裝 32GB 系統記憶體。 A520M-HDV: • 三個圖形輸出選項：D-Sub、DVI-D 及 HDMI • 支援三台顯示器 •...
- Page 78 後面板 I/O • 1 x PS/2 滑鼠／鍵盤連接埠 • 2 x USB 2.0 連接埠（支援靜電保護） • 4 x USB 3.2 Gen1 連接埠（支援靜電保護） • 1 x RJ-45 LAN 連接埠，含 LED（ACT/LINK LED 及 SPEED LED） • HD 音訊插孔：線路輸入／前置喇叭／麥克風 A520M-HDV: • 1 x D-Sub 連接埠 •...
- Page 79 A520M-HDV A520M-HVS BIOS 功能 • AMI UEFI Legal BIOS 含 GUI 支援 • 支援「隨插即用」 • ACPI 5.1 符合喚醒自動開機 • 支援免跳線模式 • 支援 SMBIOS 2.3 • CPU、CPU VDDCR_SOC、DRAM、VDDP 電壓多重調整 • 溫度感應：CPU、機殼風扇 硬體顯示器 • 風扇轉速計：CPU、機殼風扇 • 靜音風扇（依 CPU 溫度自動調整機殼風扇速度）：CPU、機殼 風扇 • 風扇多重速度控制：CPU、機殼風扇 •...
- Page 80 • APU seri AMD Ryzen (Renoir) yang mendukung memori ECC & non-ECC, tanpa buffering DDR4 4733+(OC)/4666(OC)/ 4600(OC)/4533(OC)/4466(OC)/4400(OC)/4333(OC)/4266(OC)/ 4200(OC)/4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/ 3600(OC)/3466(OC)/3200/2933/2667/2400/2133* * Lihat Daftar Dukungan Memori di situs web ASRock untuk informasi selengkapnya. (http://www.asrock.com/) * Lihat halaman 21 untuk dukungan frekuensi maksimum DDR4 UDIMM. • Kapasitas maksimum memori sistem: 64GB • Mendukung modul memori Extreme Memory Profile (XMP)
- Page 81 A520M-HDV A520M-HVS Grafis • Grafis AMD Radeon Terpadu Seri Vega dalam APU Seri Ryzen* * Dukungan sebenarnya mungkin beragam berdasarkan CPU • DirectX 12, Pixel Shader 5.0 • Default memori bersama 2GB. Memori bersama maksimum mendukung hingga 16GB. * Memori bersama maksimum 16GB mengharuskan memori sistem 32GB terpasang.
- Page 82 • 1 x Soket Ultra M.2, mendukung modul M Key tipe 2242/2260/2280 M.2 SATA3 6,0 Gb/s dan modul M.2 PCI Express hingga Gen3 x4 (32 Gb/s)* * Mendukung SSD NVMe sebagai disk boot * Mendukung Kit U.2 ASRock Konektor • 1 x Header SPI TPM • 1 x Header Port COM • 1 x Intrusi Chassis dan Header Speaker...
- Page 83 A520M-HDV A520M-HVS • 1 x Konektor Daya ATX 24 pin • 1 x Konektor Daya 4 pin 12V • 1 x Konektor Audio Panel Depan • 2 x Header USB 2.0 (Mendukung 4 port USB 2.0) (Mendukung Perlindungan dari ESD) • 1 x Header USB 3.2 Gen1 (Mendukung 2 port USB 3.2 Gen1) (Mendukung Perlindungan dari ESD) Fitur BIOS...
-
Page 84: Contact Information
Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at http://www.asrock.com/support/tsd.asp... -
Page 85: Declaration Of Conformity
DECLARATION OF CONFORMITY Per FCC Part 2 Section 2.1077(a) Responsible Party Name: ASRock Incorporation Address: 13848 Magnolia Ave, Chino, CA91710 Phone/Fax No: +1-909-590-8308/+1-909-590-1026 hereby declares that the product Product Name : Motherboard A520M-HDV / A520M-HVS Model Number : Conforms to the following speci cations:... -
Page 86: Eu Declaration Of Conformity
EU Declaration of Conformity For the following equipment: Motherboard (Product Name) A520M-HDV / A520M-HVS / ASRock (Model Designation / Trade Name) ASRock Incorporation (Manufacturer Name) 2F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) (Manufacturer Address) EMC —Directive 2014/30/EU (from April 20th, 2016)
