InVid Tech Paramont PAR PTZ Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Paramont PTZs
User Manual: PAR PTZ Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Paramont PAR PTZ Series and is the answer not in the manual?

Questions and answers

Related Manuals for InVid Tech Paramont PAR PTZ Series

Summary of Contents for InVid Tech Paramont PAR PTZ Series

  • Page 1 Paramont PTZs User Manual: PAR PTZ Series...
  • Page 2 About This Manual This manual is provided for user reference only, without legal restraint. This manual is available for many models. Some functions introduced in the manual may be not available for some models. Please take the real models as the standard. This content of this manual is subject to change without prior notice, and the updates will be added into the new version of this manual.
  • Page 3 Notes on Safety  Please use the specified power supply to connect.  Do not attempt to disassemble the camera; in order to prevent electric shock, do not remove screws or covers.  There are no user-serviceable parts inside. Please contact the nearest service center as soon as possible if there is any failure.
  • Page 4 Disclaimer  With regard to the product with internet access, the use of product shall be wholly at your own risks. Our company shall be irresponsible for abnormal operation, privacy leakage or other damages resulting from cyber attack, hacker attack, virus inspection, or other internet security risks;...
  • Page 5 2012/19/EU (WEEE directive): The Directive on waste electrical and electronic equipment (WEEE Directive). To improve the environmental management of WEEE, the improvement of collection, treatment and recycling of electronics at the end of their life is essential. Therefore, the product marked with this symbol must be disposed of in a responsible manner.

  • Page 6: Table Of Contents

    Contents Network Connection ......................1 LAN ........................1 1.1.1 Access through IP-Tool ................1 1.1.2 Directly Access through IE ................ 3 WAN ........................5 Live View ........................8 Camera Configuration ....................11 System Configuration ................... 11 3.1.1 Basic Information ..................11 3.1.2 Date and Time Configuration ..............
  • Page 7 3.6.4 Onvif ......................55 3.6.5 DDNS Configuration ................56 3.6.6 SNMP ...................... 57 3.6.7 802.1X ..................... 58 3.6.8 RTSP ......................59 3.6.9 RTMP ...................... 60 3.6.10 UPnP ......................60 3.6.11 E-mail ...................... 61 3.6.12 FTP ......................61 3.6.13 HTTP POST .................... 63 3.6.14 HTTPS .....................

  • Page 8: Network Connection

    1 Network Connection System Requirement For proper operating the product, the following requirements should be met for your computer. Operating System: Windows 7 Home basic or higher CPU: 2.0GHz or higher RAM: 1G or higher Display: 1920*1080 resolution or higher (recommended) Web browser: IE (plug-in required)/ Firefox/Edge/Safari/Google Chrome It is recommended to use the latest version of these web browsers.
  • Page 9 The default IP address of the camera is 192.168.226.201. ③ Double click the IP address and then the system will pop up the IE browser to connect the device. After you read the privacy statement, check and click “Already Read”. Then activate the device.

  • Page 10: Directly Access Through Ie

    Please enter the user name (admin) and password. Then select the stream type and language as needed. Stream Type: The plug-in free live view only supports1080P or lower resolution. The security questions should be set after you click “Login” button. It is very important for you to reset your password.
  • Page 11 Gateway: 192.168.226.1 HTTP: 80 Data port: 9008 You may use the above default settings when you log in the camera for the first time. You may directly connect the camera to the computer through network cable. ① Set the IP address of the PC and make sure the network segment should be as the same as the default settings of the IP camera.

  • Page 12: Wan

    ② Open the IE browser and enter the default address of IP-CAM and confirm. ③ Follow directions to download and install the plug-in. ④ Enter the default username and password and then enter to view. 1.2 WAN  Access through the router or virtual server ①...
  • Page 13 ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera in the “Virtual Server”. Router Setup ④ Open the IE browser and enter its WAN IP and http port to access. ...
  • Page 14   ③ Go to Config Network DDNS menu. Before you configure the DDNS, please apply for a domain name first. Please refer to DDNS Configuration for detail information. ④ Open the IE browser and enter the domain name and http port to access. ...

  • Page 15: Live View

    2 Live View After you log in, you will see the following window. Plug-in free live view: when the main stream is set over 1080P, only the sub stream or third stream tab can be displayed on the above interface by default. The descriptions of the icon on the live view interface are as follows: Icon Description...
  • Page 16 Icon Description Icon Description Start/stop local recording Region entrance indicator Zoom in Region exiting indicator Zoom out Face detection indicator PTZ control Target counting indicator Face Detection SD card recording indicator Rule information display : Move the cursor to view the live image in all direction after you click this button. Additionally, hold and drag the left mouse button to zoom in the live image.
  • Page 17 Select preset and click to call the preset. Select and set the preset and then click to save the position of the preset. Select the set preset and click to delete it. Select cruise and click to start cruise.

  • Page 18: Camera Configuration

    3 Camera Configuration In the Webcam client, choose “Config” to go to the configuration interface. Note: Wherever applicable, click “Save” to save the settings. 3.1 System Configuration The “System configuration” includes four sub-menus: Basic Information, Date and Time, Local Config and SD Card. 3.1.1 Basic Information In the Basic Information interface, you can check the relative information of the device.

  • Page 19: Local Config

    Select the time zone and DST as required. Note: The time zone of the camera and the computer must be the same. It is recommended to modify the time zone of the camera according to the time zone of the computer. If the time zone of the computer is modified, the current web client needs to be closed.

  • Page 20: Storage

    3.1.4 Storage   Go to Config System Storage to go to the interface as shown below.  SD Card Management Click “Format” to format the SD card. All data will be cleared by clicking this button. Click “Eject” to stop writing data to SD card. Then the SD card can be ejected safely. Snapshot Quota: Set the capacity proportion of captured pictures on the SD card.
  • Page 21 Weekly schedule Set the alarm time from Monday to Sunday for a single week. Each day is divided in one hour increments. Green means scheduled. Blank means unscheduled. “Add”: Add the schedule for a special day. Drag the mouse to set the time on the timeline. “Erase”: Delete the schedule.

  • Page 22: Image Configuration

    Set the format, resolution and quality of the image saved on the SD card and the snapshot interval and quantity and the timing snapshot here. Snapshot Quantity: The number you set here is the maximum quantity of snapshots. The actual quantity of snapshots may be less than this number. Supposing the occurrence time of an alarm event is less than the time of capturing pictures, the actual quantity of snapshots is less than the set quantity of snapshots.
  • Page 23 Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Hue: Set the total color degree of the image. Saturation: Set the degree of color purity. The purer the color, the brighter the image is. Sharpness: Set the resolution level of the image plane and the sharpness level of the image edge.
  • Page 24 of the image in the darkest area will be seen clearly. Antiflicker:  Off: disables the anti-flicker function. This is used mostly in outdoor installations.  50Hz: reduces flicker in 50Hz lighting conditions.  60Hz: reduces flicker in 60Hz lighting conditions. White Balance: Adjust the color temperature according to the environment automatically.

  • Page 25: Video / Audio Configuration

    Drag “ ” icons to set the time of day and night. Blue means day time and blank means night time. If the current mode of camera parameters is set to schedule, the image configuration mode will automatically switch between day and night according to the schedule. 3.2.2 Video / Audio Configuration ...

  • Page 26: Osd Configuration

    Video Compression: MJPEG, H264+, H264, H265 or H265+ can be optional. MJPEG is not available for main stream. If H.265/H.265+is chosen, make sure the client system is able to decode H.265/H.265+. Compared to H.265, H.265+ saves more storage space with the same maximum bitrate in most scenes.

  • Page 27: Video Mask

    Set time stamp, device name, device status language, OSD content and picture overlap here. After enabling the corresponding display and entering the content, drag them to change their position. Then click “Save” to save the settings. Show Azimuth: Show the PTZ moving direction on the live view interface. Show Run Status: Show the PTZ control status on the live view interface.

  • Page 28: Ptz Configuration

    To delete mask area: 1. Select the mask area in the mask area list. 2. Click “Delete” to delete this mask area. 3.3 PTZ Configuration 3.3.1 PTZ and Password Setting  PTZ Setting   Go to Config Setting. This will let you see the following submenu. In this submenu, PTZ flip, PTZ flip, language, auto logout time can be set.

  • Page 29: Restore

    3.3.2 Restore It includes the function of reset and clear. Reset: Restore the camera state and active menu to the factory default settings but do not clear those parameters such as preset, cruise. Clear: Restore the camera to the factory default settings. 3.3.3 PTZ Function PTZ function includes preset setup, cruise setup, group setup, trace setup, task setup, alarm setup, home position setup and so on.
  • Page 30 ② Enter the ID and preset name as needed. Then click “OK”. ③ Set the position of the preset by clicking the direction buttons. Then click “Save Position”. After that, click “Call” to call the preset.  Cruise Setup In this interface, by programming presets in cruise list in advance, the system will keep calling those presets at the set time in sequence when executing cruise command so that non-stop monitoring between multiple important positions can be achieved.
  • Page 31 ④ Click “Start” to run the added cruise. The camera will automatically keep running according to the cruise you set until new command is received. ⑤ Click “Stop” to stop running the cruise.  Group Setup 8 cruises can be set in a group. Click “Add Cruise”...
  • Page 32 Click “Add” and then set the trace by clicking the direction/zoom/focus buttons. Each trace can record up to 180s. If the time exceeds 180s, the system will automatically save the operation data and return to the previous menu. In addition, 360 commands can be recorded for each trace at most.
  • Page 33 ① Click “Create” and then set the start time and the end time. ② Select the function and number. Then click “Add”. ③ After all tasks are added, click “OK” to save the settings. ④ The tasks will be automatically executed in chronological order by enabling “Run”. ...

  • Page 34: Alarm Configuration

    【Alarm Trigger】: Call the preset/cruise/trace/random scanning/boundary scanning you need. When the first alarm input happens, the camera will automatically switch to this preset/cruise/trace/ random scanning/boundary scanning to monitor. 【Alarm Over】:Call the preset/cruise/trace/random scanning/boundary scanning you need. When the alarm trigger is over, the camera will automatically switch to this preset/cruise/trace/random scanning/boundary scanning to monitor.
  • Page 35 1. Check “Enable” check box to activate motion based alarms. If unchecked, the camera will not send out any signals to trigger motion-based recording to the NVR or CMS, even if there is motion in the video. Alarm Holding Time: it refers to the time that the alarm extends for after an alarm ends. For instance, if the alarm holding time is set to 20 seconds, once the camera detects a motion, it will go to alarm and would not detect any other motion in 20 seconds.

  • Page 36: Exception Alarm

    2. Set motion detection area and sensitivity. Click the “Area and Sensitivity” tab to go to the interface as shown below. Move the “Sensitivity” scroll bar to set the sensitivity. Higher sensitivity value means that motion will be triggered more easily. Select “Add”...
  • Page 37 When there are some errors in writing SD card, the corresponding alarms will be triggered.    1. Go to Config Alarm Exception Alarm SD Card Error as shown below. 2. Click “Enable” and set the alarm holding time. 3.

  • Page 38: Alarm Input

    2. Click “Enable” and set the alarm holding time. 3. Trigger alarm out. When the camera is disconnected, the system will trigger the alarm out. Note: This function is only available for some models. 3.4.3 Alarm Input Only some models support this function. If your device doesn’t support it, please skip the following instructions.

  • Page 39: Alarm Out

    triggered. (Please set the warning voice first. See Audio Alarm for details). Note: Only some models support audio alarm function. If your device doesn’t support this function, please skip the instruction of “Trigger Audio Alarm”. Trigger Light Alarm: If selected, the light of the camera will turn on or flash when the sensor alarm is triggered.

  • Page 40: Alarm Server

    Day/Night Switch Linkage: Having selected this mode, select the alarm type and then choose to open or close alarm out when the camera switches to day mode or night mode. Timing: Select the alarm type. Then click “Add” and drag the mouse on the timeline to set the schedule of alarm out;...

  • Page 41: Audio Alarm

    3.4.6 Audio Alarm Only some models support this function. If your device doesn’t support this function, please skip the following instructions.  Go to Alarm Audio Alarm interface as shown below. 1. Select the warning voice. 2. Select the voice and then set the warning times and volume as needed. Warning times: it ranges from 1 to 50.
  • Page 42 automatically zoomed in and centered on the screen until the target disappears from the screen. After that, the PTZ camera will return to the tracking start position (home position). Tracking Mode: PTZ Auto Tracking Priority or Manual PTZ Control Priority can be optional.
  • Page 43 Using the PTZ control buttons (area①) sets appropriate field of view and then draw the detection area and save the setting. After that, click the “Lock” button to save the current PTZ position as the start tracking position (home position). Now, the “Lock” button changes its function to “Unlock”. Note: a.

  • Page 44: Event Configuration

    3.5 Event Configuration (Only some models support the following functions). For more accuracy, here are some recommendations for installation.  Cameras should be installed on stable surfaces, as vibrations can affect the accuracy of detection.  Avoid pointing the camera at the reflective surfaces (like shiny floors, mirrors, glass, lake surfaces and so on).
  • Page 45 1. Enable the applicable detection that’s desired. Scene Change Detection: Alarms will be triggered if the scene of the monitor video has changed. Video Blur Detection: Alarms will be triggered if the video becomes blurry. Abnormal Color Detection: Alarms will be triggered if the image is abnormal because of color deviation.

  • Page 46: Object Abandoned/Missing

    The sensitivity value of Video Blur Detection: The higher the value is, the more sensitive the system responds to the blurriness of the image. The sensitivity value of Abnormal Color Detection: The higher the value is, the more sensitive the system responds to the color shift of the image. 3.5.2 Object Abandoned/Missing Only some models support this function.

  • Page 47: Line Crossing Detection

    3. Click “Save” button to save the settings. 4. Set the alarm area of the abandoned/missing object detection. Click the “Area” tab to go to the interface as shown below. Set the alarm area number and then enter the desired alarm area name. Only one alarm area can be added.
  • Page 48  Detection Configuration: 1. Enable line crossing detection and select the snapshot type and the detection target. Save Original Picture to SD Card: If it is enabled, the detected original pictures will be captured and saved to the SD card when the targets cross the alarm line. Save Target Picture to SD Card: If it is enabled, the detected target cutout pictures will be captured and saved to the SD card when the targets cross the alarm line.
  • Page 49 crossing detection is enabled. 2. Set the alarm holding time. 3. Set alarm trigger options. Alarm Out: If selected, this would trigger an external relay output that is connected to the camera on detecting a target crossing the alarm line. Trigger Audio Alarm: If selected, the warning voice will be uttered when the sensor alarm is triggered.

  • Page 50: Region Intrusion

    Direction：A<->B, A->B and A<-B optional. This indicates the direction of someone or a vehicle crossing over the alarm line. A<->B: Alarms will be triggered when someone or a vehicle crosses over the alarm line from B to A or from A to B. A->B: Alarms will be triggered when someone or a vehicle crosses over the alarm line from A to B.
  • Page 51  Detection Configuration Enable region intrusion detection, select the snapshot type and the detection target and set the alarm holding time and alarm trigger options. The detection setup steps are the same as line crossing detection. Please refer to the detection configuration of line crossing detection for details.

  • Page 52: Region Entrance

    2. Set the alarm area number on the right side. Up to 4 alarm areas can be added. 3. Set the detection area by clicking the buttons of area ① and then click “Lock” to lock the area. Note: The PTZ will not be controlled if you click “Lock” here. Click “Unlock” and then click the buttons of area ①...
  • Page 53 2. Enable target counting by line and select the snapshot type and the detection target. Detection Target: Select the target to calculate. Human, motor vehicle and motorcycle/bicycle can be selected. Staying Threshold: When the targets (human/vehicle) staying in the specified area exceed the threshold, alarms will be triggered.
  • Page 54 Set the alarm line number and direction. Only one alarm line can be added. Direction：A->B and A<-B can be optional. The direction of the arrow is entrance. Statistics: If enabled, you can see the statistical information in the live view interface. If disabled, the statistical information will not be displayed in the live view interface.

  • Page 55: Face Comparison

    7. View the statistical information of target counting by line. Click “Statistics” to enter the following interface. Select the report type. Daily report, weekly report, monthly report and annual report are selectable. Select the count type. Enter or leave can be optional. Select the start time and then click “Count”.
  • Page 56 2. Enable the face detection function. Save Source Information to SD Card: if checked, the whole picture will be saved to the local PC or SD card when detecting a face. Save Face Information to SD Card: if checked, the captured face picture will be saved to the local PC or SD card when detecting a face.
  • Page 57 5. Face database management: click “Face Database Management” tab. This will enter the following interface. There are four ways to add face pictures. Adding face pictures one by one Click to pop up an adding user box. Then click to select a face picture saved on the local PC.
  • Page 58 Similarity threshold: When the similarity of the captured face picture and the face picture added into the face database exceeds the similarity threshold, alarms will be triggered. Push Stranger: Push the comparison alarm information of the stranger. After it is enabled, the comparison information of the stranger will be shown on the left comparison area of the live interface.
  • Page 59 same target once every 5 seconds until the target disappears in the detected area. Proximity Priority Comparison: When several persons are in the recognition area at the same time, the person closer to the camera is recognized first. Comparison in free time: When the processor is busy, the comparison of the current detected person will not be performed immediately (for example, there is not enough time for the processor to perform all comparisons, because so many people are detected at the same time).

  • Page 60: Network Configuration

     Add captured face pictures to the face database Click a captured picture in area ①. This will bring a face picture adding box. Fill out the relevant information and click “Entry” to add this face picture. 3.6 Network Configuration 3.6.1 TCP/IPv4 Go to ConfigNetworkTCP/IP interface as shown below.

  • Page 61: Port

    Either method of network connection can be used. If PPPoE is used to connect internet, the camera will get a dynamic WAN IP address. This IP address will change frequently. To be notified, the IP change notification function can be used. Click “IP Change Notification Config”...

  • Page 62: Server Configuration

    Persistent Connection Port: The port is used for a persistent connection of the third-party platform to push smart data, like face pictures. WebSocket Port: Communication protocol port for plug-in free preview. 3.6.3 Server Configuration This function is mainly used for connecting network video management system. 1.

  • Page 63: Ddns Configuration

    Note: when adding the device to the third-party platform with ONVIF/RTSP protocol, please use the onvif user in the above interface. 3.6.5 DDNS Configuration If the camera is set up with a DHCP connection, DDNS should be set for the internet. ...

  • Page 64: Snmp

    Create domain name. After the domain name is successfully applied for, the domain name will be listed as below. 3. Enter the username, password, domain you apply for in the DDNS configuration interface. 4. Click “Save” to save the settings. 3.6.6 SNMP To get camera status, parameters and alarm information and remotely manage the camera, the SNMP function can be used.

  • Page 65: 802.1X

    2. Check the corresponding version checkbox (Enable SNMPv1, Enable SNMPv2, Enable SNMPv3) according to the version of the SNMP software that will be used. 3. Set the values for “Read SNMP Community”, “Write SNMP Community”, “Trap Address”, “Trap Port” and so on. Please make sure the settings are the same as that of the SNMP software. Note: Please use the different version in accordance with the security level you required.

  • Page 66: Rtsp

    To use this function, the camera shall be connected to a switch supporting 802.1x protocol. The switch can be reckoned as an authentication system to identify the device in a local network. If the camera connected to the network interface of the switch has passed the authentication of the switch, it can be accessed via the local network.

  • Page 67: Rtmp

    Audio: Having entered the main/sub stream in a VLC player, the video and audio will play automatically. If “Allow anonymous login…” is checked, there is no need to enter the username and password to view the video. If “auto start” is enabled, the multicast received data should be added into a VLC player to play the video.

  • Page 68: E-Mail

    3.6.11 E-mail If you need to trigger Email when an alarm happens or IP address is changed, please set the Email here first.   Go to Config Network Email. Sender Address: sender’s e-mail address. User name and password: sender’s user name and password (you don’t have to enter the username and password if “Anonymous Login”...
  • Page 69 2. Click “Add” to add the information of the FTP. After that, click “Save” to save the settings. Server Name: The name of the FTP server. Server Address: The IP address or domain name of the FTP. Upload Path: The directory where files will be uploaded to. Port: The port of the FTP server.

  • Page 70: Http Post

    File Name Event Type IP address change MOTION Motion Detection SENSOR Sensor Alarm Object Abandoned/Missing TRIPWIRE Line Crossing Detection PERIMETER Region Intrusion Detection Video Exception Face Detection AOIENTRY Region Entrance AOILEAVE Region Exiting PASSLINECOUNT Target Counting by Line SDFULL SD Full SDERROR SD Error TXT file content:...

  • Page 71: Https

    interface. After the camera is successfully connected, it will send the alarm information (HTTP format) to the third-party platform once the smart alarm is triggered. The alarm information includes target tracing coordinates, target features, the captured original/target image (like the captured face picture, motor vehicle picture) and so on.

  • Page 72: Qos

    Click “Create” to create a private certificate. Enter the country (only two letters available), domain (camera’s IP address/domain), validity date, password, province/state, region and so on. Then click “OK” to save the settings. * Click “Create a certificate request” to enter the following interface. Click “Create”...
  • Page 73 Add user: 1. Click the “Add” button to pop up the following textbox. 2. Enter user name in the “User Name” textbox. 3. Enter the password in the “Password” and “Confirm Password” textbox. Please set the password according to the requirement of the password security level (Go to ...

  • Page 74: Online Video User

    3. Enter the old password of the user in the “Old Password” text box. 4. Enter the new password in the “New password” and “Confirm Password” text box. 5. Select the user permissions for advanced or normal user. 6. Click the “OK” button to save the settings. Note: When the password level is set to “Strong”, the password cannot be set the same as the previous five.

  • Page 75: Block And Allow Lists

    An administrator user can kick out all the other users (including other administrators). 3.7.3 Block and Allow Lists   Go to Config Security Block and Allow Lists as shown below. The setup steps are as follows: Check the “Enable address filtering” check box. Select “Block/Allow the following address”, IPv4/IPv6 and then enter IP address in the address box and click the “Add”...

  • Page 76: Maintenance

    Please set the password level and expiration time as needed. Password Level: Weak, Medium or Strong. Weak level: Numbers, special characters, upper or lower case letters can be used. You can choose one of them or any combination of them when setting the password. Medium Level: 8~16 characters, including at least two of the following categories: numbers, special characters, upper case letters and lower case letters.

  • Page 77: Reboot Device

     Import & Export Settings Configuration settings of the camera can be exported form a camera into another camera. 1. Click “Browse” to select the save path for import or export information on the PC. 2. Click the “Import Setting” or “Export Setting” button. ...
  • Page 78 2. Select the main type, sub type, start and end time. 3. Click “Query” to view the operation log. 4. Click “Export” to export the operation log.

  • Page 79: Playback

    4 Playback 4.1 Image Search Click Search to go to the interface as shown below. Images that are saved on the SD card can be found here. Note: When using the plug-in free browser, the local images cannot be searched. ...
  • Page 80 Note: When using the plug-in free browser, the local images cannot be searched.  SD Card Image Search Choose “Picture”—“SD Card”. Set time: Select date and choose the start and end time. Choose the alarm events at the bottom of the interface. Click to search the images.

  • Page 81: Video Search

    4.2 Video Search 4.2.1 Local Video Search Click Search to go to the interface as shown below. Videos were recorded locally to the PC can be played in this interface. Note: When using the plug-in free browser, the local videos cannot be searched. Choose “Record”—“Local”.

  • Page 82: Sd Card Video Search

    Icon Description Icon Description Play button. After pausing the video, click this button Pause button to continue playing. Stop button Speed down Speed up Watermark display Enable / disable audio; drag the slider to adjust the volume after enabling audio. Note: When using the plug-in free browser, the local videos cannot be searched.
  • Page 83 Note: cannot be displayed in the above interface via the plug-in free browser. Additionally, for plug-in free playback, playback mode switch (balanced/real-time/fluent mode) and downloading functions are not supported too. The time table can be shown in 24H/12H/2H/1H format by clicking the corresponding buttons.

  • Page 84: Face Match Result Search

    5 Face Match Result Search Click “Face Log” tab to go to the face recognition result search interface. Set the start time and end time and click “Search” to view the face recognition result. A photo of each recognized face is marked with a colored bar. The red color of the bar means no comparison result.
  • Page 85 & & & 6 Q & A 1. Q: I forget the password. How can I do? Reset the system to the factory default setting or contact the dealer. Default IP: 192.168.226.201 User name: admin Password: 123456 2. Q：The devices can’t connect through IE browser. Why? Network is not connected well.
  • Page 86 & & & Fig 4-1 Fig 4-2 Then click OK to finish setup. Other plug-ins or anti-virus blocks ActiveX. Please uninstall or close them. 5. Q：Why does the device fail to sound? The audio input device is not connected. Please connect and try again. The audio function is not enabled at the corresponding channel.

  • Page 87: Appendix Preset Description

    Appendix Preset Description Call NO.90 Preset Run trace 1 Call NO.91 Preset Run cruise 1 Call NO.92 Preset Run cruise 2 Call NO.93 Preset Run cruise 3 Call Preset Call NO.94 Preset Run cruise 4 Call NO.97 Preset Enable random scan Call NO.99 Preset Enable auto scan Call NO.100 Preset...
