Page 3
TV screen. These types of imprints are not covered by your warranty because they are the results of misuse. ® Sony, FD Trinitron, WEGA , Steady Sound, ClearEdgeVM and Intelligent Picture are Sony Corporation's trademarks.
Page 4
User Guide IMPORTANT SAFEGUARDS Object and Liquid Entry Never push objects of any kind into the set through the cabinet slots as they may touch For your protection, please read these instructions dangerous voltage points or short out parts completely, and keep this manual for future reference. that could result in a fire or electric shock.
Page 5
Connecting Additional Equipment ❏ ❏ Never block the slots and openings by When the power cord or plug is placing the set on a bed, sofa, rug or damaged or frayed. other similar surface. ❏ If liquid has been spilled into the set ❏...
Contents Introduction ........................1 About this Manual .......................... 1 Batteries for the Remote Control ....................1 TV Front Panel..........................1 Using the Remote Control ....................2 Remote Control Description......................2 Connecting your TV ......................3 TV Rear Panel ..........................3 Basic Connections ...........................
Introduction ® Congratulations on your purchase of the Sony FD Trinitron WEGA About this Manual This manual provides instructions to help you enjoy your new TV. It shows you how to connect to an antenna or cable, Radio FM antenna, VCR, DVD or satellite receiver. Once your TV is connected, follow the instructions and use the remote control to access the on-screen menus.
Using the Remote Control Remote Control Description Button Description 1 MUTING Press to turn off the sound. Press again or press restore the sound. MUTING POWER DISPLAY 2 DISPLAY Press once to display the channel number, the channel label (if set) and the status of the stereo mode. PICTURE MODE TV/VIDEO...
Connecting your TV Read this section before setting up your TV for the first time. This section covers basic connections in additions to any optional equipment you may be connecting. TV Rear Panel VIDEO 3 IN MONITOR OUT VIDEO 1 IN VIDEO VIDEO (MONO) L...
TV with FM Radio Antenna To improve the FM Radio frequency in your TV, use the connection below: From Cable/ Radio FM Antenna antenna Antenna selector (not supplied) Rear of TV VIDEO 1 IN VIDEO 3 IN MONITOR OUT VIDEO VIDEO (MONO) L L (MONO)
Page 11
Connecting a TV and VCR Connect the coaxial cable from your TV antenna or cable service to the IN jack on your VCR. Connect a coaxial cable (not supplied) from the OUT jack on your VCR to the VHF/UHF jack on the Coaxial cable (not supplied) Rear of TV...
Using Basic Functions Setting Up the TV After you have finished connecting your TV, use Auto Program to set up your analog and digital channel lists. During Auto Program, the TV will automatically search for available channels and program receivable channels. Initial Setup Initial Setup Language:...
Introducing the WEGA GATE Navigator WEGA GATE is a gateway that allows you to access to preset list of Favorites channels, TV channels, connected external inputs, listening FM Radio and “Settings”. WEGA GATE Favorite Channels To select a list of Favorite Favorites Channels "Favorites"...
Listening to the FM Radio You are able to listen to the FM Radio stations using your TV. To Access to FM Radio Mode: WEGA GATE Press and select "FM Radio", or Press FM button on the front control panel (see page 1). To Exit From FM Radio Mode: WEGA GATE Press...
Using the Picture Menu Picture Picture Adjustment Picture Mode: Vivid Picture Picture Adjustment Brightness Color Temperature: Cool Color High Intelligent Picture: Sharpness Signal Level Indicator: Move Select Move Select WEGA GATE WEGA GATE Press v to highlight an option; then press Picture Mode Use the V or v buttons to highlight one of the following options, then press Customized picture...
Using the Channel Setup Menu Press v to highlight an option; then press Channel Setup Favorite Channels Cable: Auto Program Channel Edit FM Radio Setup Move Select WEGA GATE Favorite Press V or v to highlight the position (1 to 8) where you want to set a favorite Channels channel, then press Quick access to...
FM Radio Setup Preset up to nine FM radio stations. You can manually preset FM radio stations that can be received in your area and then store the radio frequency of the desired FM radio stations. Press V or v to select the desired FM radio station position, then press Press V or v to search the FM radio stations.
Using the Setup Menu Press v to highlight an option; then press Setup Mover Seleccionar Salir Language: English Closed Captions (CC): Info Banner: Video Label Wake-up Timer: Move Select WEGA GATE Language Display all menus in the language of your choice. Use the V or v buttons to select from one of the following options: English and Español (Spanish).
❏ I lost the remote You can use the buttons on the front panel to access the menus (page 1). control. Contact your local Sony authorized dealer to request a replacement. Picture ❏ No picture, no Make sure the power cord is pluged in.
Page 21
Perform Auto Program to add channels that are not presently in the memory (page 6). If after reading this instruction manual you have more questions about the use of your Sony television, contact your local Sony authorized dealer to get technical assistance or visit our internet page http://www.sony.net/.
Specifications Television System American TV standard/NTSC Channel Coverage VHF: 2-13/UHF: 14-69/CATV: 1-125 ® Picture tube FD Trinitron tube Power Requirements 120 V AC, 60 Hz Accessories included 2 AA batteries 1 Remote control RM-YA005 Inputs 1 video, 1 audio (front panel) 1 S VIDEO (rear panel) 1 YP 1 audio (rear panel)
Index 0-9 buttons 16:9 Enhanced Language Auto Program Menus Channel Setup Parental Control Balance Picture Basic Connections Setup Antenna and cable Sound FM Radio Antenna Brightness Auto SAP Mono Cable Stereo CC (Subtitles) Channel Edit Picture Mode Closed Captions (CC) Custom Color Standard...
Page 24
Operating Instructions Printed in the U.S.A. http://www.sony.net...
