  • Page 2: Table Of Contents

    Samsung reserves the right to alter this doc-ument or the product described herein at anytime, without obligation to provide notification of such...
  • Page 3 This Service Manual is a property of Samsung Electronics Co.,Ltd. ⓒ Samsung Electronics Co.,Ltd Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2021. 01. Rev 1.1...
  • Page 4 7. Level 2 Repair 7-1. Components on the Rear Case Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 5 AOD for Tablet Ethyl Alcohol Cotton Swab Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 6 [GH81-20354A] disassemble the Back glass. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 7 Be careful not to damage the PBA. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 8 Be careful not to damage the Motor. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 9 2) Be careful not to damage the PBA Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 10 Be care of damage each part. 2) Check for each connector connection. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 11 Be care of damage each part. Be care of scratch Rear cover. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 12 QCR205 QBC01 ※ SVC REPAIR TAPE QRT01 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 13 QCR205 QBC01 ※ SVC REPAIR TAPE QRT01 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 14 MAIN PBA (TOP SIDE) MAIN PBA (BOTTOM SIDE) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 15 SUB PBA (TOP SIDE) SUB PBA (BOTTOM SIDE) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 16 Confidential SM-E625F/M625F SM-E625F BlockDiagram Common WIFI PCIe MainMic WLAN UART CODEC I2S BT/Wi-Fi Sub Mic 32.768kHz CLK (SWB-E43) BT UART (MUSIC) CODEC SPI from AP/CP PMIC Ear Mic BT PCM (VOICE) Audio Codec CODEC CLK 26MHz EAR OUT L/R (CS47L93)
  • Page 17 SM-E625F/M625F C2022 ANT2000 ANT2002 C2004 L2008 L2007 Common C2024 L2006 C2002 C2029 R2016 L2009 C3000 C3055 U3010 R3022 R3023 R3018 R3005 C3018 L3012 U3002 OSC3000 R3021 C3058 L3026 C2043 L3024 C3046 C3049 C3029 F3001 R4060 C3063 L3011 U3011 L3022 L3025...
  • Page 18 ANT7001 SM-E625F/M625F C2028 L2014 L2012 L2013 C2035 C2037 Common C2038 ZD7002 L2011 C2036 ANT1003 ANT1002 C3057 C3072 C7042 C3059 U3009 L7003 C3061 C3064 ZD7001 C3054 L3018 R3012 ZD7000 C7002 C2027 C2023 C2000 C3052 TA6001 L3015 R3013 R3014 C8044 U6005 C3036...
  • Page 19 + driver, ESD Safe Tweezer 8960 & Spectrum Analyzer Soldering iron Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 20 AP_PS_HOLD(TP6006) = 1.8V U6000/U6003 Check the initial operation Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 21 Check the U6000/U6003 (Crack etc) Normal Change UCP4000 Abnormal Change PBA Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 22 Is the frequency 38.4 ㎒? Replace the U2009 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 23 (SIM2 : TP7019 ,R7009, TP7020) Is signal ok? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 24 Check the UCP4000 (Crack etc) Is signal ok? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 25 VBUS_IF(C6139)=5V or 9V Battery is Charging? Replace U6002 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 26 Check OTG working ? Replace SUB PBA Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 27 Check R3019, R3020 Replace U3010 (I2C is OK?) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 28 Replace U3007 TP3053, TP3034 (SPI is OK?) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 29 (SPI is OK?) Replace the Fingerprint sensor module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 30 Check U3008 Replace U3008 (Crack, Damaged, etc) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 31 Check the MAIN_MIC_P data Replace SUB PBA at C7026 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 32 Check the SUB_MIC_P Replace MIC7000 data at L7000 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 33 Replace SUB PBA ANT9005,ANT9006 in SUB Replace speaker module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 34 Resolder or replace L7003, L7004 L7003, L7004 Replace RCV module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 35 (open, crack etc) Resolder or change U3002 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 36 (open, crack etc) Resolder or replace U3011 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 37 Check UCP4000 TP3004 Resolder or Replace U3001 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 38 MAIN PBA Resolder or Replace U3003 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 39 And replace(If there are problem) Replace the Display module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 40 26MHz (C8002, C8016, C8019, C8026) Replace the camera module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 41 26MHz (C8008) Replace the Front camera module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 42 Check C6134 = 3.3V? U6000 (crack,open,etc) Replace Motor Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 43 (Crack, open, etc), is it ok? Change the board Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 44 (Crack, open, etc), is it ok? Change the board Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 45 (Crack, open, etc), is it ok? Change the board Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 46 (Crack, open, etc), is it ok? Change the board Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 47 Resolder or change Change the board TX path components Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 48: Safety Precautions

    Always use the replacement parts that are registered in the SEC system. Third-party replacement parts may not function properly. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 49 Increase the airflow to the working area to decrease the chance of accidental static electricity discharges. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 50: Specification

    -102dBm -100dBm -100dBm 10MHz) (dBm) TDMA Mux Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 51 2±5 dBm 2±5 dBm 0±5 dBm 0±5 dBm Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 52 -104dBm -106dBm -104dBm -103dBm BW 10MHz) (dBm) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 53 Sensitivity (QPSK, BW -94.3 -94.3 -93.3 -93.3 10MHz) (dBm) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 54 Sensitivity (QPSK, BW -95.8 -95.5 -95.5 -95.5 10MHz) (dBm) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 55: Product Function

    Accelerometer, Fingerprint Sensor, Gyro Sensor, Geomagnetic Sensor, RGB Light Sensor, Sensor Proximity Sensor Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 56: Level 1 Repair

    Data Cable : GH39-02028A GH39-02028C (Only for E625F_SWA) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 57: Level 2 Repair

    ※You need to reset the ID information in case of PC change and format and repair, hard disk change. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 58: Level 3 Repair

    4) Connect the device to PC via data cable. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 59 (This is known as “Service Connection” history) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 60 Do not disconnect the device from USB during processing. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 61 Click Ok and detach device from USB. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 62 Data Cable : GH39-02028A GH39-02028C (Only for E625F_SWA) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 63 Open up the S/W Installation Program by executing the Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 64 * Note : "Odin v3.14.4 or above" checks MD5 checksum just after file selection. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 65 - Press volume up button after ‘Warning’ message and ‘Downloading’ message is displayed. Volume Up Volume Down USB Cable Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 66 The device is now connected with the PC and ready to download the binary files in it. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 67 : Please check with the separate notice file about IMEI Guide. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 68: Reference Abbreviation

    ― TDM : Time Division Multiplexing ― TS : Transport Stream Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

This manual is also suitable for:

Sm-m625f
