SMC Networks SMCRPUPOE Specifications

Power Unit
OVERVIEW
Redundant power units provide an easy to
install and use method of giving you the peace
of mind required when managing safety tolerant
systems.
This Redundant Power Unit (SMCRPUPOE) can
supply 200W of primary power and up to 360W
for PoE devices in the event of AC loss or failure
of the internal power supply of the 1st attached
device to fail. It ships with four DC Backup
Power Cords included (IEC connectors). Thermal
overload protection prevents the RPU from
overheating if a thermal overload occurs. Over-
FEATURES
Connects to up to four switches with cables included
Thermal overload protection
Supplies both the switch and PoE devices with power up to 560W.
Over-voltage protection for each output channel
Over-current protection
Short-circuit protection against output channels
www.smc.com
SMCRPUPOE
4 4 P P o o r r t t R R e e d d u u n n d d a a n n t t P P o o w w e e r r U U n n i i t t
voltage protection shuts down an output channel
if the voltage exceeds a preset threshold where
as over-current protection shuts down the RPU
if the output load exceeds a preset threshold.
Short-circuit protection prevents the RPU from
being damaged from a short circuit on any out-
put channel. Four status indicators for Link,
Activity, Fan, Thermal, and Power are located on
the RPUs front panel. While the AC supply and
DC backup sockets are located on the RPUs rear
panel. The SMCRPUPOE can be mounted in a
standard 19-inch equipment rack(brackets
included) or on a flat surface.
