Summary of Contents for S.M.S.L Dp5
- Page 1 说明书 MANUAL 本说明书的内容可能会随版本更改, 如有变动, 恕不另行通知 ver 1.0...
-
Page 2: Safety Notes
Safety Notes CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT REMOVE COVER (OR BACK) The lightning flash with arrowhead symbol,with in an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... - Page 3 Feature Supports audio format of DSD , WAV , APE , FLAC , AIFF , MP3 Etc. Fully supports MQA decoding including local playback and USB DAC. Several output op�ons: USB , coaxial , I S , AES/EBU , Single-ended analog, balanced analog, headphone 6.35mm.
- Page 4 Specifica�ons Input mode: USBx2 / USB Audio / micro SD / Bluetooth DLNA/ SAMBA(NAS) Output mode: Line / balanced / headphone / op�cal fiber / coaxial / AES / Bluetooth USB / USB out / I S THD+N： 0.00015% Dynamic range: 130dB（A-Weighted）...
- Page 5 Specifica�ons DSD DOP: Top support DSD 256 DSD Native: Top support DSD 256 Digital outputDOP output: Top support for DSD64 PCM: Top support 384kHz File system: Support FAT/FAT32/NTFS micro SD Capacity of card: Top support 256G USB drive/Hard disk: Top support 4T USB Maximum output current: 2A(The sum of two USB output currents) USB A maximum output current: 2A...
- Page 6 Formats Sampling rate* Format Support Level Bit width Remarks √ √ Fast 384K 16-24bit √ √ Normal 384K 16-24bit √ APE** High 384K 16-24bit 176/192K √ Extra high 16-24bit Nonsupport × Insane √ √ 384K 16-32bit not support √ 16-24bit √...
-
Page 7: Remote Control
ON/OFF Mute VOL UP Note Play/Pause/Ok Next 1.Press “ B ” first , when using DP5 for Previous the first �me! VOL Down 2. In any interface during music playback, Func�on bu�on long press the func�on key to return to Return/exit the "... - Page 8 Parts names and func�ons Display screen AES output Power bu�on, long press ON / OFF, Line output short press turn off display. Balance output "Previous" bu�on, short press the previous Micro SD card slot song, long press to rewind. Power AC input Play / pause Network interface "Next"...
- Page 9 Connec�ng your equipment Connect headphone and ac�ve speakers. Ac�ve Speaker...
- Page 10 Connec�ng your equipment Router...
- Page 11 Device Connec�on” is displayed, and at the same �me, the digital signal is output from this USB interface, and the other output of the DP5 are silent. When unplugged, “Audio Device Disconnect” is displayed, and the original output is restored.
- Page 12 Connec�ng your equipment wall outlet with grounding Note: Please use a power outlet with a good grounding wire to ensure safety and avoid noise. The power state of SD-9 has memory Without use the button to shut down, directly unplug the power ord, the next plug will directly boot;...
-
Page 13: Main Interface
Display 1.Main interface HiBy Link Playback/pause Current page Bluetooth volume Output mode Playback mode WIFI My Music Playback Now Playing se�ngs My music System setup music sources Network setup 2.Playback interface Sampling rate File format bit width MQA Studio 352.8kHz/24Bit Song name How Long Blues Singer... -
Page 14: Music Library
Operation: "Multifunction knob":In playlists，long press knob to delete a song. Please pay attention: The maximum number of DP5 song scans is 30,000, and it will not be scanned after exceeding. (Note: the "function key" of the remote control is the same as the machine... -
Page 15: Playback Menu
Display 4. File browsing interface The contents of the file browsing menu are: File Browser 1.Micro SD card . SD Card 2.LAN. 3.OTG-1. 4.OTG-2. OTG_1 5.USB-DAC. OTG_2 6.DLNA USB DAC 7.AirPlay 8.Bluetooth DLNA AirPlay Opera�on: BLUETOOTH "Mul�func�on knob": long press to Delete files . 5. - Page 16 SD card.) 2. Update music: Click start scan I S inverting D 2P memory devices connected to Fixed sample rate output DP5. 3. Output mode: DSD Output Mode headphone output USB Mode Line output. （Digital output is not affected）...
- Page 17 Display 7.B-type USB mode： The B-type USB interface is set to “USB mode”. The unit is connected to the computer through the B-type USB interface to access and modify the micro SD card data of the machine. Please pop up before disconnec�ng. Please Eject Before Disconnecting USB Connected The B-type USB interface is set to “DAC mode”, the B-type USB interface...
- Page 18 1.Bluetooth 1.1、HiBy Link: The HiBy Link func�on in the mobile device opens the HiBy player and docks with Dp5. The mobile device can browse the storage device in the unit and can be used as a Bluetooth remote controller. (Note: When using Bluetooth to input audio, be sure to turn off the HiBy Link of the...
- Page 19 Display 1.2、High sound quality: Using advanced algorithms, the sound quality of Bluetooth transmission is improved. 1.3、Bluetooth scanning: Scan nearby devices that can connect to Bluetooth, you can choose to connect devices. Select the connected device and press and hold the “Mul�-Func�on Middle Bu�on” to delete the pairing. 2.WiFi: Select "searching Wifi"...
- Page 20 Search for Serve r MUSI C BOX 3. DLNA: Dp5 connects to the network, the mobile device installs and opens “Bubble UPnP”, plays the song, pull the playback layout to the right, and selects to push to play on “SMSL DP5”.
- Page 21 Select “ SMSL DP5 ” 4.AirPlay: As long as the DP5 is connected to the same local area network with your iOS device (iPhone、 iPod、 iTouch、 iPad or iTunes), it will appear in the AirPlay device list. You can simply send the audio stream to DP5 by selec�ng it.
- Page 22 MQA (Master Quality Authen�cated) is an award-winning Bri�sh technology that delivers the sound of the original master recording. The master MQA file is fully authen�cated and is small enough to stream or download. The DP5 includes MQA technology, which enables you to playback MQA audio files and streams, delivering the sound of the original master recording.
-
Page 23: Warranty Terms
S.M.S.L(e.g. counterfeits). 4.Sending it back to our company for repairing. 5.Contact your S.M.S.L Audio reseller for a Return or replacement. Foshan Shuangmusanlin Technology Co., Ltd. Address: Rm302, 32th Building, Zhifu Industrial Park, Erhuan Rd,...
