- Page 1 User’s Manual Networking Control Board Model Number CB-6970 VIA® C7 /Eden Networking Control Board with Four 100/10 LAN User’s Manual Version 1.1 ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 2 For more information on CB-6970 or other AEWIN products, please visit our website http://www.aewin.com.tw. For technical supports or free catalog, please send your inquiry to info@aewin.com.tw ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 3: Table Of Contents
4.2 System Driver Installation ................34 4.3 LAN Driver Installation ................38 4.4 RAID Driver Installation ................42 4.5 VGA Driver Installation................46 Appendix A: Programming the Watchdog Timer ............ 47 ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 4 User’s Manual Appendix B: Optional LAN Module................. 49 Appendix C: Optional Cable List ................49 ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 5: Chapter 1. General Information
Operating temperature: 32 to 140 ℉ （0 to 60℃） Board size: 8”(L) x 5.75”(W) (203mm x 146mm) 1.3 Order Information We offer various combination of CB-6970 control board according to CPU speed, ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 6: Package
Electrostatic discharge can be easily damage the CB-6970 control board. Do not remove the anti-static packing until you are ready to install the CB-6970 ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 7 To ground yourself, grasp the expansion slot covers or other unpainted parts of the computer chassis. Handle the CB-6970 control board by its edges and avoid touching the components on it. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 8: Board Layout
Mini PCI Socket C7/Eden CPU HDD Power CN700 System Fan SATA Connectors DDR2 Socket GPIO LAN LED System Power Bypass LAN LED * 8 CPU Fan Power 1.7 Board Dimension ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 9: Chapter 2. Connector/Jumper Configuration
CN10 COM Port Pin Header BY PASS Mode Select CN11 USB Pin Header CF Master/Slave Select CN12 VGA Pin-header (2mm) Clear CMOS CN13 KB/MS Pin-header CPU FSB Select ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 10: Onboard Processor
Define Define Reset # Chassis Ground Chassis Ground Chassis Ground Chassis Ground D1 :Link/Activity LED Link YELLOW Activity BLINKING D2: Speed indicated LED 10 Mbps 100 Mbps GREEN ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 11 CN10: COM Port Pin Header CN12: VGA Pin Header Define Define DCD# DSR# Define Define RXD# RTS# Green TXD# CTS# Blue DTR# RI#2 Ground DCC DATA HSYNC VSYNC DCC CLOCK ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 12 3.3VAUX WIP4 CLK1 RST# AD[01] 100 RESERVED_ 3.3V WIP4 REG#0 GNT#0 101 GND 102 GND 3.3V 103 AC_SYNC 104 M66EN AD{31} PME# 105 AC_SDATA_IN 106 AC_SDATA_ AD{29} CLK2 ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 13 Define Define +12V SPEED0 ACTIVE0 LINK0 SPEED1 CN16, 19, 20, 21: Fan Connector ACTIVE1 LINK1 SPEED2 ACTIVE2 LINK2 SPEED3 ACTIVE3 LINK3 CN23: Manufacturing Default Using Setting by manufacturer. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 14 JP2: Bypass Mode Select Setting Bypass Always Enabled Normal (Default) JP3: CF Master/Slave Select Setting Close Master Open Slave JP4: Clear CMOS Setting Hold Data (Default) Clear CMOS ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 15: Compactflash Socket Pin Assignment
15 Ground 35 IOW 16 Ground 36 WE 17 Ground 37 RDY/BSY Ground 18 A02 38 VCC Ground 19 A01 39 SCSE Ground 20 A00 40 NC Ground ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 16: Chapter 3. Bios Setup
3. In the main menu, press F10 (“Save & Exit Setup”) to save your changes and reboot the system. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 17: Entering The Cmos Setup Program
1. Turn on or reboot the system. After the BIOS performs a series of diagnostic checks, the following message appears: “Press DEL to enter SETUP” 2. Press the <DEL> key to enter CMOS Setup program. The main menu appears: ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 18: Menu Options
Configure the CPU speed and, if the optional system monitor IC is installed, view system information FREQUENCY / VOLTAGE CONTROL: Configure the CPU and PCI clock, if the optional system monitor IC is installed, view system information ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 19: Standard Cmos Features Setup
1. Choose “Standard CMOS Features” from the main menu. The following screen appears: 2. Use the arrow keys to move between fields. Modify the selected field using the ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 20: Advanced Bios Features Setup
3.5 Advanced BIOS Features Setup Use the Advanced BIOS Features Setup option as follows: 1. Choose “Advanced BIOS Features Setup” from the main menu. The following screen appears: ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 21 Normal: Select Keyboard controller to control Gate Typematic Rate Setting The rate to click the keyboard is defined by keyboard controller. When enabled, you can configure the Typematic Rate and Typematic ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 22: Advanced Chipset Features Setup
3.6 Advanced Chipset Features Setup Use the Advanced Chipset Features Setup option as follows: 1. Choose “Advanced Chipset Features Setup” from the main menu. The following screen appears; ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 23 BIOS at F0000h-FFFFFh, enhancing system performance. However, if any program writes to this memory area, a system error may result. Video RAM Cacheable Select Enabled or Disabled. When Enable this ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 24: Integrated Peripherals
Select and set up the super I/O devices BIOS Write Protect <Enabled> not allow to write data into BIOS. The default is <Disabled>. Super IO Device 3F8/IRQ4、2F8/IRQ3、3E8/IRQ4、2E8/IRQ3、AUTO Onboard Serial Port 1 ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 25: Power Management Setup
Down” field is activated. Min Saving Minimum power saving time for the “ Suspend Mode” and “HDD Power Down” =15min. Max Saving Maximum power saving time for the “Suspend Mode” and “HDD Power Down”=1 min. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 26: Pnp/Pci Configuration
This option is used to configure Plug and Play assignments and route PCI interrupts to designated ISA interrupts. Use the PNP/PCI Configuration Setup option as follows: 1. Choose “PNP/PCI Configuration Setup” from the main menu, the following screen appears. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 27 Enable MEPG ISA/VESA VGA cards work with PCI/VGA Disabled MPEG ISA/VESA VGA card does not work with PCI/VGA Assign IRQ for VGA Select Enabled/Disabled to specify whether the VGA ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 28: Pc Health Status Configuration Setup
The item enabled you to set up the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in the system. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 29: Load Fail-Safe Defaults
ROM. This is useful if you are having problems with the main board and need to debug or troubleshoot the system. The loaded default settings do not affect the Standard CMOS Setup screen. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 30: Load Optimized Defaults
<Y> key and then press <Enter> if you want to load the BIOS default. 3.13 Load Optimized Defaults This option loads optimized settings stored in the BIOS ROM. The auto-configured settings do not affect the Standard CMOS Setup screen. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 31: Supervisor/User Password
8 alphanumeric characters. Press <Enter> after entering the password. At the Next Prompt, confirm the new password by typing it and pressing <Enter> again. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 32: Save And Exit Setup
CMOS Setup program. 3.15 Save and Exit Setup This function automatically saves all CMOS values before exiting Setup. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 33: Exit Without Saving
User’s Manual 3.16 Exit Without Saving Use this function to exit Setup without saving the CMOS value. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 34: Chapter 4. Utility & Driver Installation
CB-6970 offers the system driver in the setup CD. Please install the driver follow the below procedures. 1. Insert the setup CD of CB-6970 into your CD-ROM drive. 2. Choose the Drivers/system file to click the Setup icon. 3. Click [Next] button. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 35 User’s Manual 4 Click [YES] button. 5. Choose <Normal Installation> to install all drivers. Click [Next] button. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 36 User’s Manual 6. Choose all setting. Click [Next] button. 7. Choose <Install VIA PCI IDE Bus Driver>. Click [Next] button. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 37 User’s Manual 8. Choose <Install AGP driver>. Click [Next] button. 9. Click [OK] button to finish the installation. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 38: Lan Driver Installation
8. Choose the [Network adapters] item. 9. Click the [Driver] tab. 10. Click the [Update Driver] button. Then the Update Device Driver Wizard will appears. 11. Click [Next] button. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 39 User’s Manual 12. Click [Next] button. 13. Choose <Specify a location>, press [Next] button. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 40 User’s Manual 14. Find the Intel® 82551 or Reatek® 8139CL+ driver in the Setup CD. 15. Press the [OK] button. 16. Click the [Next] button. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 41 User’s Manual 17. Click [Yes] button. 18. Click [Finish] button then complete the installation. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 42: Raid Driver Installation
1. Insert the setup CD of CB-6970 into your CD-ROM drive. 2. Choose the Drivers file to click the Setup icon. 3. Click [Next] button. 4. Select <I Agree>. Click [Next] button. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 43 User’s Manual 5. Choose the components you want to install, then click the [Next] button. 6. Click the [Next] button. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 44 User’s Manual 7. Click the [Yes] button. 8. Click the [Next] button ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 45 User’s Manual 9. Click the [Finish] button to complete the installation. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
-
Page 46: Vga Driver Installation
1. Insert the setup CD of CB-6970 into your CD-ROM drive. 2. Choose the Drivers file to click the Setup icon. 3. Follow the onscreen instruction to finish the driver installation in sequence. ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... -
Page 47: Appendix A: Programming The Watchdog Timer
MOV DX,2FH MOV AL,08H OUT DX,AL Program 2: Writing a watchdog timer interval value MOV DX,2EH O 2E F6 MOV AL,F6H O 2F XX OUT DX,AL O 2E AA ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006... - Page 48 8. Run Program 2 (reload the timer interval value of 3CH, 60 seconds) 9. Run Program 1 Run Program 3 (Load the timer interval of 00H, and disable the watchdog timer function) ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
- Page 49 2.54mm, 3cm, 4 pin power cable 46-IUSB01-00 USB Cable CN11 25cm 46-ICOM04-00 COM Port Cable CN10 22cm, D-Sub 9, 2*5 46-IPS200-00 KB/MS Cable CN13 15cm 46-IVGA01-00 VGA Cable CN12 2.00mm, D-Sub VGA Cable ©2006 AEWIN Technologies Co., Ltd. All rights reserved. Ver 1.1. Aug, 2006...
