- Page 1 FujiMAC Air Pump Instruction Manual Model: FujiMAC40 R2 FujiMAC60 R2 FujiMAC80 R2 FujiMAC100 R2 FujiMAC120 R2 FujiMAC150 R2 FujiMAC200 R2 FujiMAC250 R2 FujiMAC300 R2 Serial number: Installation Date: Register your FujiMAC here: Air hose sold separately www.fujimac.co.uk fujimac.co.uk/warranty...
-
Page 2: Safety Precautions
Instruction Manual Thank you for purchasing the FujiMAC Air Pump. Be sure to read through this manual to gain full understanding before proceeding to actual operation. Please retain this manual for future reference. SAFETY PRECAUTIONS Read the precautions carefully before operating the air pump. The contents of this section are vital to ensure safety. -
Page 3: For Installers
For Installers INSTALLATION WARNING • All electrical work must be performed by a licensed electrician. • Do not place any object on the power cord. Neglecting this note may cause electric shock and/or fire. CAUTION • The diaphragms will be damaged by the chlorine gas and/or other fume so any hole and gap (i.e. -
Page 4: Test Operation
TEST OPERATION CAUTION • The airline outlet area must be filled with water up to the prescribed line before turning on the air pump. • Make sure the aeration is conducted properly. • Make sure the air pump is making no abnormal noise and vibration. •... -
Page 5: Inspection And Maintenance As Required
If the diaphragm/valve becomes damaged, the automatic stop function engages (except FujiMAC40 R2). Further action must be taken to rectify the problem or deterioration of the use point due to an inoperable air pump may result. A discernible odour will be present in this event. -
Page 6: Power Plug
WATCH ONLINE Normal position. Turn auto-stop piece and Remove auto-stop face symbol along slit. piece from air pump fujimac.co.uk//maintenance auto-stop holder. 2 HOW TO SET AN AUTO-STOP PIECE Push in until it clicks. Face symbol from auto-stop piece Ready for use. -
Page 7: Specifications
SPECIFICATIONS Model FujiMAC40 FujiMAC60 FujiMAC80 FujiMAC100 FujiMAC120 Air Flow Volume L/min Normal Pressure mbar Rated Voltage 230-240 Frequency Outlet Pipe Size O.D.18mm (I.D.13mm) O.D.26mm (I.D.20mm) Weight Power Consumption 27 / 28 35 / 38 47 / 51 68 / 80 86 / 101 (at Normal Pressure) Rated power input... - Page 8 OVERALL VIEW (ALL DIMENSIONS IN MILLIMETERS) FujiMAC40 R2 FujiMAC60 R2 / 80 R2 / 100 R2 FujiMAC120 R2 FujiMAC150 R2 / 200 R2 / 250 R2 / 300 R2...
-
Page 9: Service Log
Clean Filter Change Filter Change Diaphragm Clean Filter Clean Filter Clean Filter Change Filter Change Diaphragm Clean Filter Clean Filter Clean Filter Change Filter Change Diaphragm Clean Filter Clean Filter Clean Filter Change Filter Change Diaphragm www.fujimac.co.uk tel: 01183 703307 info@fujimac.co.uk... -
Page 10: Warranty
YOUR WARRANTY fujimac.co.uk/warranty • 12 month warranty as standard on all FujiMAC R2 / RII air pumps • Register your FujiMAC R2 / RII within 30 days of purchase to activate your FREE 2nd year of warranty and receive a FREE replacement air filter •... - Page 11 UK reseller of the FujiMAC and FujiClean brands, products and spare parts. The FujiMAC R2 / RII model range is optimised for aeration of wastewater, septic tanks and packaged sewage treatment. Please refer to datasheets (available at www.fujimac.co.uk) for normal operating parameters.
