■CC-Link, POWER SUPPLY ASSIGNEMENT
Unit side connector: MC1,5/5-GF-3,5 (Phoenix Contact)
Cable side connector: TFMC1,5/5-STF-3,5 (Phoenix Contact)
Aplicable wire size: 0.2 - 1.5mm
2
AI0,25-10YE 0.25mm (Phoenix Contact)
2
A0,34-10TQ 0.34mm (Phoenix Contact)
2
AI0,5-10WH 0.5mm (Phoenix Contact)
2
AI0,75-10GY 0.75mm (Phoenix Contact)
2
AI1-10 1.0mm (Phoenix Contact)
2
AI1,5-10 1.5mm (Phoenix Contact)
· CC-Link
1 2
NO. ID
1 FE
2 SLD
3 DB
4 DG
5 DA
Note: The numbers marked on the connector have no relationship to the pin number of the unit.
Wire according to the instruction manual of the unit.
■ OUTPUT, SENSOR EXC. ASSIGNMENT
Unit side conector: FCN-365P040-AU (Fujitsu)
Cable side connector: FCN-36( )J040-AU (Fujitsu)
(The cable connector is not included in the package. Specify wire size instead of ( ); refer to the specifications of the product)
A20
B20
PIN NO. ID FUNCTION
A1 VS- Exc. supply -
A2 VS- Exc. supply -
A3 NC Unused
A4 NC Unused
A5 Y31 Output 31
A6 Y30 Output 30
A7 Y29 Output 29
A8 Y28 Output 28
A9 Y27 Output 27
A10 Y26 Output 26
A11 Y25 Output 25
A12 Y24 Output 24
A13 Y23 Output 23
A14 Y22 Output 22
A15 Y21 Output 21
A16 Y20 Output 20
A17 Y19 Output 19
A18 Y18 Output 18
A19 Y17 Output 17
A20 Y16 Output 16
2
, stripped length 10mm
3 4 5
FUNCTION
Functional earth
Shield
DB (white)
DG (yellow)
DA (blue)
A1
B1
PIN NO. ID
B1 VS+
B2 VS+
B3 NC
B4 NC
B5 Y15
B6 Y14
B7 Y13
B8 Y12
B9 Y11
B10 Y10
B11 Y9
B12 Y8
B13 Y7
B14 Y6
B15 Y5
B16 Y4
B17 Y3
B18 Y2
B19 Y1
B20 Y0
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
· POWER SUPPLY
NO.
1
2
3
4
5
FUNCTION
Exc. supply +
Exc. supply +
Unused
Unused
Output 15
Output 14
Output 13
Output 12
Output 11
Output 10
Output 9
Output 8
Output 7
Output 6
Output 5
Output 4
Output 3
Output 2
Output 1
Output 0
R7F4HC-DC32A-K
1 2 3 4 5
ID FUNCTION
PWR+ Power supply +
PWR- Power supply -
FE1 Grounding
NC Unused
NC Unused
