Features and Benefits
•
Compliant with high-speed USB 2.0 specifications
•
Compliant with USB Storage Class 1.0 specifications
•
Low power consumption-powered from the system.
No power adapter required!
•
Hot-swapping feature allows you to attach/detach
USB devices without powering your computer off
•
Designed for devices using CF type I/II, MicroDrive,
Magicstor, SM, xD Picture Card, SD, miniSD, MMC,
RSMMC and Memory Stick memory cards
Note: USB 2.0 devices are limited to USB 1.1 speed
when they are connected to USB 1.1 host adapter or
USB 1.1 hubs.
System Requirements
•
PC or Mac computer with an available USB port
(USB 2.0 recommended)
•
Windows 98SE/ME/2000/XP/Server 2003
•
Mac OS 9.x and Mac OS X (v10.1.3) or later
Package Contents
•
Hi-Speed USB 18-in-1 Reader/Writer
•
USB cable (Type A to Mini 5-pin)
•
Driver CD
•
This quick installation guide
04-0372A
Hi-Speed USB 18-in-1
Reader/Writer
Quick Installation Guide
1
Advertisement
Table of Contents
Related Manuals for SIIG JU-PC1812-S1
Summary of Contents for SIIG JU-PC1812-S1
-
Page 1: Quick Installation Guide
Hi-Speed USB 18-in-1 Reader/Writer Quick Installation Guide Features and Benefits • Compliant with high-speed USB 2.0 specifications • Compliant with USB Storage Class 1.0 specifications • Low power consumption-powered from the system. No power adapter required! • Hot-swapping feature allows you to attach/detach USB devices without powering your computer off •... - Page 2 Layout Activity LED SmartMedia/xD CF/MicroDrive/ Magicstor Note: Do not unplug the reader/writer or remove your memory card(s) while the Activity LED is flashing. Installation Windows 98SE Do not connect the reader/writer until after the driver has been installed. Boot up your system and insert the driver CD. Click Start, Run, type D:\Setup.exe, then click OK.
- Page 3 Windows 2000 Windows 2000 with service pack 2 or earlier Do not connect the reader/writer until after the driver has been installed. Boot up your system and insert the driver CD. Click Start, Run, type D:\Setup.exe, then click OK. (Change D: to match your CD-ROM drive letter) Select English, click Next.
- Page 4 Windows ME/XP/Server 2003 Important: Windows ME, XP and Server 2003 automatically detects and installs the correct drivers for this reader/writer when connected. No driver installation is needed. Refer to Accessing Memory Cards, on page 6, for the order in which the memory slots appear. However, it's hard to distinguish one drive from another unless you install the provided software that labels each drive.
- Page 5 Click Yes, then OK. XP/Server 2003 Optional Software Click Start, Control Panel, Add or Remove Programs. Click Multi-Card Reader & Flash Disk, then click Change/Remove. Click Yes, then OK. Mac OS 9.x Do not connect the reader/writer until after the driver has been installed.
-
Page 6: Inserting Memory Cards
Inserting Memory Cards For CompactFlash, MicroDrive and Magicstor memory media, insert with the top label facing up. For SmartMedia, MultiMediaCard, RSMMC, SecureDigital, xD Picture Card, and Memory Stick memory cards, insert with the gold pins facing down. For miniSD memory card, align it to the left side of the slot and insert with the gold pins facing up. -
Page 7: Technical Support And Warranty
RMA number posted on the outside of the shipping carton. • You are responsible for the cost of shipping the product to SIIG at the following address: SIIG, Inc. 6078 Stewart Avenue... - Page 8 Fremont, CA 94538-3152 Hi-Speed USB 18-in-1 Reader/Writer is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation.
