Doc.no.LER0-OM00305
PRODUCT NAME
Electric Rotary Table
/Battery-less Absolute Encoder Type
MODEL / Series / Product Number
LER50E Series
Controller
ＪＸＣ□1 Series
#This manual describes the dedicated terms for "LER50E".
Refer to the manual of LER series about other details.
#Refer to the manual relevant to the controller being used for full operating instructions.
Advertisement
Table of Contents
Related Manuals for SMC Networks LER50E Series
Summary of Contents for SMC Networks LER50E Series
- Page 1 Doc.no.LER0-OM00305 PRODUCT NAME Electric Rotary Table /Battery-less Absolute Encoder Type MODEL / Series / Product Number LER50E Series Controller ＪＸＣ□1 Series #This manual describes the dedicated terms for “LER50E”. Refer to the manual of LER series about other details. #Refer to the manual relevant to the controller being used for full operating instructions.
- Page 2 Contents Safety Instructions ................2 １．Specification ................4 ２．How to order ................5 ３．Specific product precautions ..........5...
-
Page 3: Safety Instructions
LER50E Series / Electric Rotary Table Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 LER50E Series / Electric Rotary Table Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
-
Page 5: １．Specification
１．Specification LER* LER* LER* LER* Model LER*50EK LER*50EJ 50EK-2 50EK-3 50EJ-2 50EJ-3 Rotation angle[°] Lead[°] Range of external stopper[°] ±2 Max. Rotation Torque[N･m] Max. Pushing Torque[N･m] 0.13 0.05 0.13 0.05 Max.Moment of lnertia[kg･m Angular Speed[°/sec] 20 to 280 30 to 420 20 to 280 30 to 420 Pushing speed[°/sec]... -
Page 6: ２．How To Order
２．How to order LER * 50 E * - * * - * * C * 1 * * (1) (2) (3) (4) (5) (6) (1) Table accuracy (7) Actuator cable type / length[m] Basic type Without cable High precision type 1.5m (2) Size Robotic cable... - Page 7 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2019 SMC Corporation All Rights Reserved...
