●LEHF Series
#This manual describes the dedicated terms for "LEHF*E series".
Refer to the manual of LEH series about other details..
#Refer to the manual relevant to the controller being used for full operating instructions.
PRODUCT NAME
Electric Grippers
MODEL / Series / Product Number
LEHF*E Series
Applicable model : LEHF(32,40) E
Controller
ＪＸＣ□1 Series
Doc. no. LEH-OMX0011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMC Networks LEHF E Series
Summary of Contents for SMC Networks LEHF E Series
- Page 1 Doc. no. LEH-OMX0011 PRODUCT NAME Electric Grippers / Battery-less Absolute Encoder Type MODEL / Series / Product Number LEHF*E Series Applicable model : LEHF(32,40) E F Type (2 fingers) ●LEHF Series Controller ＪＸＣ□1 Series #This manual describes the dedicated terms for “LEHF*E series”. Refer to the manual of LEH series about other details..
- Page 2 Contents Safety Instructions ................2 1. Specifications ................. 4 2. How to Order .................. 5 3. Specific product precautions ............5...
-
Page 3: Safety Instructions
LEHF*E Series /Electric Grippers Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 LEHF E Series /Electric Grippers Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
-
Page 5: Specifications
1. Specifications Model LEHF32E LEHF40E Basic Open and close stroke/both sides [mm] Long Lead [mm] 70/16 (4.375) Gripping force [N] 40 to 100％ 48 to 120 72 to 180 Open and close speed/Pushing speed [mm/s] 5 to 100 / 5 to 30 Pushing speed [mm/s] 48 to 122 72 to 182... -
Page 6: How To Order
2. How to Order LEHF 32 E K 2 - 32 * - * * C * 1 * * (1) (2) (3) (4) (5) (6) (1) Size (7) Actuator cable type/length Without cable 1.5m (2) Motor type Robotic cable 8m *1 Step motor with Battery-less (Flexible cable) - Page 7 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2019 SMC Corporation All Rights Reserved...
