SBM International T7DV Specifications

T7DV
Introduction
T Series monitor families are a flat LCD display with the wide-view angle and the most cost-efficient type. The series of
monitors are designed and developed for the application of POS display, industrial field, medical and transportation. They
provide all the features, such as to support touchscreen (Resistive) and VGA or DVI signal. With the friendly OSD and
multi-language support, users can freely operate the series of products without struggling. To touch the screen with a finger,
fingernail or object such as a credit card and you will receive a fast, accurate response every time.
Specification :
VGA Input: 15 Pins D-Sub x1
I/O Ports
DVI Input: 24 Pins DVI-D x1 (option)
VESA DDC1/2B Compatible Support
Plug & Play
Keys: Auto-tune, menu, decrease and increase
OSD Control
Functions: Brightness, Contrast, Clock, Phase,
Horzontal Position, Vertical Position
30W max.
Power Consumption
Build-in power supply, with AC 100~240V
Power
-25°~90° or -4°~90° for desk-top without
Tilt Angle
additional parts
372 mm x 388 mm x 210 mm
Dimensions(WxHxD)
6.5 kg±1
Net Weight
Environment
Operating Temperature -0~45°C
Storage Temperature -20~60°C for standard LCDs
Humidity 10~90% non-condensing
EMC Approved CE, FCC
Safety Approved UL/ Cus
17" TFT-LCD Touch Monitor
Features
17" LCD supports 1280 x 1024 pixels
Resistive and 3mm tempered glass options
Versatile mounting brackets
Modular architecture for efficient
chassis integration
VGA interface (DVI optional)
Display
17"
LCD Diagonal Size
SXGA (1280 x 1024)
Resolution
TN
Mode
8
Response Time(ms)
16.2M
Number of Colors
H:150° / V:130°
View Angle(H/V)
)(Typ.) 300 nits
Brightness(cd/m
2
Contrast Ratio(ms)(Typ.) 500:1
40,000
Lamp Lift(hours)
Touchscreen
Type 5-Wire Resistive
Thickness 3mm
Resolution Continuous
Light
80%
Transmission
Controller
RS-232 or USB
Interface
Power
+5V@200mA
Consumption
Touch
35 Million Times
Lifetime (Finger)
Driver OS DOS, Linux and Windows
Support
ME / 2000 / XP
* 17" TFT Panel 300 nits testing for reference.
* RS-232 Interface by NCT option.
* All Touch specifications are subject to be changed without notice.
Tilt
-25°~90° or -4°~90°
®
95 / 98 / NT /
