SBM International T5DV Specifications

T5DV
Introduction
T Series monitor families are a flat LCD display with the wide-view angle and the most cost-efficient type. The series of
monitors are designed and developed for the application of POS display, industrial field, medical and transportation. They
provide all the features, such as to support touchscreen (Resistive) and VGA signal. With the friendly OSD and multi-
language support, users can freely operate the series of products without struggling. To touch the screen with a finger,
fingernail or object such as a credit card and you will receive a fast, accurate response every time.
Specification :
I/O Ports VGA Input: 15 Pins D-Sub x1
Plug & Play VESA DDC1/2B Compatible Support
OSD Control Keys: Auto-tune, menu, decrease and increase
Functions: Brightness, Contrast, Clock, Phase,
Horzontal Position, Vertical Position
Power Consumption 24W max.
Power Build-in power supply, with AC 100~240V
Tilt Angle -25°~90° or -4°~90° for desk-top without
additional parts
Dimensions(WxHxD) 357 mm x 344 mm x 210 mm
Net Weight 5.2 kg±1
Environment
Operating Temperature -0~45°C
Storage Temperature -20~60°C for standard LCDs
Humidity 10~90% non-condensing
EMC Approved CE, FCC
Safety Approved UL/ Cus
15" TFT-LCD Touch Monitor
Features
15" LCD supports 1024 x 768 pixels
Resistive and 3mm tempered glass options
Versatile mounting brackets
Modular architecture for efficient
chassis integration
User friendly one level operation in OSD
VGA interface
Display
LCD Diagonal Size(inch) 15"
Resolution XGA (1024 x 768)
Mode TN
Response Time(ms) 16
Number of Colors 16.2M
View Angle(H/V) H:140° / V:130°
)(Typ.) 250 nits
Brightness(cd/m 2
Contrast Ratio(ms)(Typ.) 450:1
Lamp Lift(hours) 50,000
Touchscreen
Type
5-Wire Resistive
Thickness
3mm
Resolution
Continuous
Light
80%
Transmission
Controller
RS-232 or USB
Interface
Power
+5V@200mA
Consumption
Touch
35 Million Times
Lifetime (Finger)
Driver OS
DOS, Linux and Windows
Support
/ 2000 / XP
* 15" TFT Panel 250 nits testing for reference.
* RS-232 Interface by NCT option.
* All Touch specifications are subject to be changed without notice.
Tilt
-25°~90° or -4°~90°
®
95 / 98 / NT / ME
