ASSEMBLY
CORNER DINING SET
INSTRUCTIONS
People Required to Assembly
Tools Required
Approximate Assembly Time
2:30hrs
Before you start....
Please carefully unpack and lay out all of the component parts to ensure nothing
is missing and to check each component for any obvious damage.
Should you identify any concerns at this stage please contact the retailer from
whom this product was purchased. Please quote your order number, details of
your issue, the product code, and the batch number from the cartons which will
help to resolve your issue as quickly as possible.
Version Number - 1.0
Product Code - NEW201/NEW202/NEW203
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Julian Bowen NEW201
Summary of Contents for Julian Bowen NEW201
- Page 1 Please quote your order number, details of your issue, the product code, and the batch number from the cartons which will help to resolve your issue as quickly as possible. Version Number - 1.0 Product Code - NEW201/NEW202/NEW203...
- Page 3 Please check all hardware matches the list below. Should you notice any are missing please contact your retailer. 3,5x14mm 8x30mm 18x18mm 4x30mm 7x50mm 10x30mm 4x30mm 4,5x60mm 4,5x40mm 4x20mm 8x50mm 7x50mm 4x40mm We strongly advise that you do not use Power Tools, such as drills or electric screwdrivers during the assembly as this may cause irreparable damage and will invalidate your warranty.
- Page 4 PARTS Please ensure you carefully check all the pieces, should you have any concerns please contact the retailer before assembly commences. Please have your order number, details of the issue, the product code, and the batch number from the cartons as this will help us to resolve your issue much faster.
-
Page 5: Assembly Advice
ASSEMBLY ADVICE Please take the time to carefully read through these instructions before you commence. Keep these instructions for future reference. We advise that the product is assembled in the room it is intended for. We advise that you keep the hardware in a bowl during assembly to avoid losing anything. - Page 7 Attention! Attention!!! Right! Left! The product can be assembled left or right. Assembly instructions show option right side. For left side assembly, swap panels and rails...
-
Page 21: General Care And Maintenance
GENERAL CARE & MAINTENANCE We advise that when cleaning the product that a damp cloth is used. Avoid the use of all household cleaners and abrasive. Never push or drag the furniture. Never attempt to move the furniture when fully loaded. We advise that periodically all fixings are re-tightened.
