Manual – Starflow QSD Model 6527B and 6537A
Manual

Starflow QSD Model 6527B and 6537A

This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules in the USA. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference, in which case the user will be required to correct the
interference at their own expense.
This equipment has been tested for compliance with European regulations as follows:
Application of Council Directive:
2004/108/EC
Standards to which Conformity is declared:
EN-61000-6-1:2001
EN-61000-4-2:1995
EN-61000-4-3:1995
EN-61000-4-4:1995
EN-61000-4-6:1996
ENV-50204:1995
Any changes or modifications to this equipment not expressly approved by the manufacturer
Unidata Pty Ltd could void the user's authority to operate this equipment.
Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx
Page 1

Advertisement

Table of Contents
loading

Related Manuals for UniData Communication Systems Starflow QSD 6527B

Summary of Contents for UniData Communication Systems Starflow QSD 6527B

  • Page 1: Starflow Qsd Model 6527B And 6537A

    Manual – Starflow QSD Model 6527B and 6537A Manual Starflow QSD Model 6527B and 6537A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules in the USA. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 2 Manual – Starflow QSD Model 6527B and 6537A Revision History Checked/ Authors & Change File name / Revision Date Approve Details 27 05 19 IM First Draft Unidata Manual - 6537A Starflow QSD SDI-12 User Manual 27 05 2019.docx 21 06 19 RDS, PD Unidata Manual - 6537A Starflow QSD User Manual 21 06 2019 04 07 19...

  • Page 3: Table Of Contents

    Manual – Starflow QSD Model 6527B and 6537A TABLE OF CONTENTS Starflow QSD Model 6527B and 6537A ................1 Operation Mode ......................6 1.1. Operation Mode Configuring using SDI-12 protocol ........... 6 1.2. Operation Mode Configuring using Modbus RTU protocol ......... 6 Introduction ......................
  • Page 4 Manual – Starflow QSD Model 6527B and 6537A 5.2.6. Additional Modbus Commands 5.2.7. Unidata Logger Modbus Scheme Setup Installation ......................38 6.1. Site Considerations ....................38 6.2. Instrument Mounting – Pipes & Culverts ..............39 6.3. Instrument Mounting – Open Channels ..............41 Instrument Maintenance ..................
  • Page 5 Manual – Starflow QSD Model 6527B and 6537A 15.2.3. Opening with Notepad 15.2.4. Opening with Excel Power Failure......................97 Diagnostics ......................98 17.1. Velocity Trace ......................98 17.2. Velocity Histograms ....................99 17.3. Inherent Factors in Doppler Histograms ..............100 17.4.

  • Page 6: Operation Mode

    Manual – Starflow QSD Model 6527B and 6537A 1. OPERATION MODE There are two modes of operation for the Starflow QSD, SDI-12 and Modbus RTU. SDI-12 operates so that when a Measurement command is sent, the Starflow QSD will Initiate a read at this time and then provide data after 5 seconds.

  • Page 7: Introduction

    Manual – Starflow QSD Model 6527B and 6537A 2. INTRODUCTION The 1 generation 6527 Starflow QSD Instrument measures water velocity, depth (ultrasonic) and temperature. The Starflow QSD – 2 generation has been enhanced to include depth measurement using the hydrostatic pressure method (6527B Starflow QSD), electrical conductivity (6537A Starflow QSD), and a tilt sensor that is useful for installation and site monitoring.
  • Page 8 Manual – Starflow QSD Model 6527B and 6537A 6527B 6537A Hardware Accessories: The following accessories should be purchased according to your application requirements. Model 6907B-14 12V, 14Ah Sealed Lead Acid Battery Model 6904I-10 10W Solar Recharge Panel & Mount Model 6904I-20 20W Solar Recharge Panel &...

  • Page 9: Specifications

    Manual – Starflow QSD Model 6527B and 6537A Instrument Accessories: Model 6515 QSD Barometric Reference for pressure depth reading compensation. 3. SPECIFICATIONS 3.1. Velocity (Continuous Beam) 20mm/sec to 0.8 m/sec 20mm/sec to 1.6 m/sec (default) Range 20mm/sec to 3.2 m/sec 20mm/sec to 6.6 m/sec Bidirectional velocity capability, set using configuration tools Accuracy...

  • Page 10: Tilt (Accelerometer)

    Manual – Starflow QSD Model 6527B and 6537A 3.6. Tilt (accelerometer) Range ±70° in roll and pitch axes. Accuracy ±1° for angles less than 45° 3.7. Power Requirements Voltage range 12 to 24 V DC Supply current 50uA standby, 100mA active for 1 second @12V Power source 12V DC - typically an external battery 3.8.

  • Page 11: Instrument Wiring Table

    Manual – Starflow QSD Model 6527B and 6537A 3.11. Instrument Wiring Table Variants for Wiring are detailed below. Brown Wire Variant Starflow QSD / Wire Colour Function / Signal Name White SDI-12 Brown Power Green Ground Yellow A- (Modbus) Pink B+ (Modbus) Grey One-Wire *...
  • Page 12 Manual – Starflow QSD Model 6527B and 6537A 6515 QSD barometric Connection Diagram: There may be a small pressure offset when the sensor is first installed due to different barometric conditions compared to the factory. This can be set to zero by applying a positive or negative offset using a Modbus or SDI-12 command.

  • Page 13: Operating Principles & Measured Parameters

    Manual – Starflow QSD Model 6527B and 6537A 4. OPERATING PRINCIPLES & MEASURED PARAMETERS The 6527B and 6537A Starflow QSD measure: Flow velocity Depth (ultrasonic) Temperature Depth (Pressure) Electrical Conductivity (EC) – 6537A Only Tilt (the angular orientation of the instrument) The Starflow QSD performs data processing and analysis each time a measurement is made.

  • Page 14: Water Depth Measurement - Ultrasonic

    Manual – Starflow QSD Model 6527B and 6537A Water Depth Measurement – Ultrasonic For depth measurement, the Starflow QSD uses Time-of-Flight (ToF) Ranging. This involves transmitting a burst of ultrasonic signal upwards to the surface of the water and measuring the time taken for the echo from the surface to be received by the instrument.

  • Page 15: Temperature

    Manual – Starflow QSD Model 6527B and 6537A If the data logger used to read the Starflow QSD does not incorporate a barometric pressure sensor, then the One Wire Bus 6515 Reference Barometer option should be purchased. 6515 should be mounted near the logger and is read by the Starflow QSD instrument, which will then automatically compensate for the atmospheric pressure variations ensuring an accurate depth measurement is achieved.

  • Page 16: Signal Spread

    Manual – Starflow QSD Model 6527B and 6537A Signal Spread This can be used to determine the amount of “turbulence” affecting the signal quality and used to reject the measurement if the spread (turbulence) is too great. A good flow would return a spread value of around 50;...

  • Page 17: Taking Measurements From Instrument

    Manual – Starflow QSD Model 6527B and 6537A 5. TAKING MEASUREMENTS FROM INSTRUMENT The Starflow QSD instrument has both SDI-12 and RS485 (Modbus RTU) Interfaces. The following sections describe them in detail. If you are a user of Unidata NRL loggers, you can simply add the Starflow QSD as an instrument within the logging scheme as an SDI-12 instrument.

  • Page 18: Channels Table

    Manual – Starflow QSD Model 6527B and 6537A 5.1.1. Channels Table The Starflow QSD has a list of data registers within the instrument that are re-mapped to SDI-12 channels. These SDI-12 parameters are assigned to the Channels, and their order of return can be configured using SDI-12 eXtended commands.
  • Page 19 Manual – Starflow QSD Model 6527B and 6537A Example 2: aM1! (Firmware 20 and above) Parameter Description Units Example Meaning Water Temperature 1/10 ºC +152 15.2ºC Battery Voltage 1/100 Volts +1302 13.02Volts Ultrasonic Depth +123 123mm CW Water Velocity +/- mm/s -234 234mm/s -ve flow Start Measurement Command (aM1!) example:...

  • Page 20: Additional Sdi-12 Commands

    Manual – Starflow QSD Model 6527B and 6537A Example 5: aM4! (Firmware 20 and above) Parameter Description Units Example Meaning X-axis Tilt +/- deg 9 deg left tilt Y-axis Tilt +/- deg 7 deg forward tilt Start Measurement Command (aM4!) example: 0M4! 00052 <CR><LF>...
  • Page 21 Manual – Starflow QSD Model 6527B and 6537A 5.1.3.2. Pressure Depth Zero Offset Example 1 Examine: Send – 0X7! <CR><LF> Response – 0+30<CR><LF> The current pressure depth offset setting is 30mm. Example 2 Change: Send – 0X7+100! <CR><LF> Response - 0+100<CR><LF> Set pressure depth offset to 100mm. Example 3 Change: Send –...

  • Page 22: Unidata Logger Sdi-12 Scheme Setup

    Manual – Starflow QSD Model 6527B and 6537A 5.1.4. Unidata Logger SDI-12 Scheme Setup The Starflow QSD can be directly connected to the Unidata NRL Logger range using SDI-12. A scheme can then be set up using the StarlogV4 software to record the parameters from the QSD and to enter the channel profile for flow calculations.
  • Page 23 Manual – Starflow QSD Model 6527B and 6537A 3. Scroll down and double-click SDITASK Instrument, and it will be added to the window on the right. 4. Double-click on the 6526-EXT instrument to add the Flow Extension, and it will be added to the window on the right.
  • Page 24 Manual – Starflow QSD Model 6527B and 6537A 5. Double-click on the SDI Task Table #1 Instrument in the right window 6. Click the Add Sensor button, scroll down in the list, select the Unidata 6537 QSD and click Ok. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 24...
  • Page 25 Manual – Starflow QSD Model 6527B and 6537A 7. Set to Log Interval and set Read Time to 10s (The Starflow QSD will take 5s to take measurements); make sure the Read Time is a multiple of the Scan Rate. 8.
  • Page 26 Manual – Starflow QSD Model 6527B and 6537A 9. Open the Flow extension instrument and set up the channel profile; select the Input Depth channel to be Ultrasonic OR Pressure Depth depending on the site installation and select the Input Velocity Channel to be Velocity. 10.

  • Page 27: Modbus Rs485 Operation

    Manual – Starflow QSD Model 6527B and 6537A 5.2. Modbus RS485 Operation The Starflow QSD can be operated as a Modbus RTU Slave sensor. The Baud rate and parity selected must be configured prior to using the instrument. The instrument supports configurable Baud rates for the RS-485 Communication Port (the SDI-12 Port is fixed to 1200/9600 as per the SDI-12 standard).

  • Page 28: Slave Response Format

    Manual – Starflow QSD Model 6527B and 6537A 5.2.3. Slave Response Format Device Address Function Code Data Payload Device Address – Echo of the device address sent in the master message to the device. Function code – Echo of function code sent in the master message to the device. Data payload –...

  • Page 29: Modbus Registers

    Manual – Starflow QSD Model 6527B and 6537A 5.2.5. Modbus Registers The below list of parameters will all be located in the holding registers. Sensor Common Registers: Registers Numbered 0001 to nnnn have Data Addresses 0000 to nnnn-1 Register Size Data Mode/Access Description...

  • Page 30: Additional Modbus Commands

    Manual – Starflow QSD Model 6527B and 6537A Example 2: Water Temperature, Battery Voltage, Water Depth, Velocity, RSSI, Signal Spread Send - 01 03 00 00 00 06 C5 C8 Receive - 01 03 0C 00 DF 05 3F 00 8D 00 55 00 10 00 18 5E 8D 00 DF = 223 Temperature = 223 x 0.1 = 22.3 ˚C 05 3F = 1343...
  • Page 31 Manual – Starflow QSD Model 6527B and 6537A 5.2.6.2. Pressure Depth Zero Offset Example 1: Set pressure depth offset 100mm: Send - 01 06 00 6D 00 64 19 FC Receive - 01 06 00 6D 00 64 19 FC Example 2: Set pressure depth offset -10363mm: Send - 01 06 00 6D D7 85 86 44 Receive - 01 06 00 6D D7 85 86 44...

  • Page 32: Unidata Logger Modbus Scheme Setup

    Manual – Starflow QSD Model 6527B and 6537A 5.2.7. Unidata Logger Modbus Scheme Setup The Starflow QSD can directly connect to the Unidata NRL Logger range using SDI-12. A scheme can then be set up using the StarlogV4 software to record the parameters from the QSD and also to enter the channel profile for flow calculations.
  • Page 33 Manual – Starflow QSD Model 6527B and 6537A 3. Scroll down and double-click the MODBUS Instrument, and it will be added to the window on the right. 4. Double-click on the 6526-EXT instrument to add the Flow Extension, and it will be added to the window on the right.
  • Page 34 Manual – Starflow QSD Model 6527B and 6537A 5. Double-click on the MODBUS #1 Instrument in the right window Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 34...
  • Page 35 Manual – Starflow QSD Model 6527B and 6537A 6. Scroll down in the Name list and select the Unidata 6527/6537 QSD and click Ok. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 35...
  • Page 36 Manual – Starflow QSD Model 6527B and 6537A 7. Set to Log Interval and set Read Time to 10s (The Starflow QSD will take 5s to take measurements); make sure the Read time is a multiple of the scan rate. 8.
  • Page 37 Manual – Starflow QSD Model 6527B and 6537A 9. Open the Log Buffer and enable the log channels required; if your instrument model is 6527, then there will be no conductivity reading. 10. Save the scheme and exit the scheme editor. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 37...

  • Page 38: Installation

    Manual – Starflow QSD Model 6527B and 6537A 6. INSTALLATION 6.1. Site Considerations The Doppler signal received, and the accuracy of the computed velocity is related to the flow and cross-section characteristics of the site. A suitable site has the following features: Feature Description Flows are laminar, and the...

  • Page 39: Instrument Mounting - Pipes & Culverts

    Manual – Starflow QSD Model 6527B and 6537A 6.2. Instrument Mounting – Pipes & Culverts A typical installation is in a pipe or culvert with diameters between 150mm and 2000 mm. The Starflow QSD should be located near the downstream end of a straight and clean culvert, where non-turbulent flow conditions are maximised.
  • Page 40 Manual – Starflow QSD Model 6527B and 6537A Pipe Diameter Clamp Bands Joiners Up to 600mm 6705A 6705D 600 - 1200mm 6705B 2 x 6705D 1200 - 1800mm 6705B 3 x 6705D Note: Pipes less than 150mm in diameter are NOT RECOMMENDED for Starflow QSD installation due to the instrument’s size.

  • Page 41: Instrument Mounting - Open Channels

    Manual – Starflow QSD Model 6527B and 6537A Use a small pilot drill bit (about 2mm), then finish with the 5mm bit. When drilling stainless steel, use a slow speed and high pressure. Avoid stopping as the material will work harden, making it more difficult to drill. 4.
  • Page 42 Manual – Starflow QSD Model 6527B and 6537A Where possible, the cable to the instrument should be run back behind the instrument for several meters to minimise the effect of debris caught in the cable on the measurement. Appropriate shielding or conduit should be installed to protect the cable from damage. Care should be taken when selecting the site.

  • Page 43: Instrument Maintenance

    Manual – Starflow QSD Model 6527B and 6537A 7. INSTRUMENT MAINTENANCE The Starflow QSD requires very little maintenance. During routine site visits, the following checks can be performed: Piezo element Clean the instrument surfaces where the Piezo elements are faces located by wiping them with a cloth.

  • Page 44: Factors Affecting Flow Measurement Accuracy

    Manual – Starflow QSD Model 6527B and 6537A 8. FACTORS AFFECTING FLOW MEASUREMENT ACCURACY Starflow QSD measures velocity to an accuracy of ±2% and depth to ±1% of the range. This is logged to a resolution of 1 mm/sec and 1mm respectively. The purpose of the Starflow QSD system is to produce velocity data.

  • Page 45: Conversion Of Logged To Mean Velocity

    Manual – Starflow QSD Model 6527B and 6537A When comparing Starflow QSD velocity and mechanical current meter readings, the display should be observed long enough to estimate the mean of the readings. The Starflow QSD will do most of this processing internally but, if an external logger is being used to record the readings, the averaging could also be done here.
  • Page 46 Manual – Starflow QSD Model 6527B and 6537A The following table shows how the speed of sound varies with temperature and between fresh and seawater. Temperature (ºC) "Fresh Water" "Sea Water" 1402 1449 1426 1471 1447 1490 1466 1507 1482 1521 1497 1534...

  • Page 47: Starflow Qsd Model 6527L

    Manual – Starflow QSD Model 6527B and 6537A Starflow QSD Model 6527L 9. STARLOG V4 STARFLOW QSD INSTRUMENT-ONLY SOFTWARE INSTALLATION Please follow the below procedure to install the Starlog 4, Starflow QSD Instrument only software. You must ensure you have full “Administrator Rights” to install this software package.
  • Page 48 Manual – Starflow QSD Model 6527B and 6537A Once the download is complete, locate and run the StarlogV4.exe file. Ensure you have administrator rights before running this file. Press “Run” when you see the dialog box above. Close all other programs currently running on the computer and then press “Next”. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 48...
  • Page 49 Manual – Starflow QSD Model 6527B and 6537A Click on “I accept the agreement” and press “Next”. change the path. StarlogV4 needs to be at this location. Do install into the “Program Files” folder. If you do this, StarlogV4 will not run correctly! Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 49...
  • Page 50 Manual – Starflow QSD Model 6527B and 6537A Select program shortcuts as required. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 50...
  • Page 51 Manual – Starflow QSD Model 6527B and 6537A Press the “Install” button once you have selected your start icon options. Click “Finish” once the installation has been completed. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 51...
  • Page 52 Manual – Starflow QSD Model 6527B and 6537A When the software is run for the first time, Starlog will ask you for the path of any Legacy Starlog Version 3 files. Leave all these blank. This screen allows you to install one of the following: - Starlog 4 / Starflow QSD Instrument only - Starlog 4 / All Instruments and Loggers (Full version, additional User Name and code key required –...
  • Page 53 Manual – Starflow QSD Model 6527B and 6537A Because this installation will be for the “Starflow QSD Instrument Only” (Supplied free with the purchase of a Starflow QSD Instrument) then, you will need to select the “Starlog 4 / Starflow QSD Instrument Only” option as indicated with the red highlight above. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 53...
  • Page 54 Manual – Starflow QSD Model 6527B and 6537A Now continue by entering your Code Key into the window. The Code Key can be located on the “Unidata Recorder Software for Starflow QSD” disk that came packaged with your Starflow QSD instrument.

  • Page 55: Starflow Qsd Scheme Management

    Manual – Starflow QSD Model 6527B and 6537A 10. STARFLOW QSD SCHEME MANAGEMENT To select an existing scheme, open StarlogV4, click on the Select icon, and created schemes will be displayed. The tabs at the top allow you to view all your version 4 schemes and all your version 3 schemes (if you have any).
  • Page 56 Manual – Starflow QSD Model 6527B and 6537A When the Scheme Editor is open, select New Scheme from the File menu, or click the new icon on either of the toolbars. A list of data loggers will appear. Select the 6527L – Starflow QSD ultrasonic doppler velocity and depth.

  • Page 57: Settings

    Manual – Starflow QSD Model 6527B and 6537A Three new icons will appear inside the left toolbar: Settings, Instruments, and Log Buffer 10.2. Settings To control basic logger functionality, click on the Settings icon: One of the most important settings is the Scan Rate. This defines how often the logger scans (samples) its inputs.

  • Page 58: Instruments

    Manual – Starflow QSD Model 6527B and 6537A 10.3. Instruments Click on the Instruments icon. The Instrument Library lets you select from major groups of instruments. When you select an Instrument Library, all the instruments in the library relevant to the selected logger are shown.
  • Page 59 Manual – Starflow QSD Model 6527B and 6537A To add an instrument to your scheme, either double-click on its line in the left half of the window, or select it then click the Add button at the top of the window. A copy of the instrument will be added to the list in the right half of the window.

  • Page 60: Flow Measurement Extension

    Manual – Starflow QSD Model 6527B and 6537A 10.4. Flow Measurement Extension Starflow QSD is able to perform a wide range of flow calculations. This enables Starflow QSD to be used in partly filled circular pipes, regular open channels and natural streams. Other closed shapes such as ovoid pipes, require a user-defined Area Rating Table.

  • Page 61: Overview Of Creating A Flow Scheme

    Manual – Starflow QSD Model 6527B and 6537A 10.5. Overview of Creating a Flow Scheme Creating a Starflow QSD Scheme for flow measurement is a five-step process: Determine the dimensions of the channel. For open channels, create a Cross-Sectional Area in the Flow extension instrument which has already been added in the scheme editor and enter the parameters of your channel.
  • Page 62 Manual – Starflow QSD Model 6527B and 6537A The table type can also be a pipe; in this situation the pipe dimensions should be entered. In the case of a User Defined Area Rating Table, select the text file to be used. Once this has been completed then Save the Scheme.

  • Page 63: Creating An Area Rating Table

    Manual – Starflow QSD Model 6527B and 6537A 10.5.1. Creating an Area Rating Table To calculate Flow, Starflow QSD uses a lookup table called the Area Rating Table. The Area Rating Table is automatically generated when the scheme is saved from information provided in the Flow extension instrument.
  • Page 64 Manual – Starflow QSD Model 6527B and 6537A 10.5.2.1. Pipe Example 1 The pipe is 1.8m in diameter. A Starflow QSD unit is mounted at the bottom. No silt (dead sector) in pipe. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 64...
  • Page 65 Manual – Starflow QSD Model 6527B and 6537A 10.5.2.2. Pipe Example 2 The pipe is 900mm in diameter. A Starflow QSD unit is mounted 100mm up from the bottom and there is 75mm of silt in the pipe. Note that the Table Range was set to 1 to give improved accuracy.

  • Page 66: Open Channel And Natural Stream

    Manual – Starflow QSD Model 6527B and 6537A 10.5.3. Open Channel and Natural Stream The dimensional definition of any open channel (or stream) consists of pairs of “distance” and “reduced level” measurement which define the profile of the channel or stream. These pairs comprise the Channel Cross-Sectional Area.
  • Page 67 Manual – Starflow QSD Model 6527B and 6537A 10.5.3.2. Open Channel Example 1 This Open Channel is a V-Notch shape which is 2m wide and 1.5m deep. A 2-metre depth range Starflow QSD unit is mounted at the lowest point of the notch. The Cross-Sectional Area File is shown below: 1000 1500 2000 0...
  • Page 68 Manual – Starflow QSD Model 6527B and 6537A 10.5.3.3. Open Channel Example 2 This Open Channel is a pre-formed two-stage Rectangular Channel which is 3 metres wide and 1m deep with a 1m x 300mm secondary channel in the centre. The Cross-Sectional Area File (OCEX2.XAC) is shown below: 0 1000 1000 1000...
  • Page 69 Manual – Starflow QSD Model 6527B and 6537A 10.5.3.4. Open Channel/Natural Stream Example 3 This Natural Stream is 3 metres wide with the shape illustrated below. The Cross-Sectional Area File is shown below: 500 1000 1000 1000 1200 1300 2200 1300 2200 1800 2500 1800 3500 0...

  • Page 70: Other Applications

    Manual – Starflow QSD Model 6527B and 6537A 10.6. Other Applications If the channel you are measuring cannot be defined in the Cross-Sectional Area File (such as a partly filled ovoid pipe), you must supply your own Area Rating Table. This is called a User Area Rating Table.

  • Page 71: Configuring Starflow Qsd

    Manual – Starflow QSD Model 6527B and 6537A 11. CONFIGURING STARFLOW QSD Starflow QSDs are configured just as if they were a regular instrument. When you create a scheme, an instrument for the Starflow QSD is always added as the first instrument. Double click on 6527/6537 Starflow QSD.

  • Page 72: Configuring The Starflow Qsd As An Sdi-12 Sensor

    Manual – Starflow QSD Model 6527B and 6537A the “calibration” of the Starflow QSD. Later, when all parameters are set accurately these channels can be unselected. 11.1. Configuring the Starflow QSD as an SDI-12 Sensor When the Starflow QSD is an SDI-12 sensor, other SDI-12 recorders can access, and log data sensed by it.
  • Page 73 Manual – Starflow QSD Model 6527B and 6537A 3. When connected Click on Settings and then Configure QSD 4. Click on the Configure SDI-12 button 5. Using the dropdown buttons select which channels you would like to configure for SDI-12 output, these can be internal channels (indicated by Q at the beginning of channel name) or logged data channels (indicated by L at the beginning of channel name).

  • Page 74: Configuring The Starflow Qsd For Modbus Rtu

    Manual – Starflow QSD Model 6527B and 6537A Note: Most SDI-12 outputs are 16 bit Integers and Larger Flow parameters (Flow Rate, Flow and Total Flow) are configured as a 32 bit integer, the Flow Rate will require a multiplier of 0.001, and other flow parameters have a multiplier of 1.
  • Page 75 Manual – Starflow QSD Model 6527B and 6537A To set a Starflow QSD as a Modbus sensor as well as a logger: 1. Click on the Sonic Icon 2. When the SONIC window appears click on the Connect button. 3. When connected Click on Settings and then Configure QSD. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 75...
  • Page 76 Manual – Starflow QSD Model 6527B and 6537A 4. Click on the Configure SDI-12 button. 5. Click on the SDI-12 parameters button. 6. Using the dropdown buttons select which channels you would like to configure for Modbus output, these can be internal channels (indicated by Q at the beginning of channel name) or logged data channels (indicated by L at the beginning of channel name).
  • Page 77 Manual – Starflow QSD Model 6527B and 6537A Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 77...
  • Page 78 Manual – Starflow QSD Model 6527B and 6537A Note: Most Modbus outputs are 16 bit Integers except for Larger Flow parameters (Flow Rate, Flow and Total Flow) are configured as a 32 bit integer, the Flow Rate will also require a multiplier of 0.001, and other flow parameters have a multiplier of 1.

  • Page 79: Configuring Starflow Qsd Settings

    Manual – Starflow QSD Model 6527B and 6537A 7. Click Return button and then Exit. 11.3. Configuring Starflow QSD Settings The Starflow QSD Settings allows the user to modify the operation of the Starflow QSD, it contains very important factors which are used to interpret the Starflow QSD data. To see these options, use the following steps: Click on the Sonic Icon.
  • Page 80 Manual – Starflow QSD Model 6527B and 6537A 1. When the SONIC window appears click on the Connect button. 2. When connected Click on Settings and then Configure QSD. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 80...
  • Page 81 Manual – Starflow QSD Model 6527B and 6537A Settings: Serial No. - This is not configurable QSD Settings: QSD Modbus Addr – This can be set between 0-254 for multiple Modbus instruments on a single bus. Low Battery (V) – This Voltage setting determines when the Ultrasonic sensors will no longer be powered to take measurements.
  • Page 82 Manual – Starflow QSD Model 6527B and 6537A CW Velocity Settings: Zero Result on RSSI Fail – If the Signal strength is poor in the water and if this setting is enabled, instrument will return a result of zero for velocity. Otherwise, it will return the last known velocity when the signal was above the minimum RSSI setting.

  • Page 83: Log Buffer

    Manual – Starflow QSD Model 6527B and 6537A 11.3.1. Log Buffer Open the Log Buffer window by clicking on the Log Buffer icon. The Log Buffer window is where you set up the logger memory for recording data by selecting what to log and how often to log it. Starflow QSD loggers have one Main buffer. 11.3.2.

  • Page 84: Log Intervals

    Manual – Starflow QSD Model 6527B and 6537A 11.3.3. Log Intervals The Log Interval is the time between logs. At each log, all the Instrument Channels ticked will be recorded into the Log Buffer. In the screenshot below, data will be logged every 5 minutes. The maximum log interval is limited by the scan rate.

  • Page 85: Saving The Scheme

    Manual – Starflow QSD Model 6527B and 6537A 11.3.4. Saving the Scheme Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 85...
  • Page 86 Manual – Starflow QSD Model 6527B and 6537A To save your scheme, click the Save icon. If you’ve saved your scheme before it will immediately save it. If you’ve never saved the scheme before, the dialog shown below will appear. You can get the same dialog at any time by selecting Save Scheme...

  • Page 87: Programming Starflow Qsd

    Manual – Starflow QSD Model 6527B and 6537A 12. PROGRAMMING STARFLOW QSD Loggers are programmed from the main screen, by clicking on the Program icon, shown to the right. You will be asked to confirm before the programming will proceed: Clicking OK will program the new scheme.

  • Page 88: Test Mode

    Manual – Starflow QSD Model 6527B and 6537A 13. TEST MODE Test Mode is used to check the status of the logger, and to monitor its logging progress. To enter Test Mode, click on the Test Mode icon. A window like the following will appear: Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 88...

  • Page 89: Scheme Channels

    Manual – Starflow QSD Model 6527B and 6537A The Scheme shows the name of the scheme that has been programmed into the logger. The scheme logging parameters can be checked as highlighted below, on the right side of the screen, live logged data can be viewed. 13.1.

  • Page 90: Unloading Data From Loggers

    Manual – Starflow QSD Model 6527B and 6537A 14. UNLOADING DATA FROM LOGGERS Once you’ve had your logger operating for a while, it will have recorded some data. Unloading is the action of copying the data stored in the data logger into a CSV (comma- separated value) file on your computer.
  • Page 91 Manual – Starflow QSD Model 6527B and 6537A Incremental Unload: This unloads all data logged since the last time you unloaded the logger. If you’ve never unloaded the logger since you programmed it, this will be a Full Unload. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 91...
  • Page 92 Manual – Starflow QSD Model 6527B and 6537A When complete, the newly unloaded data will be added to the data file location where the software has been installed. You can view a CSV file by double-clicking on it, in the list. Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 92...

  • Page 93: Viewing Data

    Manual – Starflow QSD Model 6527B and 6537A 15. VIEWING DATA Starlog V4 is not data processing software. We recommend that you use Hydsys, or similar to process data. The data viewer is for functional testing only. To view data that you have previously unloaded, click the View Data icon (shown to the right).

  • Page 94: Graph View

    Manual – Starflow QSD Model 6527B and 6537A 15.2.1. Graph View The default mode for viewing your data is Graph View. This shows a zoomable graph on the left and individually selectable channels on the right. Untick or tick channels to hide or show them.

  • Page 95: Opening With Notepad

    Manual – Starflow QSD Model 6527B and 6537A 15.2.3. Opening with Notepad Opening your data file in Notepad can be useful if you suspect some file corruption. Notepad doesn’t try to interpret the data, so you can scan through it and manually correct any anomalies.
  • Page 96 Manual – Starflow QSD Model 6527B and 6537A Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 96...

  • Page 97: Power Failure

    Manual – Starflow QSD Model 6527B and 6537A 16. POWER FAILURE The Starflow QSD has an internal capacitor that allows for 4 hours of a power outage. This will allow the internal clock to keep operating for this period of time, but logging will stop.

  • Page 98: Diagnostics

    Manual – Starflow QSD Model 6527B and 6537A 17. DIAGNOSTICS Diagnostics are accessed from the main Starlog V4 window by selecting the Diagnostics tab on the left toolbar. Please see the screenshot to the right. Diagnostics provides several functions to assist you with various problems you may encounter using data loggers.

  • Page 99: Velocity Histograms

    Manual – Starflow QSD Model 6527B and 6537A 17.2. Velocity Histograms The Velocity Histograms that you will see by using Velocity Trace from the Control Panel are the Starflow QSD’s view of the channel. It is the composite of a range of factors, including both characteristics of the equipment, the sampling method, and the velocity dynamics within the channel.

  • Page 100: Inherent Factors In Doppler Histograms

    Manual – Starflow QSD Model 6527B and 6537A In fast turbulent water, the peak can be 500 mm/sec or wider because of the range of velocities present in eddies and swirls. The following histogram is typical. 17.3. Inherent Factors in Doppler Histograms The width and shape of the peak displayed are caused by a range of factors, all of which are measured by the Doppler as a frequency shift.

  • Page 101: Measuring Errors Due To "Signal Noise

    Manual – Starflow QSD Model 6527B and 6537A The Doppler shift measured is the velocity component along the line between the particle and the transmitter, so this changes by 5% as the particle traverses the beam. 17.5. Measuring Errors Due To “Signal Noise” “Signal Noise”...

  • Page 102: The Nature And Location Of The "Reflectors" In The Water

    Manual – Starflow QSD Model 6527B and 6537A In a channel with laminar flows, the shape of the peak remains symmetrical. If other factors disturb the velocity profiles within the field of view of the Starflow QSD, the histogram may become distorted.

  • Page 103: Velocity Variations Due To Cross-Section Changes

    Manual – Starflow QSD Model 6527B and 6537A 17.8. Velocity Variations Due to Cross-Section Changes If changes to the channel cross section introduce different velocity regimes within the view of the Starflow QSD, the histogram is distorted. At low flows in clean streams, the beam can be reflected for some distance and “see”...

  • Page 104: Measuring Unexpected Velocities

    Manual – Starflow QSD Model 6527B and 6537A 17.9. Measuring Unexpected Velocities In some cases, signals are from the wrong targets. A waving weed, aquatic animals, a strong stationary reflector in the bed, slow-moving saltation targets or ripples on the surface can all produce Doppler shifts that are not directly related to the water velocity.

  • Page 105: Measuring Turbulent Velocities

    Manual – Starflow QSD Model 6527B and 6537A 17.10. Measuring Turbulent Velocities In higher bed slope streams, wide and multiple peaks may be displayed because of the complex moving landscape presented to the Starflow QSD. The fact that many repeats of similar velocity histograms are seen indicates that the different velocity components seen are valid.

  • Page 106: Effects Of Surface Ripples

    Manual – Starflow QSD Model 6527B and 6537A 17.11. Effects of Surface Ripples In shallow water, the presence of ripples or small waves on the surface can cause complications. The ripples may be caused by wind or be a feature of the channel caused by obstructions in the channel or by irregularities on the bank.

  • Page 107: Measuring Flows In Very Small Channels

    Manual – Starflow QSD Model 6527B and 6537A In practice, a series of histograms in such a situation will move back and forth between the two extreme conditions, logging an average that is not the correct velocity. At some sites, ripples will be a characteristic at certain levels.

  • Page 108: Measuring Velocities In Very Shallow Water

    Manual – Starflow QSD Model 6527B and 6537A Legitimate velocity - some noise Velocity too slow - only noise remaining. 17.14. Measuring Velocities in Very Shallow Water Poor quality velocity data will result if the water becomes so shallow that the top of the eyes of the transducer comes out of the water.

  • Page 109: Burying The Transducer In Sand

    Manual – Starflow QSD Model 6527B and 6537A 17.15.2. Burying the Transducer in Sand Part-buried sensors continue to operate. Provided some parts of both velocity sensors are above the sand level, the velocity recorded is the same as if the sensor was clear. Completely buried sensors result in the signal collapsing.
  • Page 110 Manual – Starflow QSD Model 6527B and 6537A 17.15.2.2. Disruption of the Flow Pattern by Debris Larger debris in the vicinity may affect the logged values by changing the velocity distribution in the field of view of the sensor. The flow distribution in the channel may no longer be laminar, and the relationship between the logged and mean channel velocity may be distorted.

  • Page 111: Initialise

    Manual – Starflow QSD Model 6527B and 6537A 17.15.2.3. Blocking of the Signal Paths by Objects One strategically placed solid object, such as a rock, stick or other acoustically opaque material, may block the path to either sensor, blanketing any signals. Zero signals will be dominant;...

  • Page 112: Upgrade Firmware

    Manual – Starflow QSD Model 6527B and 6537A 17.18. Upgrade Firmware The Upgrade Firmware function allows you to upgrade the internal firmware of the Starflow QSD logger. Upgrade Firmware: Click to upgrade. You will then need to select the file, which will only be provided by the Unidata support team.
  • Page 113 Manual – Starflow QSD Model 6527B and 6537A Unidata Manual - 6527B and 6537A Starflow QSD User Manual 08 05 2023.docx Page 113...
