Milky FJ 90 Operating Instruction

Cream separator
Hide thumbs Also See for FJ 90:
Table of Contents

Advertisement

Quick Links

Download this manual
de
BETRIEBSANLEITUNG
en
OPERATING INSTRUCTION
fr
NOTICE D'UTILISATION
230 V - Type 17597
115 V - Type 17597-115
MILCHZENTRIFUGE FJ 90, FJ 130 EPR, FJ 130 ERR
CREAM SEPARATOR FJ 90, FJ 130 EPR, FJ 130 ERR
CENTRIFUGEUSE À LAIT FJ 90, FJ 130 EPR, FJ 130 ERR
230 V - Type 17602
115 V - Type 17602-115
JANSCHITZ GmbH | Eisenstraße 81 | A-9330 Althofen
T: +43 4262-2251-0 | F: +43 4262-2251-13
E: office@janschitz-gmbh.at | www.janschitz-gmbh.at
230 V - Type 17598
115 V - Type 17598-115
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FJ 90 and is the answer not in the manual?

Questions and answers

Related Manuals for Milky FJ 90

Summary of Contents for Milky FJ 90

  • Page 1 MILCHZENTRIFUGE FJ 90, FJ 130 EPR, FJ 130 ERR CREAM SEPARATOR FJ 90, FJ 130 EPR, FJ 130 ERR CENTRIFUGEUSE À LAIT FJ 90, FJ 130 EPR, FJ 130 ERR JANSCHITZ GmbH | Eisenstraße 81 | A-9330 Althofen T: +43 4262-2251-0 | F: +43 4262-2251-13...

  • Page 2: Table Of Contents

    Warranty Dear Customer! We are happy, that you have chosen Milky. We hope, that our device will serve you as a helpful tool for a long time without any problems. We would be happy, if you could recommend us to your friends.

  • Page 3: General Safety Recommendations

    GENERAL SAFETY RECOMMENDATIONS BEFORE ANY INSTALLATION, READ THIS MANUAL VERY CAREFULLY. MAKE SURE, THAT YOU HAVE CLOSED TOP BOWL FIXING NUT TIGHTLY. DISCONNECT DEVICE FROM MAINS BEFORE CLEANING. DON’T REPAIR THE DEVICE BY YOURSELF, IN CASE OF MALFUNCTION RATHER CALL AUTHORIZED SERVICE PROVIDED BY YOUR DISTRIBUTOR. TAKE CARE THAT WATER OR HUMIDITY WILL NOT COME INTO THE DEVICE, ESPECIALLY BY CLEANING PROCEDURES.

  • Page 4: Technical Specifications

    TECHNICAL SPECIFICATION Item MZF FJ 90 MZF FJ 130 Operating Voltage (model 230V) V / Hz 230 / 50 230 / 50 Operating Voltage (model 115V) V / Hz 115 / 60 115 / 60 Motor Power Max. Rotating speed...

  • Page 5: Assembling Procedure

    HOW TO ASSAMBLE THE CREAM SEPARATOR Put the housing on a desk or other plain and stable surface. Put assembled top bowl on the conical motor beam and softly press it. Put skimmed milk outlet on the top and then also cream outlet on the top of the housing Turn top bowl with hand and check if nothing is touching the outlets.

  • Page 6: Top Bowl Assembling Procedure

    TOP BOWL ASSEMBLING PROCEDURES Put the rubber washer into the notch of top bowl bottom part. Place the metal discs in the top bowl. Take care with the placement of the discs - device uses two different types of disks - plain and relief discs. First, insert relief disc, then plain disc and repeat the procedure until all discs are placed.

  • Page 7: Skimming Regulation

    PLEASE NOTE! After you have finished skimming, pour approximately 1/2 l of skim- med milk back into milk container. This will clean the rest of cream in the top bowl. After all procedures are finished, simply turn OFF the device and wait until motor stops.

  • Page 8: Top Bowl Cleaning Procedure

    TOP BOWL CLEANING PROCEDURE With the key, which is packed with the cream separator, unscrew the top bowl fixing nut as it is shown on the picture below. The easiest way to perform this procedure is: Fix key into the holes, which are on the top bowl fixing nut. Press the key down and turn it until the fixing nut is released.

  • Page 9: List Of Composing Parts

    PART LIST Part. no. MZF FJ 90 Part. no. MZF FJ 130 Name Foot 3711019 3711019 Bottom cover 3171017 3171017 Motor 230 V 17595 26000 Motor 115 V 17596 26001 Main switch 371151 371151 Cover of main switch 371153 371153...

  • Page 10: List If Composing Parts Top Bowl

    PART LIST TOP BOWL Name Part. no. MZF FJ 90 Part. No. MZF FJ 130 Top bowl balanced 3712021-B 375021-B Teileliste der Trommel Rubber washer 3711033 3711033 Metal disc relief 3711025 3711025 Ersatzteil Art. No.: 1. Trommelunterteil SE 404930 Metal disc plain...

  • Page 11: Spare Parts Ordering Procedure

    SPARE PARTS ORDERING PROCEDURE Fast and reliable shipment of spare parts is only possible, if the description is clear enough. At the time of ordering please state clearly: • Type of cream separator. • Serial number printed on the label plate at the bottom side of the device. •...
  • Page 12 Janschitz GmbH Eisenstrasse 81 9330 Althofen AUSTRIA Tel.: +43 4262 2251-0 Fax: +43 4262 2251-13 Email: office@janschitz-gmbh.at www.janschitz-gmbh.at...

This manual is also suitable for:

Fj 130 eprFj 130 err
