- Page 1 ELECTRONIC NO FROST COMBI REFRIGERATOR Freezer - Fridge User manual FRIGORIFERO COMBINATO NO FROST Congelatore - Frigorifero Manuale per l’utente ELEKTRONISCHE NIET-BEVRIEZEN COMBI KOELKAST Diepvriezer - Koelkast Gebruikshandleiding FC3732PXNFE...
-
Page 2: Table Of Contents
Index BEFORE USING THE APPLIANCE ......... 4 General warnings..............4 Safety warnings ................ 7 Installing and operating your fridge........... 8 Before Using your Fridge ............9 Information about New Generation Cooling Technology ..9 THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ............ - Page 3 Refrigerator compartment ............25 Freezer compartment .............. 26 SHIPMENT AND REPOSITIONING ........ 31 Repositioning the door ............. 31 BEFORE CALLING YOUR AFTER SALES SERVICE ... 32 TIPS FOR SAVING ENERGY .......... 36...
-
Page 4: Before Using The Appliance
BEFORE USING THE APPLIANCE General warnings WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the... - Page 5 BEFORE USING THE APPLIANCE - staff kitchen areas in shops, offices and other working environments - farm houses and by clients in hotels, motels and other residential type environments - bed and breakfast type environments; - catering and similar non-retail applications •...
- Page 6 BEFORE USING THE APPLIANCE Old and out-of-order fridges • If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. • Old fridges and freezers contain isolation material and refrigerant with CFC.
-
Page 7: Safety Warnings
BEFORE USING THE APPLIANCE Safety warnings • Do not use multiple receptacles or extension cord. • Do not plug in damaged, torn or old plugs. • Do not pull, bend or damage the cord. • This appliance is designed for use by adults, do not allow children to play with the appliance or let them hang off the door. -
Page 8: Installing And Operating Your Fridge
BEFORE USING THE APPLIANCE Installing and operating your fridge Before starting to use your fridge, you should pay attention to the following points: • Operating voltage for your fridge is 220-240 V at 50Hz. • Mains cord of your fridge has a grounded plug. This plug should be used with a grounded receptacle that has a 16 ampere fuse minimum. -
Page 9: Before Using Your Fridge
BEFORE USING THE APPLIANCE Before Using your Fridge • When it is operated for the first time or after transportation, keep your fridge in the upright position for 3 hours and plug it on to allow efficient operation. Otherwise, you may damage the compressor. - Page 10 THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model.
-
Page 11: The Parts Of The Appliance And The Compartments
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS 1) Wine rack (In some models) 2) Fridge shelves 3) Chiller (In some models) 4) Crisper cover 5) Crisper 6) Freezer top-middle basket 7) Freezer bottom basket 8) Leveling feet 9) Ice tray 10) Freezer glass shelves 11) Bottle shelf 12) Adjustable door shelf (In some models not adjustable) -
Page 12: The Various Function And Possibilities
THE VARIOUS FUNCTION AND POSSIBILITIES Display and control panel... - Page 13 THE VARIOUS FUNCTION AND POSSIBILITIES Use of control panel 1. It is cooler set value screen. 2. It is super cooling indicator. 3. It is freezer set value screen. 4. It is super freeze indicator. 5. It is alarm symbol. 6.
-
Page 14: Operating Your Fridge
THE VARIOUS FUNCTION AND POSSIBILITIES Operating your fridge Super freeze mode How would it be used? • Press freezer set button until Super freeze symbol will be seen on the screen. Buzzer will sound beep beep. Mode will be set. During this mode: •... -
Page 15: Holliday Mode
THE VARIOUS FUNCTION AND POSSIBILITIES During this mode: • Freezer may be adjusted. When economy mode will be cancelled, the selected setting values will proceed. • Cooler may be adjusted. When economy mode will be cancelled, the selected setting values will proceed. •... -
Page 16: Drink Cool Mode
THE VARIOUS FUNCTION AND POSSIBILITIES Drink cool mode When would it be used? This mode is used to cool the drinks within adjustable time. How would it be used? • Press freezer button for 3 seconds. • Special animation will start on freezer set value screen and 05 will blink on cooler set value screen. -
Page 17: Cooler Temperature Settings
THE VARIOUS FUNCTION AND POSSIBILITIES • If no button is pressed within 5 seconds after child lock is activated, the lights of the control panel will turn off. You can see latest status of settings or modes after you pres any button. While control panel ‘s light is on, you can cancel child lock as described in the instruction of this mode. -
Page 18: Function Of Child Lock
THE VARIOUS FUNCTION AND POSSIBILITIES Super Freeze Mode, Super Cool Mode or Economy Mode is activated will remain the same when the mode is over or cancelled. The appliance continues to operate with this temperature value. Function of Child lock When would it be used? To prevent children from playing with the buttons and changing the settings you have made, child lock is... -
Page 19: Warnings About Temperature Adjustments
THE VARIOUS FUNCTION AND POSSIBILITIES Warnings about Temperature Adjustments • Temperature adjustments should be made according to the frequency of door openings and the quantity of food kept inside the fridge. • Your fridge should be operated up to 24 hours according to the ambient temperature without interruption after being plugged in to be completely cooled. -
Page 20: Accessories
ACCESSORIES Freezer box The freezer box allows foods are maintained more regularly. Removing The freezer box; • Pull the box out as far as possible • Pull the front of box up and out. ! Make the inverse of the same operation for the resetting the sliding compartment. -
Page 21: Humidity Controler
ACCESSORIES Humidity Controler (In some models) When the humidity controler in the closed position, it allows fresh fruit and vegetables to be stored longer. In case of the crisper is totally full, the fresh dial is located in front of crisper, should be opened. -
Page 22: Adjustable Door Shelf
ACCESSORIES Adjustable Door Shelf (In some models) Six different height adjustments can be made to provide storage areas that you need by adjustable door shelf. To change the position of adjustable door shelf ; Figure -1 Hold the bottom of the shelf and pull the buttons on the side of the door shelf direction of arrow (Fig.1). -
Page 23: Cleaning And Maintenance
CLEANING AND MAINTENANCE • Make sure to unplug the fridge before starting to clean it. • Do not wash your fridge by pouring water. • You can wipe the inner and outer sides with a soft cloth or a sponge using warm and soapy water. •... -
Page 24: Replacing Led Lighting
CLEANING AND MAINTENANCE • Make sure you have disconnected the plug of your refrigerator before cleaning the vaporization container. • Remove the vaporization container from its position by unscrewing the screws as indicated. Clean it with soapy water at specific time intervals. -
Page 25: Arranging Food In The Appliance
ARRANGING FOOD IN THE APPLIANCE Refrigerator compartment • For normal operating conditions, adjusting the temperature value of the cooler partition of the fridge to 4°C will be enough. • To reduce humidity and consequent increase of frost never place liquids in unsealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the evaporator and in time will require more frequent defrosting. -
Page 26: Freezer Compartment
ARRANGING FOOD IN THE APPLIANCE Freezer compartment • Please use the deep freeze compartment of your refrigerator for storing the frozen food for a long time and for producing ice. • To get maximum capacity for freezer compartment, please just use glass shelves for upper and middle section. - Page 27 ARRANGING FOOD IN THE APPLIANCE Important note: • Frozen foods, when thawed, should be cooked just like fresh foods. If they are not cooked after being thawed they must NEVER be re- frozen. • The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar, assorted spices, ginger, garlic, onion, mustard, thyme, marjoram, black pepper, etc.) changes and they assume a strong taste when they are stored for a long period.
- Page 28 ARRANGING FOOD IN THE APPLIANCE Maximum Storing time Meat and fish Preparation (month) Steak Wrapping in a foil 6 - 8 Lamb meat Wrapping in a foil 6 - 8 Veal roast Wrapping in a foil 6 - 8 Veal cubes In small pieces 6 - 8 Lamb cubes...
- Page 29 ARRANGING FOOD IN THE APPLIANCE Maximum Vegetables and Storing Preparation Fruits time (months) String beans and Wash and cut to small pieces and 10 - 13 beans boil in water Beans Hull and wash and boil in water Cabbage Cleaned and boil in water 6 - 8 Clean and cut to slices and boil in Carrot...
- Page 30 ARRANGING FOOD IN THE APPLIANCE Maximum Dairy Preparation Storing time Storing Conditions Products (months) Packet Pure Milk – In its (Homogenize) 2 - 3 packet own packet Milk Original package may be used for Cheese- short storing period. excluding In slices 6 - 8 It should be wrapped white cheese...
-
Page 31: Shipment And Repositioning
SHIPMENT AND REPOSITIONING • Original package and foam may be kept for re- transportation (optionally). • You should fasten your fridge with thick package, bands or strong cords and follow the instructions for transportation on the package for re-transportation. • Remove movable parts (shelves, accessories, vegetable bins etc.) or fix them into the fridge against shocks using bands during re-positioning and transportation. -
Page 32: Before Calling Your After Sales Service
BEFORE CALLING YOUR AFTER SALES SERVICE Check Warnings; Your fridge warns you if the temperatures for cooler and freezer are in improper levels or when a problem occurs in the appliance. Warning codes are displayed in the Freezer and Cooler Indicators. ERROR TYPE ERROR TYPE WHAT TO DO... - Page 33 BEFORE CALLING YOUR AFTER SALES SERVICE When the power This is not a failure. This supply gets lower prevents any damages "Low voltage “--” than 170 V the on the compressor. This Warning" appliance gets to warning will off after the steady position.
- Page 34 BEFORE CALLING YOUR AFTER SALES SERVICE • Is your appliance stable? Are the legs adjusted? • Is there anything behind your fridge? • Are the shelves or dishes on the shelves vibrating? Re-place the shelves and/or dishes if this is the case. •...
- Page 35 BEFORE CALLING YOUR AFTER SALES SERVICE If the edges of fridge cabinet that the door joint contact are warm; Especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the compressor, this is normal. IMPORTANT NOTES: •...
-
Page 36: Tips For Saving Energy
TIPS FOR SAVING ENERGY 1– Install the appliance in a coll, well vantilated room , but not in direct sunlight and not near heat source (radiator, cooker.. etc). Otherwise use an insulating plate. 2– Allow ward food and drinks to cool down outside the appliance. 3–...
