Rose electronics VideoSplitter VSP-1X16VB Specifications

VideoSplitter
Features and Benefits
Models are available to switch one video source to
two, four, eight, or sixteen video monitors or two
video sources to two, four, or eight video monitors.
Easy to install, operate and expand
Units can be daisy-chained together to drive 256 or
more monitors using the 1x16 model
Uses VGA style connectors; HD15F to the monitors;
HD15M to the computer(s)
Monitors can be located up to 250 feet away from
your video source with optional extended distance
cables
Designed to drive long cables with high capacitance
Internal gain adjustment to increase brightness
Output enable turns off the video on all but port one
Optional A/B switch on dual source units enables you
to easily switch from two different CPUs
Rack mount kits available in 19", 23", and 24" sizes
Made in the USA
Video Distribution Amplifier
with up to 16 video outputs
Drives multiple monitors from
1 or 2 CPUs
Models available to drive 2, 4, 8, or
16 monitors
Easy Installation and expansion
Inhibit feature for set-up and maintenance
The VideoSplitter™ Advantage . . .
The VideoSplitter was designed to take one or two
video sources and distribute the video to multiple
monitors. These monitors can be located as far
away as 250 feet using extended distance cables.
The VideoSplitter is ideal for use in: classrooms,
conference rooms, point-of-sale terminals, trading
floors, airports, restaurants, process control areas,
and in security systems. Any application requiring
multiple monitor capability would be perfect for the
VideoSplitter. You can daisy-chain units together to
drive additional monitors if needed.
For control or setting up a presentation, a blanking
feature is available that will inhibit the video from
displaying on all monitors except port one. This
allows the presenter to organize and edit the video
before it is distributed to all monitors. On the two
input models, an added feature is the built-in A/B
switch. This allows you to switch two different
video sources to multiple video monitors.
The VideoSplitter is rack mountable with optional
19", 23", and 24" rack mount kits.
Drive multiple monitors
From 1 or 2 computers
W W W . R O S E . C O M
