LEDISONS LDM43-1250-ZI Quick Start Manual

Zigbee 12V Driver
Important: Read All Instructions Prior to Installation

Function introduction

NC
NC
ZigBee LED Driver
AC 200-240V input
Program Key:
press and hold down to increase/decrease light intensity

Product Data

DC Voltage
Output
Max. Current
Rated Power
Voltage Range
Frequency
Input Power Factor (Typ.)
Efficiency (Typ.)
Input Current
Inrush Current (Typ.)
Over Current
Protection
Over Temperature
Working Temp.
Max. Case Temp.
Environment
Working Humidity
Storage Temp. &
Humidity
emc
300MHz
Handleiding
Anleitung
Manuel
+
LED output
-
NC
Prog key
short press to switch on/off load,
12V DC 24V DC
Max. 4.16A/ch Max. 2.08A/ch
max. 50W
200-240V AC
50/60Hz
>0.9
85% @ 230VAC 88% @ 230VAC
0.27A @ 230VAC
COLD START Max. 2A @ 230VAC
Yes, auto recovery after fault removed
Yes, auto recovery after fault removed
-20°C ~ +45°C
C
85 Ta="45°C"
° ( )
10% ~ 95% RH non-condensing
40 80 , 10% ~ 95% RH
- ℃ ~ + ℃
Safety Standards
LDM43-1250-ZI
Withstand Voltage
Safety&EMC
EMC Emission
EMC Immunity
MTBF
Others
Dimension
• Dimmable LED driver
• ZigBee CC LED light device based on ZigBee 3.0 protocol
• Max. output power 50W total
• 1 channel 12/24V DC constant voltage output
• Class II power supply, full isolated plastic case
• High power factor and efficiency
• Deep and smooth dimming to 0.1%
• Enables to control ON/OFF, light intensity of connected LED lights
• ZigBee end device that supports Touchlink commissioning
• Can directly pair to a compatible ZigBee remote via Touchlink
• Supports find and bind mode to bind a ZigBee remote
• Supports zigbee green power and can bind max. 20 zigbee green power remotes
• Compatible with universal ZigBee gateway products
• Compatible with universal ZigBee remotes
• Waterproof grade: IP20
• 5 years warranty
Safety & Warnings
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.

Wiring Diagram

L
N
NC
NC
ENEC EN61347-1, EN61347-2-13 approved
I/P-O/P: 3.75KVAC
EN55015, EN61000-3-2, EN61000-3-3
EN61547, EN61000-4-2,3,4,5,6,8,11, surge immunity Line-Line 1KV
190300H, MIL-HDBK-217F @ 230VAC at full load and 25°C
ambient temperature
210*50*32mm (L*W*H)
+
-
NC
ZigBee LED Driver
Prog key
LED
