LEDISONS LDS15-WPF-ZWA Manual

SOLAR LIGHT PIANO
READ AND FOLLOW ALL INSTRUCTIONS BEFORE OPERATING YOUR SOLAR LIGHT.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Thank you for purchasing the solar up down light. We are committed to offering the
most effective home and garden solar lighting solution.

PARTS CONTAINED

1) 1X Aluminum Solar Lamp
2) 1X ST64 Filament bulb
3) 1X Dry-anchors and Screws
4) 1X Instruction

FEATURES

1) Solar panel: 5V,200mA
2) Lithium battery: LI-ION 3.7V 2000mAh
3) Filament Bulb:3V,2W
4) Lamp luminous: Full mode with 60 lumen and half mode with 30 lumen
5) Material:Aluminum lamp body and Glass

OPERATION

Select the required brightness by covering the solar panel and pushing the ON/OFF
switch.
Full brightness (first push)- Half brightness (second push)-OFF(third push).

INSTALLATION

•
Choose place where needs light at night and select a location where the unit will
receive abundant sunlight during the day.
•
Any cover or awning that shades the panel will affect the charging of the battery
resulting in a shorter run time at night.
•
Drill 2 holes on the wall according to the hole location from the wall mount and
insert the dry anchors.
•
Fix the screws in place and slide the lamp down onto the screws.
•
The light will turn on automatically after dusk. The light should not be placed clo-
se to other bright lighting such as streetlights as the the solarlight may not turn
on at night
Rendementstraat 5
8094 RA Hattemerbroek
MANUAL
LDS15-WPF-ZWA
