30" (76 CM) FREESTANDING ELECTRIC RANGES
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
DANGER
WARNING
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
IMPORTANT:
Save for local electrical inspector's use.
Installer: Leave installation instructions with the homeowner.
Homeowner: Keep installation instructions for future reference.
9758377
INSTALLATION INSTRUCTIONS
Table of Contents
RANGE SAFETY .................................................................. 1
INSTALLATION REQUIREMENTS..................................... 2
Tools and Parts ................................................................2
Location Requirements .................................................... 2
Electrical Requirements ................................................... 3
INSTALLATION INSTRUCTIONS....................................... 4
Unpack Range.................................................................. 4
Install Anti-Tip Bracket ..................................................... 5
Electrical Connection ....................................................... 6
Verify Anti-Tip Bracket Location ...................................... 9
Level Range....................................................................10
Complete Installation......................................................10
Moving the Range ..........................................................10
ANTI-TIP BRACKET TEMPLATE ....................................12
RANGE SAFETY
Your safety and the safety of others are very important.
A child or adult can tip the range and be killed.
Connect anti-tip bracket to rear range foot.
Reconnect the anti-tip bracket, if the range is moved.
Failure to follow these instructions can result in death or serious burns to children and adults.
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don't follow
instructions.
WARNING
Tip Over Hazard
