- Page 2 ADDAC107 Assembly Guide June.2023 ADDAC SYSTEM page 2...
- Page 3 ADDAC107 Assembly Guide STEP 1: Grab the pcb, gently brake it apart and trim the excess with a cutting plier. STEP 2: Locate the resistor and place it on the top of the soldered transistor like shown here. Once placed solder the resistor.
- Page 4 ADDAC107 Assembly Guide STEP 3: Next place and solder the capacitor vertically like shown here. Trim and save the 2 capacitor legs, it will be used later. STEP 4: Next place the spacer like shown here ADDAC SYSTEM page 4...
- Page 5 ADDAC107 Assembly Guide STEP 5: Place and solder the 1M trimmer (marked 105 on the top) Notice the trimmer is soldered at 90 degrees, flat against the pcb. STEP 6: Place and solder the 2x5 boxed pinheader. Notice the indent orientation marked on the pcb.
- Page 6 ADDAC107 Assembly Guide STEP 7: Next find the pinheaders insert the male into female and place them as shown, do not solder them yet. STEP 8: Once in place on front pcb place the back pcb on top and attach the back screw to keep pcbs parallel, proceed by soldering both pinheaders on top and bottom pcb.
- Page 7 ADDAC107 Assembly Guide STEP 9: Next we’ll place the remaining trimmers like shown below. 50k = 503 100k = 104 1k = 102 STEP 10: Next we’ll need to prepare some parts before placing them to the front panel. locate the jumper pinheader and the tall jumper shunt and attach them together...
- Page 8 ADDAC107 Assembly Guide STEP 11: Locate all trim pots and flatten out their legs with the help of some pliers, like shown below. STEP 12: Locate the jacks and cut the thinest leg like shown below. ADDAC SYSTEM page 8...
- Page 9 ADDAC107 Assembly Guide STEP 13: Locate the small pcb and slider switch, place the switch and solder it. STEP 14: Grab the pcb and solder the resistor and capacitor legs to its 4 points. STEP 15: Next we’ll start to populate the pcb, place the slide switch pcb like shown below.
-
Page 10: Slide Switch
ADDAC107 Assembly Guide STEP 16: Notice there’s 1 trim pot that is 100k and 2 others have a Mid Stop indent. Also Notice the 2 toggle switches are different. Same for the jacks, some are threaded some aren’t. Find and separate these first in order to avoid any misplacement Proceed by placing all parts on the pcb, notice the values, orientation and jack types shown below. - Page 11 ADDAC107 Assembly Guide STEP 17: Next, place the frontpanel and tighten all nuts. ADDAC SYSTEM page 11...
- Page 12 ADDAC107 Assembly Guide STEP 18: Adjust the height of the pcb keeping it parallel to the front panel and proceed to solder all parts. Also make sure the Slide Switch is flat against the frontpanel when soldered. Keep lines parallel...
- Page 13 ADDAC107 Assembly Guide Next start the procedure for soldering the jumpers, these will not follow the standard thru hole method, and will be soldered from the top and flush with the top of the pcb. STEP 19: Start by adding solder to the open holes.
- Page 14 ADDAC107 Assembly Guide STEP 20: Place the back screw. ADDAC SYSTEM page 14...
- Page 15 ADDAC107 Assembly Guide Finish it by placing the knobs and you’ve finished the assembly process! Proceed to the calibration method. ADDAC SYSTEM page 15...
- Page 16 ADDAC107 Assembly Guide Calibration TRIMMER LOCATIONS TUNING THE DECAY 1. Set the [VCA Decay] knob fully CCW 2. Send a trigger to the [Input] jack 3. Set Input Gain knob to 12 o’clock 4. Adjust the trimmer until there’s a very short decay 5.
-
Page 17: Assembly Guide
For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC107 ASSEMBLY GUIDE Revision.01 June.2023...
