MAINTENANCE AND
OPERATING MANUAL
CIRCULAR KNIFE
BREAD CUTTING MACHINE
MHS IDEAL SB
MHS IDEAL SBT
Vers.01 (02-2022→) Translation of the original
IDEAL SB series (EN)
Page 1-35

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IDEAL SB and is the answer not in the manual?

Questions and answers

Summary of Contents for MHS Boilers IDEAL SB

  • Page 1 MAINTENANCE AND OPERATING MANUAL CIRCULAR KNIFE BREAD CUTTING MACHINE MHS IDEAL SB MHS IDEAL SBT Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 1-35...
  • Page 2: Table Of Contents

    2.2.1. Information for maintenance personnel 2.2.2. Information for trained operating personnel 2.3. Safety devices 2.4. Safety check Technical description 3.1. Dimensioned drawing IDEAL SB 3.2. Technical data IDEAL SB 3.3. Function description 3.4. Controls 3.5. Environmental influences Device installation 4.1.
  • Page 3 Authorised representative for the creation of documentation - Christoph Stöcker, Im Deboldsacker 6, D-74232 Abstatt, Germany The machine of type IDEAL SB may be used exclusively for cutting foods such as bread. Other applications are explicitly prohibited. This declaration shall be void in the event that modifications are undertaken without prior agreement with MHS.
  • Page 4: General Instructions

    1 General instructions Dear Customer, this operating and maintenance manual will help you become familiar with the MHS IDEAL SB bread cutting machine and benefit from its intended applications. The Operating and Maintenance Manual contains important information required to use the device safely, properly and economically.
  • Page 5: Warranty Information

    1.2 PROPER USE The IDEAL SB cutter may be used exclusively for cutting fresh bread. Using it to slice other bakery products (e.g. cake, Danish pastries, etc.), dried or spoiled bread as well as any non- bakery products is strictly prohibited. Using the machine for slicing bread containing raisins or fruit will lead to increased cleaning requirements due to the high proportion of fat and sugar contained in such products.
  • Page 6: Copyright

    2.2 GENERAL SAFETY REGULATIONS The MHS IDEAL SB bread cutting machine is safe for use as per the requirements of the Directive of the Council of the European Union for Machines (2006/42/EC).
  • Page 7: Information For Maintenance Personnel

    If the safety clearance (clearance of field source from implant) of 30 cm is maintained, the influence on active implant (e.g. heart pacemakers, defibrillators) may be ruled out with high probability. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 7-35...
  • Page 8: Information For Trained Operating Personnel

    If necessary, have the machine checked by a service technician for risks such as electric shocks, fire hazards and health risks before putting it back into operation. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 8-35...
  • Page 9: Safety Devices

    The machine features a protective screen (1) in the cutting area, which protects the user against unwanted access and is secured against opening during operation. The protective screen and other protective devices are inspected via the proximity switches (7, 8, and 9). Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 9-35...
  • Page 10: Safety Check

    , shut down the machine immediately. ATTENTION! (pull out the power plug and secure it against reactivation) Arrange to have the machine checked by MHS Service prior to recommissioning. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 10-35...
  • Page 11: Technical Description

    -10°C to +45 °C Operational conditions: +5°C - +35 °C All accuracy and throughput specifications are approximate values only and can be influenced by the product to be sliced. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 11-35...
  • Page 12: Function Description

    3.3 FUNCTION DESCRIPTION The MHS Ideal SB bread cutter enables bakery products to be cut in slices to predefined thicknesses. This is completed using a rotating, toothed circular blade. 3.4 CONTROLS "Start" button for "thin, medium, thick" cutting Slice thickness buttons...
  • Page 13: Device Installation

    DEVICE INSTALLATION The transport, set-up, and commissioning of the MHS IDEAL SB bread slicer is carried out by MHS Schneidetechnik GmbH Service in accordance with the device installation. Setting up and commissioning the machine/system may only be carried out by specialist personnel of MHS Schneidetechnik GmbH or its authorised dealers.
  • Page 14 After such work is complete, the full function of all safety devices must be checked by the specialist before the machine may be approved for production once more. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 14-35...
  • Page 15: Operation

    In this case, the protective devices need to be checked (see chapters 2.3 + 2.4). After completing the cutting process, the blade must disappear completely outside of the cutting shaft. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 15-35...
  • Page 16: Positioning Of The Goods To Be Cut

    The goods to be cut must be inserted into the long, straight side of the front section (1) on the right-hand side of the machine. 5.3 CLOSING THE PROTECTIVE SCREEN Next, close the protective screen. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 16-35...
  • Page 17: Cutting Slices

    After the cutting process is complete, the protective screen may be opened again and the sliced bread may be removed. Place the bread on the bread rail and then pull the bag over the bread and the rail. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 17-35...
  • Page 18: Reading Out The Bread Counter

    Press the SET button to delete. The display blinks for 3 seconds. Press and hold the SET button once more for a period of 5 seconds within this time to reset the display. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 18-35...
  • Page 19: Reading Out The Error Memory

    The previous 10 errors can be displayed by successively pressing the SET button. After display of the last 10 errors, the display indicates EC. Press and hold the SET button for longer than 5 seconds to delete the error memory. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 19-35...
  • Page 20: Troubleshooting

    Provided that the regulations and information contained in the operating manual are complied with, the MHS IDEAL SB bread slicing machine operates normally and without any errors. In case of faults, we recommend checking the following points first before contacting the service...
  • Page 21 Poss. Item/type of part that is defective. This ensures that any repairs that may be required can be undertaken in the shortest possible time frame by competent personnel. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 21-35...
  • Page 22: Cleaning And Caring For Devices

    After each cleaning process, dry any surfaces that are still damp. Failure to observe these restrictions on cleaning can lead to the NOTE! exclusion of guarantee and warranty claims. Cleaning with a water jet is not permitted! Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 22-35...
  • Page 23: Cleaning The Protective Screen

    Check in particular all edges around the handle strips, guide rollers and guide rails for dirt and clean if necessary! Do not use scouring agents, highly alkaline cleaning products or sharp NOTE! tools for cleaning Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 23-35...
  • Page 24: Cleaning The Bread Chute

    Edges in the area of the bread chute and the cutting support must be checked for fouling in particular and cleaned as necessary! Then dry off the machine with a disposable cloth. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 24-35...
  • Page 25: Cleaning The Bread Claw

    1. Close the protective screen 2. Switch the machine on at the master switch (1). 3. and press "Start"- on the front display The machine is then ready for operation again. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 25-35...
  • Page 26 Now remove the crumb tray (5) and sweep out the cutting area before wiping it clean with a damp cloth. Then dry off the machine with a disposable cloth. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 26-35...
  • Page 27 Edges in the area of the cutting area must be checked for fouling in particular and cleaned as necessary! Remove the blade guard (9) to clean the blade guard! Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 27-35...
  • Page 28: Cleaning The Machine Housing

    Do not use scouring agents, highly alkaline cleaning products or sharp NOTE! tools for cleaning Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 28-35...
  • Page 29 In order to return to the initial position: 1. Close the protective screen 2. Switch the machine on at the master switch (1). 3. Press a "Start"- button. The machine moves to the initial position. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 29-35...
  • Page 30: Cleaning The Bread Gripper

    In order to do so, open the screw (1) with the supplied tool. The cover can now be removed in an upward direction. Clean the bread claw and the gripper. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 30-35...
  • Page 31: Care

    6.10 CARE Regular cleaning of the machine helps to prevent faults and malfunctions. Wartungs- uns Instandhaltungsarbeiten sollten wie im folgenden Kapitel beschrieben ausgeführt werden (s. a. Kap. 7). Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 31-35...
  • Page 32: Maintenance And Repair

    The knife now moves to the maintenance position  Press the "Unlock flap" (4) button while opening the flap While pressed, the display shows:  Switch off the machine again at the main switch (1). Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 32-35...
  • Page 33 Before releasing for operation, a trial run must be carried out in accordance with chapter 5.1 and the safety functions must be checked in accordance with chapter 2.4. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 33-35...
  • Page 34: Readjusting The Feed Belt

    Before releasing for operation, a trial run must be carried out in accordance with chapter 5.1 and the safety functions must be checked in accordance with chapter 2.4. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 34-35...
  • Page 35: Recommended Maintenance Intervals

     During all work, comply with the legal regulations on waste avoidance and proper recycling and disposal.  Dispose of electrical waste properly  Scrap metal parts  Recycle plastic parts  Dispose of lubricants and other auxiliary materials properly. Vers.01 (02-2022→) Translation of the original IDEAL SB series (EN) Page 35-35...

This manual is also suitable for:

Ideal sbt
