- Page 1 MOXIE E-BIKE INSTRUCTION MANUAL Do not use this product without carefully reading this instruction manual and understanding the performance of electric bicycles. Please keep the instruction manual properly.
- Page 2 HELMETS SAVE LIVES! Always wear a properly fitted helmet that complies with CPSC or CE safety standards when you ride your Gyrocopters Moxie e-bike. Correct Fitting: Make sure your helmet covers your forehead. Incorrect Fitting: Forehead is exposed and vulnerable to...
-
Page 3: Parts And Components
PARTS & COMPONENTS 1.Brake lever 2.Throttle 3.Power display 4.Gear shifter 5.Power switch 6.Basket 7.Front light 8.Front fork 9.Tire 10.Brake pad 11.Disc brake 12.Quick release lever 13.Fender 14.Fender strut 15.Frame 16.Pedal 17.Crankset 18.Chain 19.Battery 20.Chain guard 21.Kickstand 22.Rear derailleur 23.Motor 24.Spoke 25.Reflective spoke 26.Rear rack 27.Rear reflector... -
Page 4: Installation Of The Handlebar
1. Installation of the handlebar Handlebar assembly Adjust the height and handlebar alignment relative to wheel Tighten the screws with a Insert dust plug hexagon screwdriver 2.lnstallation of E-bike Seat Release the seat tube clip Insert seat tube... -
Page 5: Installation Of The Front Wheel
Adjusting the screw Lock the seat tube clip 3. Installation of the Front Wheel Remove the front fork protector Remove the brake protection pad Installation of the front axle Installation of the spring Front wheel assembly * Please note that the brake discs need to be inserted Into the brake synchronously. - Page 6 Squeeze the spring, Then the axle will pop out from the other side. Tighten the nut after spring installation Lock the front axle...
- Page 7 4.lnstallation of the Front Wheel Fender & Headlight Loosen pre-installed screws on front fork Installation of the fender Tighten the screws to finish fender and headlight assembly Loosen pre-installed screws on both sides Adjust 2 supporting frames of the fender. of front fork...
- Page 8 5.lnstallation of the Front Basket Remove screws on both sides as images shown Place the e-bike basket bracket 6. Installation of the Basket...
- Page 9 Installation of the side of basket as per the image shown Installation of bottom part of basket as per the image shown...
-
Page 10: How To Remove The Battery
7.lnstallation of the Pedals Installation of pedals based on label instruction. Label R: Pedal with label R should be installed clockwise on right side of the e-bike. Label L: Pedal with label L should be installed counterclockwise on left side of the e-bike. Mounting Right Pedal Mounting Left Pedal 8. - Page 11 Unlock battery with the key Remove the batter Note: Incorrect Battery Placement Wrong Right...
-
Page 12: Getting Started
2. Charging: Connect the DC jack of the original charger to the charging port of your Gyrocopters 6. Ride assistance : Moxie e-bike and the AC plug to the mains. The a. Throttle Assist: In Throttle Assist Mode, when charger light turns from red to green when the the power is on, you can accelerate and start the charging is complete. - Page 13 A downshift is moving from high to low gear, making pedaling easier for the rider. An upshift is moving to a higher or faster gear, which makes pedaling harder. While riding Moxie e-bike, you can upshift to go faster and downshift to go uphill. A shift is possible only when you are pedaling forward, i.e. the drive chain is moving forward and under some tension.
-
Page 14: Specification
SPECIFICATION Model Moxie 1850*610*1170mm Vehicle size Size Wheel Size 26inch Package size 1510*240*790mm Color White Weight 27kg Max load 120kg *Max speed 32km/h *Mileage (Fully electric) 55±3km Performance *Mileage (Pedal Assist) 70±5km Hill climbing capacity 15 degree Operating temperature -10~45℃... -
Page 15: Maintenance
MAINTENANCE About the charger Use only the factory designated charger and avoid charging in residential buildings. Keep it out of reach of children. Be careful with the charger plug to avoid damaging it and causing poor input/output. Make sure the charger is moisture-proof and waterproof. - Page 16 Otherwise, the company is not responsible for any damage to the product caused by improper use or error or the loss of personal property. For product-related information, please inquire on Gyrocopters.ca WEIGHT AND SPEED LIMITATIONS Speed and weight limits are set for your own safety. Please do not exceed the limits listed in the“...
-
Page 17: Operating Range
OPERATING RANGE The following are some of the major factors that will affect the operating range of your device. Terrain:Riding distance is highest when riding on a smooth, flat surface. Riding uphill and/or on rough terrain will reduce distance significantly. Weight: A lighter user will have further range than a heavier user. -
Page 18: Safety Alerts
Manufacturer warranty does not cover any physical or accidental damage due to improper usage. The warranty also does not cover normal wear and tear, damage to wheels, fenders, or any other physical damage, or water/liquid damage to your parts and units. For warranty information, Please visit us at www.gyrocopters.ca or Email us at customercare@gyrocopters.ca...
