- Page 1 BRIO MOUNTAIN E-BIKE INSTRUCTION MANUAL Do not use this product without carefully reading this instruction manual and understanding the performance of electric bicycles. Please keep the instruction manual properly.
- Page 2 HELMETS SAVE LIVES! Always wear a properly fitted helmet that complies with CPSC or CE safety standards when you ride your Gyrocopters Brio e-bike. Correct Fitting: Make sure your helmet covers your forehead. Incorrect Fitting: Forehead is exposed and vulnerable to...
-
Page 3: Parts And Components
PARTS & COMPONENTS 1.The riser 2.Acceleration handle 3.Handle grip 4.Variable speed finger 5.Battery display 6.Front reflector 7.Brake lever 8.Headlight 9.Front fork 10.Front wheel reflector 11.Tyre 12.Wheel 13.Spoke 14.Disc 15.Brake 16.Pedal 17.Chain wheel 18.Chain 19. Parking rack 20.Transmission 21.Tyre 22.Wheel 23.Spoke 24.Brake disc 25.Brake 26.Rear wheel reflector... -
Page 4: Getting Started
Gyrocopters long as the brake levers are not ultimately released. Brio e-bike and the AC plug to the mains. The charger light turns from red to green when the 8. Removing and Installing the Battery: Gyrocopters charging is complete. -
Page 5: Installing The Front Wheel
INSTALLING THE FRONT WHEEL Turn the anchor nuts clockwise to increase clamping, and anti-clockwise to decrease. II. How to install 1. To insert the front wheel, manually turn the anchor nuts anti-clockwise to loosen them up, and then insert the front wheel all the way into the dropouts of the front fork. - Page 6 A downshift is moving from high to low gear, making pedaling easier for the rider. An upshift is moving to a higher or faster gear, which makes pedaling harder. While riding Brio e-bike, you can upshift to go faster and downshift to go uphill. A shift is possible only when you are pedaling forward, i.e. the drive chain is moving forward and under some tension.
-
Page 7: Specification
SPECIFICATION Model BRIO Material Aluminum alloy frame Expanded size 1870*580*1110 mm Build Pedal height from ground 130 mm Wheel hub 27.5 inches Body color Black Net Weight 21.5 kg Maximum Load 120 kg *Max speed 32km/h 40±3km *Range in throttle mode *Range in pedal assist mode 55±5KM... -
Page 8: Maintenance
MAINTENANCE About the charger ● Use only the factory designated charger and avoid charging in residential buildings. Keep it out of reach of children. ● Be careful with the charger plug to avoid damaging it and causing poor input/output. Make sure the charger is moisture-proof and waterproof. - Page 9 Otherwise, the company is not responsible for any damage to the product caused by improper use or error or the loss of personal property. For product-related information, please inquire on Gyrocopters.ca WEIGHT AND SPEED LIMITATIONS Speed and weight limits are set for your own safety. Please do not exceed the limits listed in the“Specifications”...
-
Page 10: Operating Range
OPERATING RANGE The following are some of the major factors that will affect the operating range of your device. Terrain:Riding distance is highest when riding on a smooth, flat surface. Riding uphill and/or on rough terrain will reduce distance significantly. Weight: A lighter user will have further range than a heavier user. -
Page 11: Safety Alerts
Manufacturer warranty does not cover any physical or accidental damage due to improper usage. The warranty also does not cover normal wear and tear, damage to wheels, fenders, or any other physical damage, or water/liquid damage to your parts and units. For warranty information, Please visit us at www.gyrocopters.ca or Email us at customercare@gyrocopters.ca... - Page 12 Website: Gyrocopters.ca Phone: 647 846 1064 Address: 11-2340 Meadowvale Blvd, Mississauga, Ontario. Canada...
