2
OUT
1
OUT
RA2100b Power
Amplifier
The RA2100b is an ideal installation amplifier for
small to medium sized applications. The unit is built
solid and housed in a painted steel chassis. It also
includes special high performance transformers and
a fused power line. The MOSFET output stage is
fault protected which allows the R2100b to forgive
momentary output shorts. It is designed to drive 4 or
8 Ohm speakers, 25V speakers (individual channels)
or 70V speakers (in bridged mode). CAUTION: The
2100b is convection cooled. Adequate ventilation
room for the heat sink fins on the rear panel must
be provided for.

FEATURES:

• Great install amp, drives 25V or 70V lines
directly.
• MOSFET drivers in a voltage and current gain
circuit
• 1 second turn-on delay
• LED power output meters
• Fault protected outputs

SPECIFICATIONS

Power Output Stereo: 100 Watts RMS/ch. 4 Ohms
Bridged: 200 Watts RMS into 8 Ohms
Sensitivity:
THD:
S/N Ratio:
Power Bandwidth:
Damping Factor:
Slew Rate:
Phase Shift:
Input Impedance:
Power:
Size:
Weight:
ROLLS Coporation
5968 South 350 West, Salt Lake City, UT 84107
(801) 263-9053 FAX (801) 263-9068
info@rolls.com • www.rolls.com
85 Watts RMS/ch. 8 Ohms
or 70V
<1 VRMS for full output
<.08% (1kHz @ 1 Watt)
106 dBU
60 Hz - 30 kHz +/- 1dB
> 150
100 Volts/microSecond
<10 Deg., 20Hz - 20kHz
10 K Ohms Balanced
120 VAC 60Hz 2.5A
230 VAC 50Hz
19" x 3.5" x 7.5"
(48 x 9 x 19 cm)
12 lbs (5.5 kg)
