Summary of Contents for MISURA M16TB
- Page 1 TOUCHSCREEN PORTABLE MONITOR 16“ USER MANUAL ENGLISH Model: M16TB with built in battery 178° 1080 Working time Multi-Gesture Battery High Dynamic Super TFT Ultra Wide Ultra slim Touch screen 8000 mAh Range display 3– 4 hrs Viewing Angle monitor...
-
Page 2: Safety Information
MISURA. MISURA is not responsible for any errors or inaccuracies that may appear in this manual, including the products and software described in this manual. -
Page 3: What's In The Box
WHAT’S IN THE BOX 1. Portable monitor (FHD) 2. HDMI to mini HDMI 3. USB-C to USB-C cable 4. User manual 5. QC 3.0 USB-C cable and 18W charger 6. Magnetic case... -
Page 4: Device Layout
DEVICE LAYOUT RIGHT SIDE LEFT SIDE 1. Micro-USB Port 6. Mini HDMI Port Used to connect to keyboard / Video / Audio input port. mouse (may need USB-A 7. Speakers to micro USB adapter). Audio. 2. Power Indicator Light 8. Power Press and hold to turn off 3. - Page 5 USING MONITOR BUTTONS Power On / Off: Hold power button for 3 seconds to turn on and off. Return / Exit: Click power button while menu open to return or exit menu. Show Menu / Settings: Press wheel button. Select Menu Option: Click wheel button while menu open to confirm / select highlighted option.
-
Page 6: Led Indicator Light
LED INDICATOR LIGHT INPUT INDICATOR LIGHT Blue Color: ON / Input source detected. Red Color: No source / Standby status. Dark: OFF. POWER INDICATOR LIGHT Green Color: Charging / Not fully charged. Dark: Fully charged. MONITOR MENU SETTINGS PICTURE • Brightness: Select brightness level between 0 (lowest) to 100 (highest). •... -
Page 7: Osd Settings
OTHER • 3D Sound: Select 3D Sound • Sharpness: Select sharpness • Mute: Toggle ON (muted) or OFF (unmuted). • EyeProtection: ON or OFF. Low Blue Light Technology reduces the emission of the harmful low-blue lights on a display in order to prevent eye fatigue. -
Page 8: Power And Charging
POWER AND CHARGING Connect USB-C to Input Power USB-C Port: Note the Input Data Only port cannot charge or provide power to the monitor. The monitor most likely will not be able to be charged by your laptop as it requires QC 18W or 5V, 4A input power, which is a higher output than PCs and laptops have. - Page 9 HDMI will only input / output display and audio signal. However, you touch signal can work if you connect both HDMI and USB-C at the same time. Alternatively you can USB 3.0A to USB C can also transfer touch signal in conjunction with HDMI. Connect via USB-C Port: You can use single-finger touch or multi-finger touch for up to 70 simultaneous touch points.
- Page 10 USB-C Will consume built-in battery NOTICE: Check if the USB-C of your laptop/phone is a full featured life without input power. USB-C port. Your device should support Thunderbolt 3.0 or USB 3.1 Touch function is avaible. Gen2, USB-C DP ALT-MODE. If it is just a USB-C for charging, it will not be available.
- Page 11 USB-C Input power optional. Will consume built-in battery life without input power. Lightning to HDMI adapter iPhone / iPad Input power optional. Will consume built-in battery life without input power. NOTE: • Touchscreen function is only enabled when connecting to your device via USB-C as the HDMI connection does not output touch signal.
-
Page 12: Troubleshooting (Faq)
TROUBLESHOOTING (FAQ) 1. My screen does not turnon or I’m seeing a black / blank screen. It is likely your device is out of battery or you are connecting your external device to the Input Power port rather than the Input Data port. Monitor uses a very specific battery to optimize for power efficiency, size, and weight. - Page 13 4. Why doesn’t the touchscreen work? • Touchscreen will only work on devices that have been designed to receive touchscreen signal. For example some MacBooks cannot receive touchscreen inputs. Other devices that are not already touchscreen enabled will also not be able to receive input touchscreen signal. If your connected laptop is not already touchscreen compatible, Monitor will not be touchscreen compatible.
-
Page 14: Specifications
10. Screen image has color defects (white does not look white). • The monitor will shut down when the battery is out of power. • Make sure the device that powers Monitor has sufficient power. SPECIFICATIONS Model number M16TB touch monitor with battery Panel Type Touch function Size Backlight... - Page 15 Declaration of conformity according to the EMC Directive 2014/30 / EC on the harmonization of legal regulations of Member States related to electromagnetic compatibility. Manufacturer / importer: MISURA Store s.r.o. K Pošte 429/2 252 67 Tuchomerice Person responsible for completing the technical documentation: Ing.
- Page 16 Manuál vo Slovenčine otvoríte tu / Open the English manual from here / Das Handbuch in Deutsch können Sie öffnen hier / A magyar nyelvű kézikönyvet itt tudja megnyitni / Odprite priročnik v slovenščini tukaj / Aprire il manuale in italiano qui / URL: www.misura.shop/en/advisor/m16tb-manual-for-download...
