- Page 1 TOUCHSCREEN PORTABLE MONITOR 16“ USER MANUAL ENGLISH Model: M16T 178° 1080 Multi-Gesture High Dynamic Ultra Wide Ultra slim Super TFT Touch screen Viewing Angle monitor Range display...
-
Page 2: Safety Information
MISURA. MISURA is not responsible for any errors or inaccuracies that may appear in this manual, including the products and software described in this manual. -
Page 3: What's In The Box
WHAT’S IN THE BOX 1. Portable monitor (FHD) 2. HDMI to mini HDMI 3. USB-C to USB-C cable 4. User manual 5. USB-C cable and charger 6. Magnetic case... -
Page 4: Device Layout
DEVICE LAYOUT RIGHT SIDE LEFT SIDE 1. Micro-USB Port 7. Speakers Used to connect to keyboard / Audio. mouse (may need USB-A 8. Power to micro USB adapter). Press and hold to turn off 2. Power Indicator Light and on monitor. Tap to return while in menu. - Page 5 USING MONITOR BUTTONS Power On / Off: Hold power button for 3 seconds to turn on and off. Return / Exit: Click power button while menu open to return or exit menu. Show Menu / Settings: Press wheel button. Select Menu Option: Click wheel button while menu open to confirm / select highlighted option.
-
Page 6: Led Indicator Light
LED INDICATOR LIGHT INPUT INDICATOR LIGHT Blue Color: ON / Searching for Input Source Red Color: No source / Standby status. Dark: OFF. MONITOR MENU SETTINGS PICTURE • Brightness: Select brightness level between 0 (lowest) to 100 (highest). • Contrast: Select contrast level between 0 (lowest) to 100 (highest). •... -
Page 7: Osd Settings
OTHER • 3D Sound: Select 3D Sound • Sharpness: Select sharpness • Mute: Toggle ON (muted) or OFF (unmuted). • EyeProtection: ON or OFF. Low Blue Light Technology reduces the emission of the harmful low-blue lights on a display in order to prevent eye fatigue. -
Page 8: Power And Charging
PORTS AND CONNECTION VIDEO Connect Monitor to valid source via mini HDMI or USB-C port . Please note that not all PC, laptop, or mobile phone USB-C ports output display or video signal. Please see the FAQ for more information. POWER AND CHARGING Plug the Supplied AC Adaptor (or USB 3.0 Port From Other Device) to the Power Port of the Monitor to Get Power Supply. - Page 9 HOW TO CONNECT YOUR MONITOR Input Mini HDMI PC / Game Consoles / TV Box / etc. USB-C Data: Video Display / Audio / Touch signal Power: 5V-2A/5V-4A AC Adaptor /USB 3.0 port / Power bank Input Micro USB Port Keyboard / Mouse (needs Female USB A to Male micro USB adapter).
- Page 10 USB-C Touch function is avaible. NOTICE: Check if the USB-C of your laptop/phone is a full featured USB-C port. Your device should support Thunderbolt 3.0 or USB 3.1 Gen2, USB-C DP ALT-MODE. If it is just a USB-C for charging, it will not be available.
- Page 11 USB-C Input power optional. Will consume built-in battery life without input power. Lightning to HDMI adapter iPhone / iPad Input power optional. Will consume built-in battery life without input power. NOTE: • Touchscreen function is only enabled when connecting to your device via USB-C as the HDMI connection does not output touch signal.
-
Page 12: Troubleshooting (Faq)
TROUBLESHOOTING (FAQ) 1. Why the Monitor Without Display or Flash? There’s Maybe Because of Power Shortage ,Please Power the Monitor With the AC Adaptor 2. Audio is playing from my Monitor screen instead of my laptop or headphones. Please go into the audio / volume settings on your computer and switch output back to your laptop or headphones. - Page 13 6. The Power LED Light is on, but there is no screen image. • Ensure your monitor and input source have power and are on. • Check that your video input (USB-C or mini HDMI) are properly connected. • Inspect the signal cable and make sure the pins are not bent or damaged.
-
Page 14: Specifications
SPECIFICATIONS Model number M16T touch monitor Panel Type Touch function Size Backlight WLED Brithgness 300cd/m2 Contrast 1200:1 eDP (2 Lanes), eDP1.2 Pitch 0.0607×0.1821 mm (H×V) Resolution 1920×1080 Aspect 16/9 Response time(typ) 30ms View angle H:85º,V:85º(CR≥ 10) Surface Glare Display color 16.7M (8-bit) - Page 15 Declaration of conformity according to the EMC Directive 2014/30 / EC on the harmonization of legal regulations of Member States related to electromagnetic compatibility. Manufacturer / importer: MISURA Store s.r.o. K Pošte 429/2 252 67 Tuchomerice Person responsible for completing the technical documentation: Ing.
