- Page 1 5.14 DT-E TECHNICAL AND OPERATIONAL DOCUMENTATION INSTALLATION MANUAL, OPERATING MANUAL AND INSTRUCTIONS FOR SAFE USE (Translated from the original manual) 5. Steel and aluminium components and structural sets 5.14. Pergola SB400 PRO...
- Page 2 ALUMINIUM CONSTRUCTION PERGOLA SB400 PRO MARKING OF PRODUCT MANUFACTURER: Manufacturer name: SELT Sp. z o. o. KRS 0000589791, share capital: 64 000 000 zł NIP: 7543103311, REGON: 363154414, BDO no 000009177 Manufacturer’s registered office: 45- 449 Opole, ul. Wschodnia 23A ...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ................................4 SAFETY GUIDELINES FOR THE PRODUCT ......................... 4 EXPLANATION OF SYMBOLS AND SIGNS ......................... 4 TERMS AND DEFINITIONS ............................5 SUBJECT, INTENDED USE AND CONTENTS OF THE DOCUMENTATION ..............6 PRODUCT TECHNICAL INFORMATION .......................... 7 TECHNICAL PARAMETERS: ............................ -
Page 4: Introduction
INTRODUCTION SAFETY GUIDELINES FOR THE PRODUCT The product has been manufactured in accordance with the latest technical knowledge in the field of construction and manufacturing and meets the safety requirements in accordance with the following standards. Subject European Legal Basis Polish Legal Basis Execution of steel and aluminium structures... -
Page 5: Terms And Definitions
A situation that could damage the product or require user’s action. NOTE! No threat for people. This symbol indicates all information concerning safety, which could pose a hazard to human health or life in case of non-observance. The health of life hazard. -
Page 6: Subject, Intended Use And Contents Of The Documentation
Copyrights for this documentation remains with SELT Sp. z o.o. with its registered office in Opole. This documentation may not be used in any way, either in whole or in part, without the permission of SELT Sp. z o. o. -
Page 7: Product Technical Information
PRODUCT TECHNICAL IN FORMATION Technical specifications of the product are available after logging in on website www.selt.com TECHNICAL PARAMETERS : Pergola SB400PRO – free-standing Fig. 1. Pergola SB400PRO free-standing – Overall dimensions: B max – maximum width, L max – maximum projection, H max –... - Page 8 *- tolerances of external dimensions are +/-10 mm. Detailed data for parameters of the individual motors are available on the websites of motor manufacturers and on the website: www.selt.com→ OUR OFFER → ELECTRIC EQUIPMENT Translated from the original manual DT-E 5.14: ALUMINIUM CONSTRUCTION – SYSTEM PERGOLA SB400PRO...
-
Page 9: Product Specification
COMPLETENESS AND QUALITY CONDITION OF TH E DELIVERY Goods produced by SELT Sp. z o. o. are in accordance with their production technology. In the event of any reservations as to the product or damage to the product packaging, the reservations or comments should be reported to the driver / warehouseman / assembly team and marked on the WZ document under pain of losing claims in this respect, and a protocol describing these reservations or comments should be drawn up with the driver's participation. -
Page 10: General Conditions For Transport And Storage Of The Product
OBLIGATORY DESCRIPTI ONS TO BE PLACED ON THE PRODUCT PACKAGIN G Prior to installation and use of the product please read carefully the operation and maintenance manual available at the following website: https://www.selt.com/dte-en Translated from the original manual DT-E 5.14: ALUMINIUM CONSTRUCTION – SYSTEM PERGOLA SB400PRO... -
Page 11: Product Installation
This chapter contains general requirements concerning the product installation. Correct assembly is a necessary condition for smooth operation of the product. SELT Sp. o.o. recommends using only professional assembly crews, which guarantee the Purchaser that the conducted installation will be correct. -
Page 12: General Guidelines For Product Installation
Walls or floor should be load-bearing and adapted for transferring of forces from product anchoring, SELT shall not be responsible for damages caused by use of too weak anchoring components or fixing in the floor with too small load bearing, ... -
Page 13: Installation Tools
INSTALLATION TOOLS Installation instructions, operation and maintenance manual and instructions for safe use are available at www.selt.com after logging in. List: drill bits for metal and concrete, hammer drill, ladder / scaffolding, crane, bucket truck, loader crane, hydraulic crane, ... -
Page 14: Installation
INSTALLATION Fig. 4a View of the assembly of elements of the free-standing Pergola SB400PRO Fig. 4b. View of the assembly of Pergola SB400PRO modules Translated from the original manual DT-E 5.14: ALUMINIUM CONSTRUCTION – SYSTEM PERGOLA SB400PRO Edition 1 / April 2023 / EN page 14 / 53... - Page 15 Fig. 5a. View of the assembly of Pergola SB400PRO- wall-mounted (transverse). Fig. 5b. View of the assembly of Pergola SB400PRO- wall-mounted (lengthwise). Translated from the original manual DT-E 5.14: ALUMINIUM CONSTRUCTION – SYSTEM PERGOLA SB400PRO Edition 1 / April 2023 / EN page 15 / 53...
- Page 16 Before proceeding with the assembly, it is necessary to verify the visual condition of the packaging of the elements delivered for assembly, the visual condition of the elements and their completeness. For damages arising after the delivery (transfer of risk) SELT Sp. z o.o. is not responsible. ...
-
Page 17: Installation Of Standard Feet
4.6.1 INSTALLATION OF STANDARD FEET Install all feet to the appropriate post types. Screw on both sides with conical screws with M8x20 Allen socket. For feet with outflow set up the cutouts in the bottom of the sheet and the mouse hole accordingly for the drainage of water in the post and the foot. -
Page 18: Installation Of Aligned Feet
4.6.3 INSTALLATION OF ALIG NED FEET Insert the feet from the bottom of the posts (fig. 12) and temporarily tighten the feet from the sides with 1 screw on each side - see standard foot (point 4.6.1.). They are used to temporarily protect the bottom edges of the posts during the assembly of the frame. -
Page 19: Installation Of The Frame
4.6.4 INSTALLATION OF THE FRAME NOTE: Elements of the load-bearing structure during assembly should be secured against tipping over or falling onto the persons performing the assembly. The assembled supporting structure (frame) should be placed in the right place and anchored to the ground with a suitable fastening product. Suggested size of the anchors is M12. - Page 20 In case of adjustable feet carry out the final levelling and drilling of the bone to lock in the selected foot extension. 10. In case of aligned feet – trace the final position of feet and anchors. 11. Anchor the product to the ground (anchors are not supplied by SELT). The size of anchors is M12. Translated from the original manual DT-E 5.14: ALUMINIUM CONSTRUCTION –...
-
Page 21: Free-Standing Version - 4 Gutters
4.6.4.2 FREE-STANDING VERSION – 4 GUTTERS The lengthwise beam without angle overflows has a factory-fixed gutter and straight outflows. In case of other beams, the gutters require fixing during installation. All angular corner overflows also require tightening during assembly. Figure 19 Insert the angle overflow at the end into the lower chamber of the cross beam without a straight outflow so that the side with the oval cut overlaps with the hole in the beam. - Page 22 Figure 21 Slide the lengthwise beam on the bones of the cross frame posts from the side of the angular overflow (fig. 21- left). Before sliding the overflow with EPDM foam, additionally apply a strip of silicone tightly around the edge of the oval hole and around both small holes at its ends.
-
Page 23: Wall-Mounted Version - 2 Gutters
22. In case of adjustable feet carry out the final levelling and drilling of the bone to lock in the selected foot extension 23. In case of aligned feet – trace the final position of feet and anchors. 24. Anchor the product to the ground (anchors are not supplied by SELT). The size of anchors is M12. 4.6.4.3 WALL-MOUNTED VERSION –... - Page 24 Figure 25 Place the wall beam on the anchors and fasten it with the nut washer from the anchor. Tightening torque according to the anchor manufacturer's instructions (fig. 25). Cover the holes for the anchors in the beam with aluminium plugs set on silicone (fig. 25-right). Figure 26 Apply EPDM self-adhesive spacer tapes to the end caps at the ends of the lengthwise beams on the wall side at the upper and lower edge after degreasing them (fig.
-
Page 25: Wall-Mounted Version - 4 Gutters
100 mm. Embed M12 size anchors (not supplied by SELT) in the ground, ensuring that they are leveled together and that the axial spacing is consistent with the arrangement of holes in the beam. Maintain the correct distance of the anchor protrusion from the face of the wall in the range of W= min. - Page 26 upper and lower edge (fig. 30). Figure 31 Place the wall beam on the anchors and fasten it with the nut washer from the anchor (size M12). Tightening torque according to the anchor manufacturer's instructions (fig. 31). Cover the holes for the anchors in the beam with aluminium plugs set on silicone (fig. 31-right). Figure 32 Install the angular overflow at one end of each cross beam on the side without the planned post (fig.
- Page 27 Figure 34 12. Insert both cross beams successively into the ends of the lengthwise beam fixed on the wall – bone to the upper chamber and the arm of the angular overflow to the lower chamber, the end cap adheres to the wall - fig.34. 13.
-
Page 28: Modular Installation
Figure 38 22. Stud the outer slip rings into the large holes for the blade’s axis on the lengthwise beams (fig. 38). 4.6.5 MODULAR INSTALLATION Modular connection is made by joining individual frames together. Note: Seal the contact of modular pergolas from the top with silicone (EPDM gaskets do not ensure full tightness against precipitation). -
Page 29: Gutters Installation
4.6.6 GUTTERS INSTALLATION Gutters can be factory fixed to the beams depending on the ordered configuration. The other gutters should be tightened during the assembly. Pay attention to: - correspondence and overlapping of the oval drain holes, - compliance and alignment of the mounting holes in the beam and the top wall of the gutter, - gutters for lengthwise beams have a total length equal to the lengthwise beam, - transverse gutters are inserted between the lengthwise gutters and are shorter than the beams. -
Page 30: Blades Installation
Figure 43 It is possible to install an additional protective grate on the oval outflow. To do this, loosen both M5 screws at the ends of the hole and insert the ends of the grate with the fork cut into one screw as far as it will go, and then move it back towards the other (fig. - Page 31 Figure 45 Install small plastic slip rings into the holes in the lower corner of the end caps from the outside (fig.45). Blade pins do not have spacer rings applied. NOTE: The installation of plastic rings must not cause too much slack in the longitudinal blade and, consequently, its falling out, as this will create a hazard.
- Page 32 Figure 48 12. The drive rod equipped with all pins place in the gutter on the side of the drive beam. 13. Turn the blade vertically. 14. Lift the rod to the level of the lower hole in the blade drive end cap and apply it from the outside (between the end cap and the beam) to the side of the drive end cap (fig.
- Page 33 Figure 51 22. Install the next blades starting from the places already installed towards the ends of the pergola. Set the blade horizontally over the beam, tilt it and insert it with the shaft from the drive side into the hole in the beam. When pushed in as far as possible, lower the opposite end and insert it into the beam as well (steps 1 to 3 in Fig.
-
Page 34: Revision Installation
4.6.8 REVISION INSTALLATIO N Figure 53 Run the wiring in the top (open part of the beams) – fig. 53. The upper edges of the posts have open windows in the upper walls for cable routing. Insert the Louver control unit into the window of the upper part of the drive beam above the motor (fig. 53-right- arrow). -
Page 35: Foundation Guidelines
For a free-standing pergola with a maximum size of 4x7 m and in accordance with the location data (given in the table below), the maximum calculation reactions are*: Reaction directions with a V [kN] T1 [kN] T2 [kN] M1 [kNm] M2 [kNm] positive sign PERGOLA SUPPORT SB400 PRO 7,0x4,0 m -11,23 -0,51 2,68 -0,94 2,71 (presses) 6,64 (pulls -1,40... - Page 36 STREFA III – ZONE III - 1,2 m STREFA IV – ZONE IV - 1,4 m Selt recommends making foundations of reinforced concrete of min. C20/25 with a minimum size of 45x45 cm and a height: a) in the case of non-heavy soils, min. 70 cm,...
-
Page 37: System Operation And Product Safety
GENERAL REQUIREMENTS FOR OCC UPATIONAL HEALTH AND SAFETY To ensure correct operation of the product SELT Sp. z o.o. forbids making any structural changes; non-observance of the above condition releases the manufacturer from the liability for the product and the warranty will be invalidated. -
Page 38: Special Snow Load Requirements
It is essential to take account of reasonably foreseeable conditions of operation and potential threats during defining performance requirements for the product. Do not allow children to play with the roof controls. Remote control equipment should be kept away from children. -
Page 39: Operational Safety
2.1 “Technical parameters” (depending on the type of the motor and manufacturer, detailed data are available on the motor manufacturer’s website or www.selt.com). Exceeding the specified run-time of the motor can lead to permanent damage, ... -
Page 40: Connection To Electrical Installation
It is recommended to use wind automation to help meet safety conditions. If any abnormalities in product operation are detected then you should immediately inform the SELT Sp. o.o. service. Using damaged product and self-repairs pose a hazard for health and life and could be a reason of warranty invalidation. - Page 41 The instructions are attached to the product and are also available on the websites of motor manufacturers and on the website: www.selt.com → OUR OFFER → ELECTRIC EQUIPMENT Incorrect connection of the motor may damage the product or create a hazard.
-
Page 42: Control
Important Cables passing through a metal wall should be protected and insulated with a sleeve or a cover. Secure cables to prevent them from touching any moving parts. If the receiver is used outdoors and the power cord is of the H05-WF type, install the cable in a UV-resistant tray, e.g. - Page 43 The control unit can only be mounted inside the drive beam (through the window above the motor), or outside in a case with a protection degree of min. IP65. Failure to follow the manufacturer's instructions will void the warranty. Connecting the SOMFY Pergola Tilt 0 motor wires inside the Louver control unit (fig. 54): Fig.
-
Page 44: Start-Up And Adjustment
START-UP AND ADJUSTMENT Recommendations and actions: it is necessary to adjust the limit switches of the blades during assembly (closed and open position, person adjusting the limit switches should have electric licenses, knowledge and experience, adjustment of the limit switches should be made in accordance with the motor's operation and maintenance manual;... -
Page 45: Misuse Of The System
No power supply to the 230V sensor. Check the sensor powering. Despite the installed wind sensor, The sensor is not assigned/set. Refer to the relevant manual to the powered product does not move assign/set up the sensor.. to the upper position in strong winds. -
Page 46: System Use And Maintenance
If the product is used in other way than described in this documentation or modified without the authorization of SELT Sp. z o.o. then this is considered as misuse. -
Page 47: Indications Of Risk, Breakdown Or Accident
INDICATIONS OF RISK, BREAKDOWN OR ACCIDENT Description of the residual risk Risk factor Description of the correct procedure - disconnect the product from the power supply Accident - take first aid measures for the injured - call for help – tel. 112 - disconnect the product from the power supply, - remove users from the danger zone, - in case of fire use only class ABC fire extinguishers,... -
Page 48: 6.4. Technical Inspections And Repairs
Technical inspections Performed on request for a fee by the SELT company or a specialized installer after the warranty period has expired. The scope is each time determined by a specialized assembly team, and the execution is confirmed by a service report. -
Page 49: Complaint / Technical Defects
Any incorrect/unusual operation of the system or abnormal noises of its operation require user intervention and notification to a specialized installer. Repairs are performed by SELT Sp. z o. o. or a specialized assembly team on the basis of a separate agreement. -
Page 50: Product Disassembly / Utilisation / Disposal
PRODUCT DISASSEMBLY / UTILISATION / DISPOSAL Improper disassembly of the system can cause serious personal injury and damage the system. Disassembly of the system should be entrusted to a properly specialized assembly team or a person with appropriate health and safety training and knowledge in the field of recovery. Disposal of waste electrical and electronic equipment After the end of the product's life, in order to dispose of it, it is necessary to dismantle it and segregate individual materials and elements in accordance with the Regulation of the Minister of Climate of January 2, 2020 on the waste catalog. -
Page 51: Information Accompanying The Ce Marking
INFORMATION ACCOMPANYING THE CE MARKING Marking on the product: Marking on accompanying documents SELT Sp. z o. o. SELT Sp. z o. o. Opole, ul. Wschodnia 23A Opole, ul. Wschodnia 23A POLAND POLAND Outdoor shutter pergola EN 1090-1 Pergola SB400PRO... -
Page 52: Warranty Exclusions
WARRANTY EXCLUSIONS General warranty conditions are available on www.selt.com. If the SELT Sp. z o.o. the website is inaccessible then warranty terms and conditions can be obtained from the sales representative of SELT Sp. z o.o. 10.1 WARRANTY EXCLUSIONS SELT Sp. z o.o. shall not bear responsibility for the following cases and the warranty will not cover: ... -
Page 53: Appendix No 1 (Somfy Pergola Tilt 0 Motor Operating Manual)
Notwithstanding the above, the scope of responsibility of SELT Sp. z o. o. is limited and results from the contract concluded with the buyer of the product.
