E
V
HD-IP200
DGE
IS
HARDWARE INSTALLATION GUIDE
VERSION 8.0 – MARCH 22
Thank you for purchasing the EdgeVis HD-IP200. This document explains how to physically configure the HD-IP200.
As well as identifying the available connectors and status indicators on the device, it also details how to add your
desired SIM card to it. This document should be read in conjunction with the IP Series, HD-Q800, 4K-R800 - Setup
Guide, which covers the web-based setup interface for all devices in the IP Series range, including the HD-IP200.
© Copyright 2020 Digital Barriers plc
Advertisement
Table of Contents
Related Manuals for Digital Barriers EDGEVIS IP Series
Summary of Contents for Digital Barriers EDGEVIS IP Series
- Page 1 SIM card to it. This document should be read in conjunction with the IP Series, HD-Q800, 4K-R800 - Setup Guide, which covers the web-based setup interface for all devices in the IP Series range, including the HD-IP200. © Copyright 2020 Digital Barriers plc...
-
Page 2: What Is In The Box
EDGEVIS HD-IP200 HARDWARE INSTALLATION Introduction Before proceeding with the installation and setup of your HD-IP200 unit, please ensure that you check the package contents listed below, refer to the installation notes on the next page and consult the Quick Start Guide that was supplied with your unit for step-by-step instructions on preparing hardware and software components. -
Page 3: Safety Notes
EDGEVIS HD-IP200 HARDWARE INSTALLATION SAFETY NOTES The EdgeVis Encoder has been designed for use in indoor environments. It can operate in temperatures from 0˚C to +50˚C whilst powered from 12V DC. All deployments of an HD-IP200 encoder unit should ensure that the device is not mounted: •... -
Page 4: Section 1- Basic Operations Of The Unit
EDGEVIS HD-IP200 HARDWARE INSTALLATION Section 1- Basic operations of the unit The EdgeVis HD-IP200 is a small and robust device, ideally suited for use in fixed installations for the recording and live streaming of video from a single IP camera. Device connectors The HD-IP200 features integral TVI streaming using an internal 4G modem, external Wi-Fi adapter or wired LAN, and archiving onto external SSD/HDD. -
Page 5: Connecting Ip Cameras
EDGEVIS HD-IP200 HARDWARE INSTALLATION Powering the device and switching it on/off The HD-IP200 must be powered using an AC/DC adapter (supplied). To switch the unit on simply connect the output cable from the AC/DC adapter to the DC input connector on the front panel of the HD-IP200 and connect the AC/DC adapter to the mains power outlet. - Page 6 EDGEVIS HD-IP200 HARDWARE INSTALLATION Updating the software on the unit Once notified of a new software release by Digital Barriers, updates are available for download from the EdgeVis support site (see below for link) for installation onto the device. There are three ways to update the firmware: •...
-
Page 7: Section 2 - Configuring Communications On The Hd
EDGEVIS HD-IP200 HARDWARE INSTALLATION Section 2 - Configuring communications on the HD- IP200 The HD-IP200 supports communications over wired LAN, Wi-Fi and Cellular. A cellular or Wi-Fi connection requires the use of an external USB device. Refer to the IP Series, HD-Q800, 4K-R800 - Setup Guide for instructions on this step. - Page 8 EDGEVIS HD-IP200 HARDWARE INSTALLATION Connecting over a wired LAN connection When using a wired LAN connection as the communications bearer, connect an Ethernet cable into the LAN connector on the front of the HD-IP200. The encoder also includes a driver for the USB to Ethernet adapters using the Asix AX88772 chipset.
-
Page 9: Setting Up The Encoder
EDGEVIS HD-IP200 HARDWARE INSTALLATION Section 3 – Next Steps… After unpacking the encoder, inserting a SIM card, and wiring up your encoder the next step is to perform the initial setup, where comms settings, server details and IP Cameras are configured. Setting up the encoder With the encoder unpacked and all of the physical setup complete it is time to set up the encoder so that it is available on the EdgeVis Server for viewing. -
Page 10: Appendix A - Troubleshooting And Frequently Asked Questions
EDGEVIS HD-IP200 HARDWARE INSTALLATION Appendix A - Troubleshooting and frequently asked questions How many channels does the HD-IP200 support? The HD-IP200 can record and transmit one camera. What level of recording and streaming performance is achievable? Based on the processing power of the HD-IP200, the unit can typically achieve 25/30 fps of 1080p quality recording whilst simultaneously streaming one 1080p quality video at 10 fps. - Page 11 EDGEVIS HD-IP200 HARDWARE INSTALLATION What bearers can the HD-IP200 use to transmit video to EdgeVis Server? The HD-IP200 can use an external cellular modem for efficient streaming over commercially available cellular networks. It can also transmit using its inbuilt LAN port or optional Wi-Fi module. EdgeVis optimises its transmission to the characteristics of the bearer that it is being used to maximise performance.
-
Page 12: Fcc Compliance
EDGEVIS HD-IP200 HARDWARE INSTALLATION FCC COMPLIANCE This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with instructions, may cause harmful interference to radio communications.
